VEVOR Thicknesser M1B-LS-3301 Manuale utente
M1B-LS-3301
USER MANUAL
Thicknesser
Have product questions? Need technical suppo? Please feel free to contact us:
CustomerSe[email protected]
NEED HELP? CONTACTUS!
This is the original instruction, please read all manual instructions carefully before
operating. VEVOR resees clear interpretation of our user manual. The appear-
ance of the product shall be subject to the product you received. Please forgive us
that we won't inform you again if there is any technology or software updates on
our product.
Thicknesser
01
02
IMPORTANT: carefully read the instructions in this manual as well as the general
safety instructions before using this tool.
Keep the packaging material out of the reach of children -- risk of suocation.
WARNING ! Always take basic safety precautions when using power tools to
safeguard against the risk of re、electric shock and /or personal inju.
1. For safe operation. We recommend that you take appropriate measures for the
protection of hearing if the sound pressure of 85dB (A) is exceeded
2. Keep the work area clean.Cluttered work areas increase the risk of accidents and
injuries.
3. Keep the workplace environment safe. Do not use power tools in damp or wet
areas. Do not expose power tools to rain. Make sure the work area is well lit. Do not
use power tools in explosive environments, such as in the vicinity of ammable
liquids、gases or dust.
4. Protect against the risk of electric shock. Avoid body contact with eahed
suaces, Such as pipes,radiators,cookers and refrigerators.
5. Keep children at a safe distance. Do not allow onlookers to touch the tool or the
extension cord. Onlookers should be kept away from the work area.
6. Put away tools that are not being used . When not in use, sto the tool in a d
place out of the reach of children.
7. Do not force the tool . The tool does the job better and safer when used at the
rate for which it was designed.
8. Use the correct machine. Do not force small machines or accessories to peorm
jobs that require a poweul machine. Use tools only for their intended purpose.
9. Wear suitable clothing. Do not wear loose clothing or jewelle. they can be
caught in moving pas. Non-slip shoes are recommended when working outdoors.
Wear a hair net if you have long hair.
10. Wear safety glasses. Wear a dust mask if the work generates dust.
11. Be careful with the cable. Never car the tool by the cable. Do not pull the
cable to disconnect the plug from the socket. Keep the cable away from heat、oil
and sharp edges.
SAFETY INSTRUCTIONS
Before using the tool, read the instruction book carefully.
Class ll appliance, reinforced insulation or double insulation
03
12. Secure the workpiece. Secure the workpiece with stand. This is safer than using
your hands and means you have both hands free to operate the tool.
13. Do not overreach. Always maintain a rm footing and good balance.
14. Maintain the tool in good care. Keep cutting tools sharp an chean for better,
safer work. Follow the instructions for lubricating and for the replacement accesso-
ries. Check power cords regularly. If damaged, they must be replaced at an autho-
rised seice centre. Check extension cords at regular inteals and replace them if
they are damaged. Keep the hands clean、d and free from oil and grease.
15. Always unplug the power cord. when the tool is not being used, and before
caring out seice work or changing accessories, such as knife blades/carbon
brush/gears and so on.
16. Remove adjuster keys/spanners and other assembling tools. Remove adjuster
keys/spanners and other assembling tools before staing the power tool.
17. Avoid accidental staing. Never car a power tool with your nger on the
switch when it is connected to the mains. Make sure the power switch is in the OFF
position before plugging in the power cord.
18. If using the tool outdoors. only use an extension cord approved for outdoor use.
19. Stay ale . Always be careful when using the equipment. Use your common
sense ,Do not use the tool if you are tired.
20. Connect dust extraction equipment . If dust extraction and dust collection
equipment is provided. This should be connected and used correctly.
21. Check for damaged pas. If a guard or some other pa has been damaged,
check carefully before using the tool to ensure that it will operate correctly and as
intended. Make sure that moving pas are properly adjusted and do not jam and
that no pas are incorrectly tted or damaged. Check for any other factors that
could inuence functionality. Guards or other pas that are damaged must be
repaired or replaced by an authorised seice centre. Unless otherwise specied in
these instructions. If the power switch does not work, it must be replaced by an
suthorised seice centre. Do not use the tool if it cannot be switched on and o
using the power switch.
WARNING! The use of accessories or attachments other than those recommended in
these operating instructions can result in personal inju. Repairs must only be
carried out by qualied personnel. This power tool has been manufactured in
compliance with current safety standards and requirments. Repair may only be
carried out by qualied personnel using identical spare pas. Failure to car out
repairs currectly can result in the risk of personal inju/death or material damage.
NOTE: A tempora voltage drop can occur when staing the machine. Which could
aect other equipment. If the main supply impedance Zmax. is lower than
0.206ohms, this kind of inteerence is common. Contact your electricity supplier for
more information.
04
1. Wear safety glasses, Don’t sent wood into outfeed side.
2. Before use, check that all screws connections are properly tightened.
3. Do not force the tool. Let the feed mechanism do the work. Never inse objects or
body pas in the outfeed.
4. Check regularly that the rubber roller and iron roller are clean. If the rollers are
contaminated the workpiece will not infeed correctly- risk of persona inju.
5. Do not machine workpieces with many knots or sprigs.
6. The operating position is in front of the machine. Stand by the side of the infeed
table.
7. Remove any nails,screws and other metal objects from the workpiece before
machining.
8. Check that the blades are correctly installed.
9. Handle the knife blades with care--risk of personal inju and/or damage to
propey.
10. Never sta to planer until the blade shaft has reached full speed.
11. Never use blunt blades-risk of kickback.
12. Always replace or sharpen all blades at the same time. All blades must be of the
same size and weight.
13. Never inse your ngers or other body pas in the chip outlet side--risk of
personal inju-- DANGER.
14. Pls check the recoil claw is in the correct position.
15. If infeed wood not smooth,pls don’t force the wood,check if machine have some
problems.
16. Do not wear gloves to plane wood.
17. Do not plane wet wood, will cause the feed roller to slip and lead machine
broken.
18. Do not plane hardness wood, will shoen the working life of the knife blades.
19. Do not plane the wood too long, the machine will be overloaded,infulence the
wood planing suace eect.
IMPORTANT SAFETY INSTRUCTIONS
05
TECHNICAL DATA
Model：M1B-LS-3301
For US user
M1B-LS-3301
For European users
Specs:
Rating(s):
Feed Speed:
Max.planing width:
blade:
Planing depth:
Planing height:
Working table size:
Packing size:
110V~60Hz 2000W
6m/min
330mm
2pcs
0-3mm
6-160mm
330x290mm
570×360×505mm
230V~50Hz 2000W
6m/min
330mm
2pcs
0-3mm
6-160mm
330x290mm
570×360×505mm
G.W: 29.3kg
N.W: 27.5kg
29.3kg
27.5kg
Tested wood width is 150mm for feeding speed
06
DESCRIPTION
1. The tool is designed for planing wooden planks and d wood. It is forbidden to
plane other materials. such as metals、plastics、branches、tree trunks、wet
wood and ve hard wood.
2. The tool is intended for household and professional use .
3. Pls use this machine under correct operation, if don’t know how to use it, pls
contact with facto.
E-Knife blade bit gauge F-Depth adjustment handle G-Caring handle
H-depth label I-Overcurrent protective device J-Extension table
K-Roller bar L-Switch M-Allen wrench
N-Open spanner O-Rubber feet W-Carbon brush cover
Advised wear ear protection.
Advised wear safety glasses.
Advised wear dusk mask.
07
Unpacking
Carefully unpack the machine. The packaging must be recycled in accordance with
local regulations.
WARNING! Turn o the machine and unplug the power cord before cleaning 、
peorming maintenance and adjustment.
Assembly
Before using the machine must be in accordance with the requirements of the
assembly complete.
Evacuation of shavings and wooddust:
The tool is equipped with a dust hood with vacuum cleaner connection (V),this dust
hood at the bakc of the machine for connection to a vacuum cleaner connection. A
exible hose(not supplied) can be connected to the collector . Some species of wood
or processed wood produce sawdust harmful to health.
Pls attention: Always use the tool must be connected to a vacuum cleaner.
Install rubber feet (O):
If no need use foot frame to working ,pls put 4pcs rubber feet into the fourholes in
the buttom of the machine.
Install depth Adjustment handle
Place the depth adjustment handle (F) on the protruding shaft to the right of the
machine’s top suace. Push on the handle rmly and lock it with the supplied screw.
OPERATION STEPS
08
Adjust depth of the planer
In order to be able to completely correct and safe operate this machine, User
must be know how to correct adjust. Ve Impoent!!!
Rotate the depth adjustment handle(F) a circle, the machine depth can be rised
or lowered by 1.5 mm.
Before using, pls plane the wood a few times, that’s can be ensure the surgace of the
wood is completely horizontal in later use. Please refer to the correct wood width
range to adjust the depth of the one-time planer:
0~100
width of wood (mm) cutting depth (mm)
160~210
210~330
0~3
0~2
0~1
