Wharfedale Pro WLA-210XF Manuale utente

before operating them.

and follow a routine for powering up and powering down a sound system. With all system components connected, turn

on source equipment (mixers, signal processors, record and playback units, etc.) BEFORE powering up ampli ers.

Transient voltages from powering up source equipment can damage speakers if ampli ers are already turned on. Make

sure that ampli er volumes are set to their minimum settings and power up any system ampli ers LAST. It is

recommended that all system components be allowed to stabilize for several seconds before any source signals are

introduced or level setting adjustments are made. Similarly, when shutting systems down, turn all ampli ers o rst,

before powering down any other system components.

ers and speakers. Use only

approved speaker cables with proper connectors.

care with placement and operation to avoid exposure to excessive volume levels. Permanent hearing damage can result

when operated to extreme levels.

product. Warranty nulli cation could result if this is attempted.

8. RIGGING - SUSPENDING - MOUNTING - Rigging suspending or mounting of speaker systems can expose

members of the public to serious health risks and even death.

UNDER NO CIRCUMSTANCES ATTEMPT TO RIG, SUSPEND OR OTHERWISE MOUNT THESE SPEAKERS UNLESS YOU

ARE FULLY QUALIFIED AND CERTIFIED TO DO SO BY RELEVANT LOCAL, STATE AND NATIONAL AUTHORITIES. ALL

RELEVANT SAFETY REGULATIONS MUST BE FOLLOWED. IF YOU ARE NOT PROPERLY QUALIFIED OR DO NOT KNOW

OF PERTINENT REGULATIONS, CONSULT QUALIFIED PERSONNEL FOR ADVICE.

WHARFEDALE PROFESSIONAL

IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK

www.wharfedalepro.com

Wharfedale Professional reserves the right to alter or improve speci cations without notice.

IMPORTANT SAFETY INSTRUCTIONS

For your full PDF User manual, please visit

www.wharfedalepro.com

Wharfedale Pro products are warranted of manufacturing or material defects for a period of

three years from the original date of purchase. In the event of malfunction, contact your

authorised Wharfedale Pro dealer or distributor for information.

Please be aware that the warranty details may diﬀer from country to country. Contact your dealer or distributor for

information (available at www.wharfedalepro.com). These terms do not infringe your statutory rights.

OVERVIEW

For your full PDF User manual, please visit www.wharfedalepro.com

WLA-210XF

Wharfedale Pro also manufacture a wide range of power ampliﬁers and signal processors.

For recommended accessories, ampliﬁers and system diagrams please visit www.wharfedalepro.com

May 2022

• Dual 10 ” Passive line array

• IPX6 Waterproof Certiﬁcation

• Wax wrapped components

• Anti-corrosion stainless steel hardware

• Waterproof input connectors

• System Continuous Power LF: 800 W HF: 90 W

• System Programme Power LF: 1600 W HF: 180 W

• System Peak Power LF: 3200 W HF: 360 W

• Impedance 16 Ω

• 15 mm / 18 mm Plywood construction / 3.0 mm Aluminium

SPECIFICATIONS

Model Name

System Type

Conﬁguration

Frequency Response (+/-3 dB)

Frequency Range (-10 dB)

Sensitivity (2.83 v / 1 m)

Calculated Maximum SPL @1 m

System Rated Impedance

Low Frequency Transducer 

Size

Voice Coil Size

Rated Impedance

LF Power (re:AES2-2012)

High Frequency Transducer

HF Driver Type

Voice Coil Size

Exit Size

Diaphragm Material

Rated Impedance

HF Power (re:AES2-2012)

Nominal Coverage (H x V)

Power   

System Continuous Power

System Programme Power

System Peak Power

Input Connector

Hardware

WLA-210XF

Passive IPX6 waterproof

Two-way 2 x 10”

65 Hz - 20 KHz

60 Hz - 20 KHz

102 dB

138 dB

16 Ω

65 mm / 2.5''

2 x 260 mm / 2 x 10''

2 x 400 W

35.6 mm / 1.4”

Compression Driver - Neo

75 mm / 3.0"

Titanium

8 Ω

100°x 10°

LF:800 W HF:90 W

2 x WY-24K4Z (waterproof)

Integral side plate adjustable

rigging 0°-10°

LF:1600 W HF:180 W

LF:3200 W HF:360 W

90 W

2 x 8 Ω

Enclosure Material 15 mm,18 mm Plywood

3.0 mm Aluminium

Width Front

Finish

Grille Material & Finish

Dimensions - (Unpacked)

Height Front / Height Rear

Width Rear

Depth

Dimensions - (Packed)

Height

Width Front

Width Rear

Weight

Depth

845 mm / 33.3"

Waterproof Black Paint

3.0 mm Black Aluminium

333.3 mm / 13.1" 256.3 mm / 10.0"

845 mm / 33.3"

443 mm / 17.4"

953 mm / 37.5"

424 mm / 16.7"

513 mm / 20.2"

Net Weight (kg / lbs)

Gross Weight (kg / lbs)

46.0 kg / 101.2 lbs

50.0 kg / 110.0 lbs

Crossover frequency

Operational Modes:

1.5 KHz

443.0

845.0

333.3

443.0

256.3
