Volt VPL-1011-4-BBZ Manuale utente

VOLT®Low Voltage Landscape Lighting

VOLT® Guardsman Post Top Light

VPL-1011-4-BBZ

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

- 1 -

VOLT®Guardsman Post Top Light

VPL-1011-4-BBZ

Important: Please Read Before Installation

INSTALLATION INSTRUCTIONS

This xture is intended for installation in accordance with local codes and

the National Electric Code (NEC). Failure to adhere to these codes and

instructions may result in serious injury, property damage and void the

warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situations.

1. Make sure that the power is turned OFF before installing or servicing

this xture.

2. Warning: this xture is not intended to be installed within 10 feet [3

meters] of a pool, spa or fountain.

3. This xture is intended to be used only with a power supply

(transformer) rated maximum of 50 watts (25 AMPS) at 12 volts.

4. Underground Low Energy Cable must not be buried over 6” (15.2 cm)

in order to connect to the main low voltage cable.

5. Wiring connections must be made with UL listed wire connectors that

are suitable for outdoor use.

6. Position the wire connector so that it is located within 6 inches (15.2

cm) from a building structure, a luminaire, or tting.

www.voltlighting.com

Important Safety Instructions

LIGHTED LAMP IS HOT!

WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.

1. Turn off/unplug and allow to cool before reducing lamp.

2. Lamp gets HOT quickly!

3. Do not touch the hot lens, guard or cowl.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time.

6. Use a soft cloth.

7. Oil from skin may damage lamp.

8. Do not operate the xture with a damaged or missing lens or shield.

- 2 -

Package Contents

Product Dimensions

A. (1) Fixture Body

[email protected] • 813.978.3700

6”

7”

6”

Optional Parts (sold separately)

A. (1) Stake

B. (1) Extension Riser

This xture can be mounted to 4x4 wooden post or stake. Please refer

to the respective installation instruction steps per below.

C. (4) Self-tapping Screws

- 3 -

INSTALLATION INSTRUCTIONS

www.voltlighting.com

Install Extension Riser on Fixture

Using a screwdriver, remove the

bottom 4 screws from the xture body.

Pull the lead wire into the center of

the xture through the side wire exit

and then place it through the center

hole going back out. Attach the bottom

back onto the xture body and secure

with the previously removed screws.

Thread a coupler and lock nut to

the bottom of the xture body. Then

attach the extension riser, running the

wire through all pieces.

Fixture

Body

Bottom Screw

Install Stake

Determine the desired location for

mounting the xture. Hammer the stake

into the ground until ange of stake is ush

to grade. To avoid damage to the stake,

place a board on top of the stake while

hammering.

NOTE: If the ground is hard and the stake

is difcult to install, make a crosscut in the

ground using a at shovel.

Board

Stake

Soil

Ground

- 4 -

OPTION A: MOUNT TO STAKE

VOLT®Guardsman Post Top Light

VPL-1011-4-BBZ

Coupler

Lock Nut

[email protected] • 813.978.3700

Install Fixture Body to Stake

Clear away an area in the ground at

the wireway slot on top of the stake.

Lay the luminaire pigtail into the

wireway slot. Then, thread the bottom

end of the extension riser with the

xture body onto the stake. Tighten to

secure the base.

Fixture Body

Base

Stake

Pigtail

Wireway Slot

Extension Riser

- 5 -

Wire Connection

Strip both leads from the luminaire pigtail. Using two wire connectors

(sold separately), connect the leads from the luminaire to the main

supply cable leads.

Pigtail

Main Supply Cable

Wire Connectors

INSTALLATION INSTRUCTIONS

www.voltlighting.com

- 6 -

Remove Top from Base

Install Base to 4x4

Using a screwdriver, unscew the screws

on the side of the base and remove the

top from the base.

Attach the base onto a 4” x 4” square

wood post and secure with the

self-tapping screws. Hand tighten

with a screwdriver.

Screw

Self-tapping

Screw

Remove

WOOD POST

To p

Base

OPTION B: MOUNT TO A 4X4 Post

VOLT®Guardsman Post Top Light

VPL-1011-4-BBZ

[email protected] • 813.978.3700

- 7 -

Screw

Install

To p

Base

Install Top to Base

Attach the top back onto the base

and secure with the screws previously

removed. Hand tighten with a

screwdriver.

Wire Connection

Strip both leads from the luminaire pigtail. Using two wire connectors

(sold separately), connect the leads from the luminaire to the main

supply cable leads.

Pigtail

Main Supply Cable

Wire Connectors

- 8 -

Specications and product details subject to change without notice.

reserved. [email protected] • 813.978.3700

www.voltlighting.com

IS-VPL-1011-ver3.pdf
