Winmate IA70 Manuale utente

IA70 Motherboard

Mini-ITX Fan SBC w/ Intel®ATOM

N270 1.6GHz Processor, VGA, LCD,

Giga Ethernet, Mini-PCI and PCI Slot

Interface.

USER MANUAL Version 1.0

IA70 Motherboard User Manual

FCC Statement

This device complies with part 15 FCC rules. Operation is subject to

the following two conditions ：

This device may not cause harmful interference.

This device must accept any interference received including

interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a class "a"

digital device, pursuant to part 15 of the FCC rules. These limits are designed to

provide reasonable protection against harmful int erference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio c ommunications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at hi m

own expense.

IA70 Motherboard User Manual

III

translated, or transmitted in any form or by any means, electronic or mechanical, for

any purpose, without the prior written permission of the original manufacturer.

Trademark Acknowledgement

Brand and product names are tradem arks or registered trademarks of their respective

owners.

Disclaimer

We reserve the right to make changes, without notice, to any product, including

circuits and/or software described or contained in this manual in order to improve

design and/or performan ce. We assume no responsibility or liability for the use of the

described product(s), conveys no license or title under any patent, copyright, or masks

work rights to these products, and makes no representations or warranties that these

products are free from patent, copyright, or mask work right infringement, unless

otherwise specified. Applications that are described in this manual are for illustration

purposes only. We make no representation or warranty that such application will be

suitable for the specified use without further testing or modification.

Warranty

We warrant that each of its products will be free from material and workmanship

defects for a period of one year from the invoice date . If the customer discovers a

defect, We will, at its option, repair or replace the defective product at no charge to

the customer, provided it is returned during the warranty period of one year, with

transportation charges prepaid. The returned product must be properly packaged in its

original packaging to obtain warranty service.

If the serial number and the product shipping data differ by over 30 days, the

in-warranty service will be made according to the shipping date. In the serial numbers

the third and fourth two digits give the year of manufacture, and the f ifth digit means

the month (e. g., with A for October, B for November and C for December).

For example, the serial number 1W07Axxxxxxxx means October of year 2007.

IA70 Motherboard User Manual

Packing List

Before using this Motherboard, please make sure that all the items listed bel ow are

present in your package ：

IA70 Motherboard

IA70 SBC User Manual

HDD IDE Cable

User’s Manual & Driver CD

If any of these items are missing or damaged, contact your distributor or sales

representative immediately.

Customer Service

We provide service guide for any problem as follo w steps：First, visit the website at to

find the update information about the product. Second, contact with your distributor,

sales representative, or our customer service center for technical support if you need

additional assistance. You may have the foll owing information ready before you call ：

Product serial number

Peripheral attachments

Software (OS, version, application software, etc.)

Description of complete problem

The exact wording of any error messages

In addition, free technical support is availab le from our engineers every business day.

We are always ready to give advice on application requirements or specific

information on the installation and operation of any of our products. Please do not

hesitate to call or e-mail us.

IA70 Motherboard User Manual

Safety Precautions

Warning!

Always completely disconnect the power cord from your chassis

whenever you work with the hardware. Do not make connections

while the power is on. Sensitive electronic components can be

damaged by sudden power surges. Only experienced electronic

personnel should open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution, use a

grounding wrist strap at all times. Place all electronic components

in a static-dissipative surface or static -shielded bag when they are

not in the chassis.

IA70 Motherboard User Manual

Safety and Warranty

1. Please read these safety instructions carefully.

2. Please keep this user's manual for later reference.

3. Please disconnect this equipment from any AC outlet before cleaning. Do not use

liquid or spray detergents for cleaning. Use a damp cloth.

4. For pluggable equipment, the power outlet must be installed near the equipment

and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting

it fall could cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment from

overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything

over the power cord.

10. All cautions and warnings on the equip ment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source

to avoid damage by transient over -voltage.

12. Never pour any liquid into an opening. This could cause fire or electrical shock.

13. Never open the equipment. F or safety reasons, only qualified service personnel

should open the equipment.

14. If any of the following situations arises, get the equipment checked by service

personnel:

A. The power cord or plug is damaged.

B. Liquid has penetrated into the equipment.

C. The equipment has been exposed to moisture.

D. The equipment does not work well, or you cannot get it to work according to

the user’s manual.

E. The equipment has been dropped and damaged.

F. The equipment has obvious signs of breakage.

15. Do not leave this equipment in an unc ontrolled environment where the storage

temperature is below -20° C (-4°F) or above 60° C (140° F). It may damage the

equipment.

IA70 Motherboard User Manual

VII

Revision History

Version

Date

Note

Author

0.8

2008.12.04

Initial Draft

Aladin Huang

1.0

2008.12.23

First Version

Aladin Huang

IA70 Motherboard User Manual

VIII

Contents

CHAPTER 1 GENERAL INFORMATION ................................ .....1

1.1 INTRODUCTION ................................................................ ............ 1

1.2 FEATURE ................................................................ ..................... 1

1.3 MOTHERBOARD SPECIFICATIONS.................................................. 2

1.4 FUNCTION BLOCK ................................ ................................ ....... 3

1.5 BOARD DIMENSIONS .................................................................... 4

CHAPTER 2 INSTALLATIONS ................................ ...................... 6

2.1 MEMORY MODULE（DIMM）INSTALLATION .............................. 6

2.2 I/O EQUIPMENT INSTALLATION .................................................... 7

2.3 JUMPERS AND CONNECTORS ........................................................ 9

2.4 JUMPER SETTING ................................................................ ....... 10

2.5 CONNECTORS AND PIN ASSIGNMENT .......................................... 13

CHAPTER 3 GRAPHIC DRIVER INSTA LLATION ...................22

3.1 STANDARD CMOS FEATURE....................................................... 22

3.2 PANEL RESOLUTION SETTING ..................................................... 26

CHAPTER 4 CHIPSET DRIVER INSTA LLATION .................... 29

4.1 STANDARD CMOS FEATURES ..................................................... 29

CHAPTER 5 ETHERNET DRIVER INSTALLATION ................. 34

5.1 INTRODUCTION ................................................................ .......... 34

5.1 INSTALLATION OF ETHERNET DRIVER......................................... 35

CHAPTER 6 AUDIO DRIVER INSTALLATION ........................ 39

6.1 INTRODUCTION ................................................................ .......... 39

6.2 INSTALLATION OF AUDIO DRIVER............................................... 39

CHAPTER 7 AMI BIOS SETUP .................................................... 42

7.1 STARTING SETUP ....................................................................... 42

7.2 SYSTEM OVERVIEW ................................................................... 43

7.3 ADVANCED SETTING ................................................................. 44

NOTE1: DIGITAL I/O SAMPLE CODE ................................ ...........76

IA70 Motherboard User Manual

General Information

This chapter includes IA70 Motherboard background

information.

Sections include:

Introduction

Feature

Motherboard Specification

Function Block

Board Dimensions

C H A P T E R

IA70 Motherboard User Manual

Chapter 1 General Information

1.1 Introduction

IA70 SBC is equipped with Intel 945GSE North Bridge and Intel ICH7M South

Bridge which are designed for use with Intel’s mobile platform . Intel’s 945GSE

platform delivers the performance and high scalability cutting -edge embedded

computing application.

In peripheral connectivity, IA70 SBC with one PCI slot, one PCI-E(x1) and

Mini-PCI I/O ports, two SATA connectors, and eight Hi-Speed USB connectors.

Thus, IA70 SBC is designed to satisfy most of the applications in the industrial

computer market, such as Gaming, POS, KIOSK, Industrial Automation, and

Programmable Control System . It is a compact desig n to meet the demanding

performance requirements of today’s business and industrial applications.

1.2 Feature

Mini-ITX Form Factor ( 170mm x 170mm)

Supports Intel® Atom N270 1.6GHz processors

System memory up to 2 GB DDR2 400/533, 1xDIMM

Integrated Intel 945GSE + ICH7M Chipset

Intel® GMA950 graphic engine Integrated 224 MB shared supports VGA

Dual Gigabit Ethernet ( Dual Fast Ethernet optional)

1 x PCI slot, 1 x PCIE(x1), 1 x Mini PCI, 4 x COM, 8 x USB2.0, 1 x

CF(Optional)

2 x SATA,
