Vox PMB-472LF Manuale utente

USER’S

MANUAL

PMB-472LF

ULVCeleron®M

Mini-ITXMotherboard

WithVGA/Sound/2LAN

PMB-472LF M2

PMB-472LF Celeron® M

Mini-ITX Motherboard

With VGA /Sound/2LAN

OPERATION MANUAL

This operation manual is meant to assist both Embedded Computer

manufacturers and end users in installing and setting up the system. The

information contained in this document is subject to change without any

notice.

This manual is copyrighted in February, 2006. You may not reproduce or

transmit in any form or by any means, electronic, or mechanical, including

photocopying and recording.

ACKNOWLEDGEMENTS

All trademarks and registered trademarks mentioned herein are the

property of their respective owners.

CE NOTICE

This is a class A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

FCC NOTICE

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

You are cautioned that any change or modifications to the equipment not

expressly approve by the party responsible for compliance could void

your authority to operate such equipment.

Contents

TABLE OF CONTENTS

CHAPTER 1 INTRODUCTION

1-1 About This Manual ........................................................ 1-2

1-2 System Specification ...................................................... 1-3

1-3 Extra Industrial Application Features................................ 1-6

1-4 Safety Precautions ……………………………………. 1-6

CHAPTER 2 HARDWARE CONFIGURATION

2-1 Jumper & Connector Quick Reference Table ................ 2-2

2-2 Component Locations .................................................... 2-3

2-3 How to Set the Jumpers ................................................. 2-4

2-4 COM Port Connector ……..…………………………... 2-6

2-5 COM4 RI/ Voltage Selection ………………………… 2-8

2-6 RS232/422/485(COM2) Selection ................................ 2-9

2-7 RS232/422/485(COM3) Selection ……………………. 2-10

2-8 Keyboard or PS/2 Mouse Connector .....................….... 2-11

2-9 Reset Connector ............................................................ 2-11

2-10 Hard Disk Drive LED Connector .................................. 2-11

2-11 Power Button …............................................................ 2-12

2-12 External Speaker Connector .......................................... 2-12

2-13 Power LED Connector ……........................................... 2-12

2-14 External SMI Connector ………………………………. 2-13

2-15 Inverter Connector …………………………………….. 2-13

2-16 Clear CMOS Data Selection ………………………….. 2-14

2-17 CPU Fan Connector …………………………………… 2-14

2-18 VGA Connector ………………….…………………… 2-15

2-19 Hard Disk Drive Connector ........................................... 2-16

2-20 Floppy Disk Drive Connector ....................................... 2-18

2-21 Printer Connector .......................................................... 2-19

2-22 Universal Serial Bus Connector ……………………… 2-20

2-23 IRDA Connector ………………………………………. 2-21

2-24 LAN Connector ………………………………………. 2-21

2-25 USB & LAN Connector ……………………………… 2-22

2-26 Wake-On-LAN Connector ……………………………. 2-23

Contents

2-27 LVDS Connector ……………..……………………….. 2-24

2-28 LVDS Panel Voltage Selection ……………………….. 2-25

2-29 ATX Power Connector ………………………………… 2-26

2-30 Sound Connector ………………………………………. 2-27

2-31 CD Audio-In Connector ……………………………….. 2-28

2-32 Speaker Connector …………………………………….. 2-28

2-33 Memory Installation …………………………………… 2-28

2-34 PCI/Riser Card Selection ……………………………… 2-29

2-35 Reset / NMI Selection…………………………………… 2-30

2-36 CF Master/Slave Selection ……………………………. 2-31

2-37 PCI Slot Signal Explanation …………………………... 2-32

2-38 PCI Riser Board Information ………………………….. 2-33

2-39 Digital I/O Port ………………………………………… 2-33

CHAPTER 3 SOFTWARE UTILITIES

3-1 Introduction …………..........................................…....... 3-2

3-2 VGA Driver Utility ……………………………….…… 3-2

3-3 Flash BIOS Update ..............................................…....... 3-4

3-4 LAN Driver Utility …...........................................…...... 3-6

3-5 Sound Driver Utility …………………………………… 3-7

3-6 Intel Chipset Software Installation Utility …..……..….. 3-8

3-7 USB2.0 Software Installation Utility ………………….. 3-9

3-8 Watchdog Configuration ……………………………… 3-10

CHAPTER 4 AWARD BIOS SETUP

4-1 Introduction ................................................................... 4-2

4-2 Entering Setup ............................................................... 4-3

4-3 The Standard CMOS Features ………............................ 4-4

4-4 The Advanced BIOS Features ....................................... 4-7

4-5 Advanced Chipset Features ........................................... 4-9

4-6 Integrated Peripherals …............................................... 4-12

4-7 Power Management Setup ............................................. 4-17

4-8 PNP/PCI Configuration …............................................. 4-19

4-9 PC Health Status …….................................................... 4-21

4-10 Frequency Control ....................................…………...... 4-22

Contents

4-11 Load Fail-Safe Defaults ................................................. 4-23

4-12 Load Optimized Defaults .........................................…. 4-23

4-13 Set Supervisor Password ……………………………… 4-24

4-14 Save & Exit Setup ......................................................... 4-25

4-15 Exit Without Saving ………………………………… 4-26

APPENDIX A EXPANSION BUS

PCI Bus Pin Assignment ..............................................…......... A-2

Mini-PCI Bus Connector Pin Assignment ................................... A-3

Compact Flash Card Connector Pin Assignment ……………. A-4

APPENDIX B TECHNICAL SUMMARY

Block Diagram ........................................................................... B-2

Interrupt Map ............................................................................ B-3

RTC & CMOS RAM Map ........................................................ B-4

Timer & DMA Channels Map .................................................. B-5

I/O & Memory Map ...............................................…................ B-6

Page:1-1

INTRODUCTION

This chapter gives you the information for PMB-472LF. It also

outlines the System specifications.

Section includes:

zAbout This Manual

zSystem Specifications

zExtra Industrial Application Features

zSafety Precautions

Experienced users can skip to chapter 2 on page 2-1

for a Quick Start.

CHAPTER

Chapter 1 Introduction

Page: 1-2 PMB-472LF USER

′

S MANUAL

1-1. ABOUT THIS MANUAL

Thank you for purchasing our PMB-472LF ULV Celeron-M Mini-ITX

Mainboard enhanced with VGA/Sound/2LAN, which is fully PC / AT

compatible. The PMB-472LF provides faster processing speed, greater

expandability and can handle more tasks than before. This manual is

designed to assist you how to install and set up the system. It contains four

chapters. The user can apply this manual for configuration according to the

following chapters:

Chapter 1 Introduction

This chapter introduces you to the background of this manual, and the

specifications for this system. The final page of this chapter will indicate

how to avoid damaging this board.

Chapter 2 Hardware Configuration

This chapter outlines the component locations and their functions. In the

end of this chapter, you will learn how to set jumper and how to configure

this card to meet your own needs.

Chapter 3 Software Utilities

This chapter contains helpful information for proper installations of the

VGA utility, LAN utility, Sound utility, and Flash BIOS Update. It also

describes the Watchdog-timer configuration.

Chapter 4 Award BIOS Setup

This chapter indicates you how to set up the BIOS configurations.

Appendix A Expansion Bus

This Appendix introduces you the expansion bus for Mini-PCI BUS, and

PCI BUS.

Appendix B Technical Summary

This section gives you the information about the Technical maps.

Chapter 1 Introduction

PMB-472LF USER

′

S MANUAL Page: 1-3

1-2. SYSTEM SPECIFICATIONS

zCPU (mPGA479):

Intel® Celeron® M processor.

ULV 600MHz (non L2 cache).

Auto detect voltage regulator.

zMEMORY :

Supports up to 1GB DDR SDRAM.

One 200-pin DDR SO-DIMM sockets on board.

zCACHE :

Built-in CPU

zREAL-TIME CLOCK :

256-byte battery backed CMOS RAM.

Hardware implementation to indicate century rollover.

zBIOS :

Phoenix-AwardBIOS™for plug & play function.

4Mb with VGA BIOS.

Easy update 512KB flash EEPROM.

Support S/IO Setup.

zKEYBOARD CONNECTOR :

Mini DIN connector.

Supports for AT/PS2 keyboard.

zMOUSE CONNECTOR :

Mini DIN connector.

Supports for PS/2 Mouse.

zBUS SUPPORT :

One PCI- Slot

One Mini-PCI Slots

One Compact Flash Bus (for secondary IDE-based)

Chapter 1 Introduction

Page: 1-4 PMB-472LF USER

′

S MANUAL

zDISPLAY :

Integrated Graphic in Intel® 852GM

Support D-Sub 15 pin VGA connector

Support 18/24bit LVDS connector

Support 3.3V/5V LVDS Panel Power selection

Support 12V Panel Backlight

*24bit hardware is ready but Intel does not recommend using.

zIDE INTERFACE :

Two IDE ports support up to four IED devices.

Supports Ultra DMA 33/66/100.

Compact Flash is connected at secondary IDE Bus.

Compact Flash Master/Slave Mode Selectable.

zFLOPPY DISK DRIVER INTERFACE :

Support Floppy Disk Drives 3.5".

zUSB CONNECTOR :

Support up to six USB 2.0 ports.

zLAN ADAPTER :

Dual ports, Realtek RTL8100C (10/100 Mbps)

Support wake-on-LAN function.

zSERIAL PORT :

Four high speed 16550 Compatible UARTs with Send / Receive 16 Byte

FIFOs; COM1:RS-232; COM2/3: RS-232/422/485; COM4: RS-232 with

+12V/+5V

MIDI Compatible

Programmable Baud Rate Generator

zSOUND :

Realtek ALC655 (AC’97 Codec).

Fully Compliant AC’97 Analog I/O Component

16-Bit Stereo Full-Duplex Codec

Four Analog Line-level Stereo Inputs for Connection.

High Quality CD Input with Ground Sense

Stereo Line-Level Output

Interface: Line-In, Line-Out, Microphone, SPDIF, and CD Audio-In.
