Viper AS1050R Guida utente

Use and maintenance

Operating guidelines AS1050R

Disconnect battery charger

and store the cable.

Fill the solution tank with

fresh water and add low foam

detergent according to needs.

The water temperature must

not exceed 40 °C.

Install the squeegee and x it

by using the two knobs.

Adjust squeegee angle and

blade pressure for optimal

water pick-up by turning

the adjustment knob on

the support.

Click One Touch button to

activate all functions

Adjust the maximum

speed with the speed

adjustment dial.

Use buttons to change

cleaning settings from the

dashboard

Turn the main key to on and press the click on button to install the brush

automatically. Deck will lower and brushes turn slowly to attach.

Loosen the two knobs to

remove the side skirt.

To install the brush/pad holder, pull up the metal handle and slide

in the brush/pad holder until it stops against the pins in the proper

position and release the handle. Put back the side skirt

Solution level indicator is on the side of the tank showing current

level. If the solution tank is empty or recovery tank full, an indicator

on the display will show up with sound warning.

During the cleaning job it’s

possible to adjust the solution

ow, the brush pressure,

activiting Eco Mode or Silent

Mode from the dashboard.

October 2020

Local Viper dealer:

Phone number:

SN:

Maintenance

Operating guidelines AS1050R

October 2020

Turn OFF the machine using

the key.

Empty the tank with the hose in the back. Empty and

clean the debris tray in the tank, ush&clean out the

recovery tank.

Empty solution tank.

Check and clean lter (weekly).

With the key turned on press the brush

click off button to remove the brushes/pad

holders for inspection and cleaning.

Park the machine leaving the recovery tank

open.

Take the squeegee off, check and clean

the blades.

Hang the squeegee on the machine to dry.

Connect the battery charger to the

charging inlet on the machine and switch

on the charger.

V112_0019_V1 10/2020
