Wharfedale Pro WPM-1 Manuale utente

www.wharfedalepro.com

The WPM-1 from Wharfedale Pro is a personal monitoring solution with a number of great

features that suit performers and artists who demand perfect monitor mixes and total control.

A 5” full range driver is matched to the on-board processing, EQ and amplication to provide

clear, natural and intelligible vocal foldback.

The WPM-1 can be stand mounted with straight or boom mic stands, alternatively the WPM-1

can be placed on the stage itself for maximum versatility. Front panel controls allow you to ne

tune your onstage vocal sound and the integration of your monitor mix. With a WPM-1 you no

longer get the monitor mix that your engineer supplies, you hear exactly what you want to hear.

The balanced microphone input has a through output so your performance can be seamlessly

integrated into the front of house mix. The WPM-1 also includes an instrument/line level input

and mix output, facilitating use as a small format personal mixer with 3 inputs. This versatile

interfacing allows the WPM-1 to t into the widest range of on stage situations.

The WPM-1 uses the same high tech gas assist injection moulding techniques as used in our

famous Titan Series loudspeakers, ensuring road tough reliability and ultra light portability.

WPM-1

Personal Monitoring Solution

Wharfedale Professional

IAG House, Sovereign Court, Ermine Business Park, Huntingdon, Cambs, PE29 6XU, England

www.wharfedalepro.com

● Microphone, line/instrument and auxiliary inputs

● Microphone thru, line and mix outputs

● Vocal volume and EQ controls

● Independent master and auxiliary level controls

● Switchable output sensitivity

● Ultra lightweight gas assist injection moulded enclosure

● Dual angle mic stand receptacles and microphone mounting system

● IEC receptacle for AC supply

Features

WPM-1

Fullrange

120-18kHz

114dB

75W

150W

5"/125mm

Steel

-45dBu (-0dBu / -20 dBu)

0dBu (0dBu / -20 dBu)

Peak +/-15dB @2.1KHz

330mm x 315mm x 285mm

Vented

Black

ABS

8mm

Steel

Black

Yes

Female XLR

Male XLR

Switchable

TRS Jack

Switchable

TRS Jack

Switchable

3.5KG

4.9KG

System Type

Frequency Response @ +/- 3dB

Peak SPL

Power Handling

Continuous

Music

Driver

Driver Size

Frame Material

Input Sensitivity

Mic input

Line and Aux input

Mic EQ

Enclosure

Dimensions (LxWxH)

Enclosure Type

Colour

Enclosure material

Thickness

Grille Material

Grille Colour

Microphone Stand Mounting

Bottom Receptacle

Boom Arm Mount Receptacle

Rubber Base

Input/Output Panel

Microphone Input

Microphone Output

Mic / Line Level

Line / Instrument Input

Line / Instrument Output

Line / Instrument Level

Aux Input

Mix Output

Mix Output Pre / Post

Weight

Net

Gross Weight

Specifications

WPM-1

Personal Monitoring Solution
