VULU STROLLER
Instruction Manual
VULU 01
PLEASE KEEP INSTRUCTIONS FOR FUTURE REFERENCE
POSITIONS
FOLLOW THE MANUFACTURER’S INSTRUCTIONS.
PUT ON ALL THE BRAKES WHENEVER YOU PARK THE STROLLER.
ALWAYS APPLY THE BRAKES WHENEVER THE STROLLER IS STATIONARY.
DO NOT LEAVE CHILDREN UNATTENDED.
SECURE THE CHILD IN THE HARNESS AT ALLTIMES.
DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS STROLLER.
DO NOT USE THIS SEAT WITH ANY OTHER MODELS OF STROLLER.
DO NOT USE THIS BASSINET ONCE THE CHILD CAN SIT UP UNAIDED.
USE THE SEAT IN THE UPRIGHT ONCE THIS OCCURS.
ALWAYS LOAD THE HEAVIER CHILD IN THE FRONT SEAT THEN PLACE THE
LIGHTER CHILD IN THE REAR SEAT. ALWAYS UNLOAD THE REAR CHILD FIRST.
MAKE SURE CHILDREN ARE CLEAR OFANY MOVING PARTS IF YOUADJUST THE
STROLLER, OTHERWISE THEY MAY BE INJURED.
USE THE HARNESS AT ALL TIMES.
WHEN NOT IN USE DISCONNECT SHOULDER STRAPS FROM THE WAIST STRAP
AND/OR BUCKLE.
THE HARNESS CAN FORM LOOPS WHICH MAY BE A STRANGULATION HAZARD.
NEVER LEAVE A HARNESS CONNECTED WHEN NOT FITTED TO A CHILD IN THE
STROLLER.
TO AVOID SERIOUS INJURY ALWAYS USE THE HARNESS PROVIDED TO SECURE THE
CHILD. (ADJUST THE STRAPS TO SUIT THE SIZE OF YOUR CHILDS BODY)
IT IS UNSAFE TO USE ACCESSORIES OTHER THAN THOSE SUPPLIED BY LOVE N CARE.
CARE SHOULD BE TAKEN IF THE STROLLER IS TO BE USED ON STAIRS OR ESCALATORS.
THIS STROLLER SHOULD NOT BE USED NEAR AN OPEN FIRE OR AN EXPOSED FLAME.
CARE SHOULD BE TAKEN WHILST FOLDING AND UNFOLDING THE STROLLER TO
PREVENT FINGERS BEING TRAPPED.
ENSURE YOUR CHILDS FINGERS, HANDS AND ALL OTHER BODY PARTS ARE CLEAR
FROM ANY MOVING PARTS WHEN ADJUSTING THE SEAT OR HANDLE ON YOUR
STROLLER.
WHEN USED IN THE UPPER POSITION MAX WEIGHT OF SEAT: 15KG
WHEN USED IN LOWER POSITION MAX WEIGHT OF SEAT : 9KG
MAXIMUM WEIGHT FOR BASKET: 3KGS
MAXIMUM WEIGHT FOR THE CUP HOLDER: 1KG
MAXIMUM WEIGHT CAPACITY IS: 28KG
WARNING
SAFETY GUIDELINES AND INSTRUCTIONS MUST ALWAYS BE FOLLOWED BEFORE
MAKING USE OF THIS PRODUCT. PLEASE RETAIN THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
THIS PRODUCT COMPLIES WITH PRODUCT SAFETY STANDARD AS/NZS 2088:2009
*PICTURES USED IN THIS MANUAL ARE FOR ILLUSTRATIVE PURPOSES ONLY. THE ACTUAL STROLLER MAY
VARY IN DISPLAY.
1. 2. 3.
4. 5.
6. 7.
8.
PARTS LIST:
MAKE SURE YOU HAVE THE FOLLOWING
1. 2X REAR WHEELS
2. 2X FRONT WHEELS
3. 2X REAR MUDGUARD
4. 2X REAR SEAT ADAPTER (SOLD SEPARATELY)
5. HANDLE BAR (MAIN SEAT)
6. CANOPY (MAIN SEAT)
7. CANOPY SECOND SEAT (SOLD SEPARATELY)
8. PRIMARY SEAT UNIT (LARGE)
9. SECOND SEAT UNIT (SMALL)(SOLD SEPARATELY)
10. HANDLE BAR (SECOND SEAT)(SOLD SEPARATELY)
11. MAIN FRAME
12. TETHER STRAP
WHATS INSIDE
9.
10.
11.
12.
HOW TO ASSEMBLE
UNFOLD THE FRAME
Unclip the latch from the
frame. Pull the frame away from the
handle.
When pulling the stroller away
from the handle make sure you
keep you ngers away from the
joints.
Pull the handle upwards. You should hear
the handle bar locking into place
the sould of a click.
ATTACHING THE FRONT WHEELS
Slide front wheel (2) into the front axel
hole. he wheel should click into place.
Repeat on both sides.
To remove the front wheel: Press the button
on the top of the front axel to release the front
wheel.
To use the stroller in swivel
mode the front lock on the
axel should be upwards.
To lock the front wheels,
press downwards on the
front axel switch.
HOW TO ASSEMBLE
ATTACHING THE REAR WHEELS
Slide the mudguard (3) onto the rail on the
rear axel.
Slide the Mudguard until it clips into position.
You will hear it click.
To remove the mudguard just slide it the
opposite direction.
Place the wheel into the hole located on the
rear axel. Push the wheel inside until it is locked
inside. Pull on it slightly to ensure that it is not
loose.
To remove the wheel press on the middle
release button and pull the wheel out
HOW TO ASSEMBLE
ATTACHING THE SECOND SEAT UNIT TO THE FRAME
(SOLD SEPARATELY)
ATTACHING THE ADAPTERS FOR THE SECOND SEAT
(SOLD SEPARATELY)
To remove the seat from the frame press
the release buttons located on each side
of the seat unit (8) then lift.
Place the seat unit (8) over the openings
on the frame. It should click into place.
Slide the rear seat adapters (5) in the
slots located next to the rear wheels.
once they are locked in you will hear
a click.
To remove the adapters press the
button located on the frame then lift
the adapter out.
Place the seat unit (8) over the openings
on the frame. It should click into place.
HOW TO ASSEMBLE
ATTACHING THE BASKET
To assemble the basket place the
3 velcro straps through the 3
openings located on the front
footrest.
Once they are through the openings
attach them to the velcro slots on the
bottom of the seat unit.
Then you can strap the middle velcro
strap on the assist tube.
Then you can attach the rear velcro
strap around the rear axel.
MAXIMUM WEIGHT LIMIT IS 3KG
HOW TO ASSEMBLE
ATTACHING THE HOOD AND BUMPER BAR
Insert the ends of the Canopy (7)
into the slots located on the
sides of the seat unit (8)
Match the zipper ends together
and then pull it upwards.
The assembled canopy should look
like this.
To use the canopy pull it
forwards.
To close the canopy push it
inwards.
To Attach the bumper bar (6) slide it into the
slots located on each side of the seat units (8)
To remove the bumper bar (6) press the buttons on
the front of the bar then lift it out of the slots.
HOW TO ASSEMBLE
