Volt VAL-9501-4036-BBZ Manuale utente
VOLT®Low Voltage Landscape Lighting
VOLT® Tranquility Brass LED Hanging Light
VAL-9501-4036-BBZ
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2018, VOLT®Lighting, Lutz FL USA 33549 • All rights
reserved. [email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
VOLT®Tranquility Brass LED Hanging Light
VAL-9501-4036-BBZ
INSTALLATION INSTRUCTIONS
www.voltlighting.com
Important: Please Read Before Installation
!
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M) or
more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with wire connectors that are suitable
for outdoor use.
5. The unit low voltage cable should:
a) Be protected by routing in close proximity to the luminaire or
tting, or next to a building structure such as a house or deck;
b) Not be buried except for a maximum 6 inches (15.2 cm) in order to
connect to the main low voltage cable; and
c) Have the length cut o so that it is connected to a connector within
6 inches (15.2 cm) from the building structure, a luminaire, or tting.
6. If additional lengths of low voltage cable are required, please contact
www.voltlighting.com or call 1-813-978-3700.
Important Safety Instructions
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn o/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may damage lamp.
6. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
Package Contents
A. (1) Fixture Body
B. (1) Fixture Chain
C. (1) Quick Link
D. (1) Mounting Bracket
Product Dimensions
2.2”
5” 5.4”
6.6”
Parts Required (sold separately)
A. (3) Self-tapping Screws
B. (3) Wall Anchors
C. (3) Flat Washers
D. (1) LED MR16 Lamp
E. (1) Low Voltage Transformer
F. (1) Exterior Grade Caulk
INSTALLATION INSTRUCTIONS
www.voltlighting.com
VOLT®Tranquility Brass LED Hanging Light
VAL-9501-4036-BBZ
Lamp
Shade
Socket
Shade
Holder
Install Lamp
Install Shade
2
3
Insert the lamp with the correct wattage and type
marked on the xture label. These xtures use LED
MR16s (pictured) and LED GU4 Bi-pins (not pictured).
CAUTION: This xture is for LED use only. Do not exceed
maximum wattage marked on luminaire label.
NOTE: DO NOT touch lamp with bare hands. Use soft
cloth to handle lamp.
Thread the shade back onto the shade
holder and hand tighten until snug.
Remove Shade
1
Shade
Holder
Shade
Unscrew the shade and remove it from
the shade holder to expose the socket.
Install Mounting Bracket
Attach Fixture to Mounting Bracket
4
5
Wall Anchor
(sold separately)
Flat Washer
(sold separately)
Supply Wires
Fixture Chain
Self-tapping Screw
(sold separately)
Fixture Body
Mounting
Bracket
Mounting
Bracket
Ceiling
Quick Link
Ceiling Loop
Attach the mounting bracket
onto the desired ceiling surface.
Secure with the at washers and
self-tapping screws.
Note: Wall anchors are
required for certain installation
conditions (concrete or brick
walls). Mark on the desired
ceiling surface for wall anchors
by using the holes on the
mounting bracket. Remove
the mounting bracket and drill
proper holes on the desired
ceiling surface and then insert
the wall anchors.
Adjust the xture chain to the desired
length by removing the links if needed.
(Note: Pliers are required for this step).
With the xture chain unattached to the
xture loop on the top of the xture body;
or the ceiling loop on the underside of
the mounting bracket, pull the supply
wires through the xture chain alternating
between the links.
After the wires are through the xture
chain, pull the supply wires up and around
the backside of the mounting bracket.
Attach one end of the xture chain to the
xture loop at the top of the xture body.
Lift the xture body and xture chain up
and attach the other end of the xture
chain onto the ceiling loop on the bottom of
the mounting bracket with the quick link.
The xture will now hang safely. Close the
chain loop at the ceiling loop.
INSTALLATION INSTRUCTIONS
www.voltlighting.com
VOLT®Tranquility Brass LED Hanging Light
VAL-9501-4036-BBZ
Lay out the supply cable to the transformer. Strip both leads
from the luminaire pigtail. Connect the leads from the luminaire
supply cable to the transformer (sold separately).
Using the exterior grade caulk, caulk
over the hole on the xture loop.
Fixture
Body
Pigtail
Hole
Transformer
(sold seperately)
Exterior Grade
Caulk (sold
seperately)
Supply Wire
Wire Connections
Apply Caulk to the Hole on Fixture Loop
6
6
Specications and product details subject to change without notice.
© Copyright 2018, VOLT®Lighting, Lutz FL USA 33549 • All rights
reserved. [email protected] • 813.978.3700
www.voltlighting.com
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
is-VAL-950x-ver4.pdf
