Wharfedale Pro K Series Manuale utente

K SERIES

K6010

K6012

K6015

WWW.WHARFEDALEPRO.COM

WHARFEDALE PRO K SERIES USER MANUAL

USER MANUAL

IMPORTANT WARNINGS & SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS – Carefully and become familiar with the features

and functions of these products before operating them.

RETAIN THESE INSTRUCTIONS – For future reference.

COMPLY WITH ALL WARNINGS – All warnings and instructions for this

product should be adhered to.

USE WITH AMPLIFIERS – In order to avoid damage to drivers and other

equipment, it is advisable to establish and follow a routine for powering up

and powering down a sound system. With all system components

connected, turn on source equipment (mixers, signal processors, record

and playback units, etc.) BEFORE powering up ampliﬁers. Transient voltages

from powering up source equipment can damage speakers if ampliﬁers are

already turned on. Make sure that ampliﬁer volumes are set to their

minimum settings and power up any system ampliﬁers LAST. It is

recommended that all system components be allowed to stabilize for

several seconds before any source signals are introduced or level setting

adjustments are made. Similarly, when shutting systems down, turn all

ampliﬁers oﬀ ﬁrst, before powering down any other system components.

CABLES – Do not use shielded or microphone cables for connection

between ampliﬁers and speakers. Use only approved speaker cables with

proper connectors.

CAUTION – These professional loudspeaker systems are capable of

generating very high sound pressure levels. Use care with placement and

operation to avoid exposure to excessive volume levels. Permanent hearing

damage can result when operated to extreme levels.

SERVICE – There are no user serviceable parts inside this product. Users

should not attempt to service this product. Warranty nulliﬁcation could

result if this is attempted.

RIGGING - SUSPENDING - MOUNTING - Rigging suspending or mounting of

speaker systems can expose members of the public to serious health risks

and even death.

UNDER NO CIRCUMSTANCES ATTEMPT TO RIG, SUSPEND OR

OTHERWISE MOUNT THESE SPEAKERS UNLESS YOU ARE FULLY

QUALIFIED AND CERTIFIED TO DO SO BY RELEVANT LOCAL, STATE

AND NATIONAL AUTHORITIES. ALL RELEVANT SAFETY

REGULATIONS MUST BE FOLLOWED. IF YOU ARE NOT PROPERLY

QUALIFIED OR DO NOT KNOW OF PERTINENT REGULATIONS,

CONSULT QUALIFIED PERSONNEL FOR ADVICE.

K Series

INTRODUCTION

K6000 is a series of 3 premium, high output and superior performance full

range speakers, speciﬁcally engineered for ﬁxed entertainment space

installations.

The LF transducers are a low distortion design using ferrite magnets with a

built-in aluminium ring for optimum heat dissipation. The HF compression

drivers have a 1.75” voice coil and use a polyethylene (pe) diaphragm for

maximum vocal intelligibility in enclosed spaces. This HF compression driver

is coupled to a 70° x 70° waveguide for smooth dispersion regardless of

horizontal or vertical placement.

The cabinet of K6000 series is made of high quality 15mm multi-layer birch

plywood. This plywood is covered with a black, wear-resistant paint

treatment. The cabinet is trapezoidal and is equipped with two Neutrik

speakON nl4mp connectors.

With 13 x M8 threaded suspension points and a further 6 x M8 points in a

100mm conﬁguration, installation at any angle is simple and easy.

The hexagonal hole steel front grille and inner foam lining protects the drive

units from dust or insects. In addition, the iconic Wharfedale Pro logo on the

front grille is rotatable to ensure that K6000 looks great in any orientation.

K6000 - the premium entertainment loudspeaker from Wharfedale Pro.

K SERIES FEATURES

Premium components for premium sound

3” voice coils K6012 / K6015

70° x 70° rounded waveguide

19 x M8 rigging points

Rotatable logo and cosmetic front grille ﬁnish

APPLICATIONS

High-end entertainment sound reinforcement

Club live sound reinforcement

For use with or without a subwoofer

USER MANUAL

DIMENSIONS

K6010

310.0

533.0

335.0

100.0

50.0

157.5

100.0

145.0

335.0

210.0

25.60

K Series

DIMENSIONS

K6012

100.0

140.0

382.0

23.30

350.0

600.0

100.0

50.0

382.0

177.5

USER MANUAL

K6015

DIMENSIONS

100.0

175.0

172.5

430.0

680.0

100.0

50.0

450.0

298.0

24.00

K Series

SPECIFICATIONS

Model Name

System Type

Conﬁguration

Frequency Response (+/-3 dB)

Sensitivity 2.83 v / 1 m

Calculated Maximum SPL @1 m

System Rated Impedance

Low Frequency Transducer

Size (mm / inches)

Voice Coil Size (mm / inches)

LF Magnet Material

LF Frame Material

Rated Impedance

High Frequency Transducer

HF Driver Type

Voice Coil Size (mm / inches)

Diaphragm Material

Nominal Coverage (H x V)

Power

System Continuous Power

System Programme Power

System Peak Power

Crossover frequency

Input Connector

Rigging

Pole mount

Handles

Cabinet type

Enclosure Material and ﬁnish

Colour Options

Grille Material & Finish

Dimensions - Unpacked

Height

Width Front

Width Rear

Depth

Net Weight

K6010

Passive

two-way

65 Hz - 20 kHz

96 dB

127 dB

8 Ω

288 mm / 10''

63.5 mm / 2.5''

Ferrite

Aluminium

8 Ω

Compression Driver

44 mm / 1.75''

Polyethylene

70° x 70°

300 w

600 w

1200 w

2.9 kHz

2 x Neutrik NL4MP

M8 * 19

35 mm pole socket

Trapezoid

15 mm plywood

Black paint

Steel

533 mm

310 mm

210 mm

335 mm

18.9 kg

K6012

Passive

two-way

60 Hz - 20 kHz

97 dB

129 dB

8 Ω

305 mm / 12''

75 mm / 3.0''

Ferrite

Aluminium

8 Ω

Compression Driver

44 mm / 1.75''

Polyethylene

70° x 70°

400 w

800 w

1600 w

3.75 kHz

2 x Neutrik NL4MP

M8 * 19

35 mm pole socket

Trapezoid

15 mm plywood

Black paint

Steel

600 mm

350 mm

242 mm

382 mm

24.3 kg

K6015

Passive

two-way

45 Hz - 20 kHz

98 dB

131 dB

8 Ω

381 mm / 15''

75 mm / 3.0''

Ferrite

Aluminium

8 Ω

Compression Driver

44 mm / 1.75''

Polyethylene

70° x 70°

500 w

1000 w

2000 w

3.2 kHz

2 x Neutrik NL4MP

M8 * 19

35 mm pole socket

Trapezoid

15 mm plywood

Black paint

Steel

680 mm

430 mm

298 mm

450 mm

29.3 kg

WHARFEDALE PRO LIMITED WARRANTY

Wharfedale Pro products are warranted of manufacturing or material defects for a

period of one year from the original date of purchase. In the event of malfunction,

contact your authorized Wharfedale Pro dealer or distributor for information.

*Be aware that warranty details may diﬀer from country to country. Contact your

dealers or distributor for information. These terms do not infringe your statutory

rights.

Wharfedale Professional

IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK

www.wharfedalepro.com

Wharfedale Professional reserves the right to alter or improve speciﬁcations without notice.
