VIA Technologies VX900 Manuale utente

USER'S MANUAL

For

VlA VX900 Express Chipset

Based Motherboard

Trademark:

* Specifications and Information contained in this documentation are furnished for information use only, and are

subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

NO. G03-MVBVX9GSM-F

Rev: 1.0

Release date: November, 2010

Environmental Safety Instruction

zAvoid the dusty, humidity and temperature extremes. Do not place the product in any

area where it may become wet.

z0 to 40 centigrade is the suitable temperature. (The figure comes from the request of

the main chipset)

zGenerally speaking, dramatic changes in temperature may lead to contact malfunction

and crackles due to constant thermal expansion and contraction from the welding

spots’ that connect components and PCB. Computer should go through an adaptive

phase before it boots when it is moved from a cold environment to a warmer one to

avoid condensation phenomenon. These water drops attached on PCB or the surface

of the components can bring about phenomena as minor as computer instability

resulted from corrosion and oxidation from components and PCB or as major as short

circuit that can burn the components. Suggest starting the computer until the

temperature goes up.

zThe increasing temperature of the capacitor may decrease the life of computer. Using

the close case may decrease the life of other device because the higher temperature in

the inner of the case.

zAttention to the heat sink when you over-clocking. The higher temperature may

decrease the life of the device and burned the capacitor.

Environmental Protection Announcement

Do not dispose this electronic device into the trash while discarding. To minimize pollution

and ensure environment protection of mother earth, please recycle.

CHAPTER 1 INTRODUCTION OF VIA VX900 MOTHERBOARDS

1-1 FEATURES OF MOTHERBOARD................................................................1

1-1.1 SPECIAL FEATURES OF MOTHERBOARD .................................2

1-2 ITEM CHECKLIST.........................................................................................2

1-3 SPECIFICATION...........................................................................................3

1-4 LAYOUT DIAGRAM......................................................................................4

CHAPTER 2 HARDWARE INSTALLATION

2-1 MEMORY MODULE INSTALLATION...........................................................5

2-2 EXPANSION SLOTS.....................................................................................6

CHAPTER 3 CONNCTORS, HEADERS & JUMPERS SETTING

3-1 CONNECTORS .............................................................................................6

3-2 HEADERS .....................................................................................................8

3-3 JUMPER SETTING .......................................................................................11

CHAPTER 4 USEFUL HELP

4-1 HOW TO UPDATE BIOS ..............................................................................12

4-2 TROUBLE SHOOTING .................................................................................12

TABLE OF CONTENT

Chapter 1

Introduction of VIA VX900 Motherboards

1-1 Features of Motherboard

The VIA VX900 Express chip based motherboard series are based on VIA VX900

Express chipset technology which supports the embedded VIA Nano™2007L Series

CPU

The VIA VX900 chipset based motherboard series comes with an integrated DDRIII

memory controller for dual channel DDRIII 1066 /DDRIII 1333 MHz system memories

which are expandable to 4 GB capacity and the new generation of PCI Express

interface for the latest graphics AMD cards. The VIA VX900 Express chipset

motherboard series are absolutely the ultimate solution for game enthusiasts and

applications, and it also meets the demanding usage of computing of gaming,

multimedia entertainment and business applications.

The motherboard provides two serial ATA2 interfaces of 3.0 Gb / s data transfer rate

for two serial ATA devices.

The VIA VX900 Express chipset Based motherboard provides Ethernet LAN function

by using Megabit LAN chip which support 10M / 100M data transfer rate. Embedded

6-channel CODEC is fully compatible with Sound Blaster Pro®standards that offer

you with the home cinema quality and absolutely software compatibility.

The VIA VX900 Express chipset based motherboard series offer one PCI-Express2.0

x16 graphics slot and one 32-bit PCI slot guarantee the rich connectivity for the I/O of

peripherals.

Embedded USB controllers as well as capability of expanding to 8 of USB2.0

functional ports delivering 480Mb/s bandwidth of rich connectivity, these

motherboards meet the future USB demands which are also equipped with hardware

monitor function on system to monitor and protect your system and maintain your

non-stop business computing.

Some special features--- CPU Vcore Input & Output OC-CON in this motherboard is

designed for power user to use the over-clocking function in more flexible ways. But

please be caution that the over-clocking may cause the failure in system reliability.

This motherboard provides the guaranteed performance and meets the demands of

the next generation computing. But if you insist to gain more system performance with

variety possibilities of the components you choose, please be careful and make sure

to read the detailed descriptions of these value added product features, please get

them in the coming section.

1-1-1 Special Features of motherboard

CPU Vcore Input and Output adopt OC-CON solid capacitors. (High-polymer

Solid Electrolysis Aluminum Capacitors)

OC-CON solid capacitors make it possible for motherboard to work from 55 degrees

Centigrade below zero to 125 degrees centigrade. OC-CON capacitors possess

superior physical characteristics to prolong product life ten times than corresponding

motherboard without capacitors every time working temperature increases 20

degrees. Life of product of motherboard with solid capacitors declines only 10% of

those without solid capacitors as well under same conditions.

1-2 Item Checklist

5VIA VX900 Chipset based motherboard

5DVD for motherboard utilities

5User’s Manual

5SATA Cable(s)

5I/O back panel shield

1-3 Specification

Spec Description

Design zPCB size: 17cmx19cm

Chipset zVIA VX900 Express Chipset

Embedded CPU zVIA Nano™Series 1.6 GHZ Processor

Memory Sockets

zDDRIII module slot x 2

zSupport 2pcs DDRIII 1066/DDRIII 1333 memory modules

expandable to 4 GB

zSupport dual channel function

Expansion Slots z1pcs PCI-Express2.0 x16by8 lane slot

z1pcs 32-bit PCI slot

Serial ATA2 zThe VIA VX900 chipset supports two internal Serial ATA

ports for two SATA devices providing 3.0 Gb/sec data

transfer rate.

Ethernet LAN

zIntegrated PCI-E LAN chip

zSupports Fast Ethernet LAN function provide 10Mb/100Mb

data transfer rate.

6-CH HD Audio z6chanel HD Audio Codec integrated

zSupport 6-channel 3D surround & Positioning Audio

zAudio driver and utility included

BIOS zAMI 32MB SMT Flash ROM

Multi I/O

zHDMI Connector x1

zVGA Connector x1

zSATA connector x2

zUSB2.0 port x6 and header x1

zRJ-45 LAN connector x1

zAudio connector x1 (6-CH Audio)

zFront Panel Audio Header x1

zSerial Port headerx1

1-4 Layout Diagram

VIA Nano™ L2007 CPU

PCI Slot

CPU FAN1

RJ-45 Over

USB Connecto

Power LED Header

Speaker Header

Front Panel Audio Header

USB Headers

SYSFAN1

ATX 12V

Power Connector

RJ-45 LAN

Line-IN

MIC-IN

VGA Connector

DDRIII Slot x 2

HDMI

Connector

USB Connectors

USB Connector

Serial-ATAII Connecto

(SATA 1, 2, )

Audio Connector

COM Header

PCI Express

2.0x16by8lane slot

Line-OUT

HDMI

Connector

VGA Connector

JP1

LAN Chip

USB Connecto

USB Connectors

6CH HD

Audio Decode

VIA VX900 Chipset

HDMI-SPDIF

Header

Front Panel

Header

Chapter 2

Hardware Installation

WARNING! Turn off your power when adding or removing expansion cards or

other system components. Failure to do so may cause severe

damage to both your motherboard and expansion cards.

2-1 Memory Module Installation

This motherboard provides two 240-pin DDR III DUAL INLINE MEMORY MODULES

(DIMM) socket for DDR III memory expansion available to maximum memory volume

of 8 GB DDRIII SDRAM.

Valid Memory Configurations

Bank 240-Pin DIMM PCS Maximum Capacity

DIMM1 DDR III 1066/ DDR III1333 X1 4GB

DIMM2 DDR III 1066/ DDR III1333 X1 4GB

Total System Memory (Max 4GB) 2 8GB

Recommend DIMM Module Combination

：

1. One DDRIII Memory Module ----Plug in DIMMM1.

2. Two DDRIII Memory Modules---Plug in DIMM1 & DIMM2 for Dual channel function

Dual channel Limited!

1. Dual channel function only supports when 2 DIMM Modules plug in either both DIMM1

& DIMM2.

2. Memory modules plugged in the same color DIMM must be of the same type, same

size, and same frequency for dual channel function.

Install DDR SDRAM modules to your motherboard is not difficult, you can refer to

figure below to see how to install DDRIII 1066/DDRIII 1333 SDRAM module.

DIMM2(BANK2+BANK3)

DIMM1(BANK0+BANK1)

DIMM1 & DIMM2: Dual Channel

NOTE! When you install DIMM module fully into the DIMM socket the eject

tab should be locked into the DIMM module very firmly and fit into its

indention on both sides.

Installation Tips：

Open the two plastic clips of memory slots then push down the module

vertically into the slot. See to it that the hole of the module fit into the notch of

the slot;

The two plastic clips will automatically close if the memory module is fitted in a

proper way.

2-2 Expansion Slots

The VIA VX900 Express chipset based motherboard series offer one PCI-Express2.0

x16 graphics slot and one 32-bit PCI slot guarantee the rich connectivity for the I/O of

peripherals.

Chapter 3

Connectors, Headers &Jumper Setting

3-1 Connectors

(1) Power Connector (24-pin block): ATXPWR1

ATX Power Supply connector: This is a new defined 24-pins connector that

usually comes with ATX case. The ATX Power Supply allows using soft power

on momentary switch that connect from the front panel switch to 2-pins Power

On jumper pole on the motherboard. When the power switch on the back of the

ATX power supply turned on, the full power will not come into the system board

until the front panel switch is momentarily pressed. Press this switch again will

turn off the power to the system board.

** We recommend that you use an ATX 12V Specification 2.0-compliant power

supply unit (PSU) with a minimum of 350W power rating. This type has 24-pin

plugs.

** If you intend to use a PSU with 20-pin and 4-pin power plugs, make sure that the

20-pin power plug can provide at least 15A on +12V and the power supply unit

has a minimum power rating of 350W. The system may become unstable or may

not boot up if the power is inadequate.

PCI-E2.0 x16@8 Lane Slot

PCI slot

** If you are using a 20-pin power plug, please refer to Figure1 for power supply

connection. Power plug form power supply and power connectors from

motherboard both adopt key design to avoid mistake installation. You can insert

the power plug into the connector with ease only in the right direction. If the

direction is wrong it is hard to fit in and if you make the connection by force if is

possible.

Figure1：20-pinpowerplug Figure2：24-pin power plug

(4) USB Port connector: USB port fromUL1, CN1, USB3

The connectors are 4-pin connectors that connect USB devices with the 480

Mbit / sec data transfer rate to the system board.

(5) LAN Port connector: RJ-45 LAN port from UL1

This connector is standard RJ45 over USB connectors for Network connection.

The connector supports 10MB/100MB/1G B/s data transfer rate

(6) Audio Line-In, Lin-Out, MIC: AUDIO

These Connectors are 3 Phone-Jack for LINE-OUT, LINE-IN, MIC audio

connections.

Line-in: (BLUE) Audio input to sound chip

Line-out: (GREEN) Audio output to speaker

MIC: (PINK) Microphone Connector

ROW

PIN ROW1 ROW2

1 3.3V 3.3V

2 3.3V -12V

3 GND GND

4 5V Soft Power On

5 GND GND

6 5V GND

7 GND GND

8 Power OK -5V

9 +5V (for Soft Logic) +5V

10 +12V +5V

11 +12V +5V

12 +3V GND

Line-IN

MIC-IN

VGA Connector USB Connectors

Line-OUT

HDMI

Connector

USB Connectors

Indice

Altri manuali VIA Technologies Scheda madre

VIA Technologies

VIA Technologies P4XB-MA Manuale utente

VIA Technologies

VIA Technologies P4PB ULTRA-URL Manuale utente

VIA Technologies

VIA Technologies EPIA-P820 Manuale utente

VIA Technologies

VIA Technologies EPIA-M10000G - VIA Motherboard - Mini ITX Manuale utente

VIA Technologies

VIA Technologies VT310-DP Manuale utente

VIA Technologies

VIA Technologies EPIA-PE Manuale utente

VIA Technologies

VIA Technologies PT-6VAX Manuale utente

VIA Technologies

VIA Technologies Epia LT15000G Manuale utente

VIA Technologies

VIA Technologies NR10000EG - VIA EPIA Nano ITX Motherboard Manuale utente

VIA Technologies

VIA Technologies EITX-3000 Manuale utente

VIA Technologies

VIA Technologies ARTIGO A2000 - VIA ARTiGO Barebone Storage... Manuale utente

VIA Technologies

VIA Technologies EPIA-P710 Manuale utente

VIA Technologies

VIA Technologies EPIA-CN13000G - VIA Motherboard - Mini ITX Manuale utente

VIA Technologies

VIA Technologies VT82C694X Pro Manuale utente

VIA Technologies

VIA Technologies EPIA-PX Manuale utente

VIA Technologies

VIA Technologies EPIA-5000 - VIA Motherboard - Mini ITX Manuale utente

VIA Technologies

VIA Technologies Mini-ITX Mainboard EPIA-MII Manuale utente

VIA Technologies

VIA Technologies EPIA ME6000 - VIA Motherboard - Mini ITX Manuale utente

VIA Technologies

VIA Technologies EPIA-PX10000G - VIA Motherboard - Pico ITX Manuale utente

VIA Technologies

VIA Technologies VB8002 Manuale utente

VIA Technologies

VIA Technologies PT-TVBT Manuale utente

VIA Technologies

VIA Technologies VIA KT266A ChipsetMotherboard Manuale utente

VIA Technologies

VIA Technologies P4M890DMP VT8237R Plus Manuale utente

VIA Technologies

VIA Technologies EPIA-N Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente
