Wildgame Innovations Terra 8 Manuale utente
Infrared Digital Scouting Camera
User’s Manual Model # TR8i1-7
Camera Unit 2 - Bungee Cords
User Manual
page 1
Includes
RESOLUTION
FLASH
FLASH RANGE
SENSOR
SENSOR RANGE
IMAGE FORMAT
MEMORY
IMAGE RESOLUTION
POWER SUPPLY
BATTERY LIFE
HOUSING
MOUNTING
MAX: 8 MP
21 pc High Intensity Infrared LED’s
up to 60 feet
Passive Infrared Sensor (PIR) Motion and Heat
up to 60 feet
JPEG - Digital Stills/ AVI-Digital Video
up to 32GB SD Card (not included and required)
Class 4 and above recommended
8 MP
8 AA batteries (not included and required)
Alkaline recommended
Estimated up to 1 year or 30,000 photos
Weather resistant with rubber gaskets
2 Bungee cords - included
page 2
Features
Installing Batteries
1. Open the door at the bottom of the
camera by unlatching the locking
tab.
2. With the camera facing open, open
the battery compartment cover by
sliding the latch to the left.
page 3
3. With the bottom of the camera to-
wards you, Make sure to insert the
batteries into the camera with the
positive ends towards you where
marked positive and the negative
ends towards you where marked
negative.
NOTE:
Do not mix old and new batteries. Do
not mix alkaline, standard (carbon-
zinc) or rechargable (ni-cad, ni-mh,
etc) batteries.
page 4
4. Close battery compartment cover.
To latch the cover simply pull the
latch slightly to the left as you close
the battery compartment cover.
IMPORTANT:
Make sure the camera is powered off
before removing or installing an SD card.
If you are using an SD card from other
cameras, please make sure to format the
SD card in your computer prior to use in
your camera. New cards are ok to use
straight from the package.
5. Load SD memory card (up to 32GB
not included) into the SD card slot
with the connectors facing up.
page 4
4. Close battery compartment cover.
To latch the cover simply pull the
latch slightly to the left as you close
the battery compartment cover.
IMPORTANT:
Make sure the camera is powered off
before removing or installing an SD card.
If you are using an SD card from other
cameras, please make sure to format the
SD card in your computer prior to use in
your camera. New cards are ok to use
straight from the package.
5. Load SD memory card (up to 32GB
not included) into the SD card slot
with the connectors facing up.
page 5
1. To turn the unit ON press and re-
lease the power button.
2. Check the battery level icon
to ensure the batteries just
installed contain the proper
charge level. If so, you are ok to
proceed with camera use.
Time/Date
Still Video
AM
Photos
Power On Test Mode
1. LCD Ready Mode: The camera will
automatically enter Ready Mode if a
button is not pressed for greater than
30 seconds.
2. LED Status Light: During the first
30 seconds of the LCD Ready Mode,
the red light will illuminate when a
PIR event is triggered. After the LCD
turns off, the red light will blink 2-3
seconds when photo is taken. After
2 minutes, all indicator lights will
turn off until a button is pressed.
page 5
1. To turn the unit ON press and re-
lease the power button.
2. Check the battery level icon
to ensure the batteries just
installed contain the proper
charge level. If so, you are ok to
proceed with camera use.
Time/Date
Still Video
AM
Photos
Power On Test Mode
1. LCD Ready Mode: The camera will
automatically enter Ready Mode if a
button is not pressed for greater than
30 seconds.
2. LED Status Light: During the first
30 seconds of the LCD Ready Mode,
the red light will illuminate when a
PIR event is triggered. After the LCD
turns off, the red light will blink 2-3
seconds when photo is taken. After
2 minutes, all indicator lights will
turn off until a button is pressed.
page 6
1. To change date and time, start by
pressing and releasing the enter
navigation button to set the hour.
2.Press the + or - navigation button
to go up or down in sequence.
3.When the hour is set, repeat
steps 1 and 2 to set the minutes.
Time/Date
Still Video
AM
Photos
Time/Date
Still Video
AM
Photos
Power Save Setting Time
1. After 30 seconds without any buttons
being pushed, the LCD will turn off
and camera enters into Power Save
or Ready Mode.
2.The LCD screen can be awakened by
pressing the Power button briefly.
Note: The LCD will not “wake up”
when camera is writing to memory.
page 6
1. To change date and time, start by
pressing and releasing the enter
navigation button to set the hour.
2.Press the + or - navigation button
to go up or down in sequence.
3.When the hour is set, repeat
steps 1 and 2 to set the minutes.
Time/Date
Still Video
AM
Photos
Time/Date
Still Video
AM
Photos
Power Save Setting Time
1. After 30 seconds without any buttons
being pushed, the LCD will turn off
and camera enters into Power Save
or Ready Mode.
2.The LCD screen can be awakened by
pressing the Power button briefly.
Note: The LCD will not “wake up”
when camera is writing to memory.
