X-Vision X2C4000 Manuale utente

Professional HD IP Camera

User Guide

Version 1

Thank you purchasing the X2C4000 HD IP Camera from Xvision Pro HD.

Please ensure that you read and understand this User Guide before operating the camera.

Please store this User Guide in an easily accessible location.

PRO

XHD

X2C4000 IPC Manual

Table of Contents

Table of Contents................................................................................................................................................ 1

Functional Descriptions and Features............................................................................................................. 3

SAFETY INSTRUCTION................................................................................................................................... 1

Introduction.......................................................................................................................................................... 2

Pre-requisites ...................................................................................................................................................... 2

IPC Description and Device Connection......................................................................................................... 3

Appearance Description................................................................................................................................. 3

Device Connection........................................................................................................................................ 10

Device Search Tool.......................................................................................................................................... 11

Active X Setup................................................................................................................................................... 14

Web Browser Interface..................................................................................................................................... 16

Live View........................................................................................................................................................ 16

Remote Setting.............................................................................................................................................. 18

Display............................................................................................................................................................ 18

Live.............................................................................................................................................................. 18

Image Control............................................................................................................................................ 19

Privacy Zone.............................................................................................................................................. 20

ROI.............................................................................................................................................................. 21

Record............................................................................................................................................................ 22

Rec Parameters........................................................................................................................................ 22

Schedule .................................................................................................................................................... 23

Network .......................................................................................................................................................... 24

Network Setting......................................................................................................................................... 24

Video Streaming........................................................................................................................................ 25

Email........................................................................................................................................................... 26

DDNS.......................................................................................................................................................... 27

IP Filter....................................................................................................................................................... 28

RTSP .......................................................................................................................................................... 29

FTP.............................................................................................................................................................. 30

Alarm............................................................................................................................................................... 31

Motion......................................................................................................................................................... 31

Alarm........................................................................................................................................................... 32

Lens Shade................................................................................................................................................ 33

Device............................................................................................................................................................. 34

SD Card...................................................................................................................................................... 34

Log .............................................................................................................................................................. 35

Audio........................................................................................................................................................... 36

X2C4000 IPC Manual

System............................................................................................................................................................ 37

Date/Time................................................................................................................................................... 37

Users........................................................................................................................................................... 38

Info .............................................................................................................................................................. 39

Advanced....................................................................................................................................................... 40

Firmware Update....................................................................................................................................... 40

Load Default .............................................................................................................................................. 41

Maintain...................................................................................................................................................... 42

PEA (Perimeter Alarm) .......................................................................................................................... 43

OSC –Object Care.................................................................................................................................... 46

X2C4000 Specification’s.................................................................................................................................. 49

FAQ..................................................................................................................................................................... 55

X2C4000 IPC Manual

Functional Descriptions and Features

Features

Brief Description

Real time

monitoring

Optimized H.265/H.264/MJPEG video compression algorithms; Multi-

stream transmission ensures high definition image transmission on both

narrowband and wideband.

Recording

Support simultaneous connection of up to 5 video streams.

Onvif

Support ONVIF protocol, please check with www.xvision.com for latest

supported version.

Network

protocols

Support multiple network protocols, such as TCP/UDP

,IP,HTTP,DHCP,RTP,RTSP,FTP,SMTP,DNS,DDNS,NTP,ICMP,IGMP

,ARP, GB28181

Record backup

Backup via Browser and some IPC support MSD card.

POE

POE Power over Ethernet support on all IPC - 12 VDC ± 10%, PoE

Network

operation

Authorized accessing of remote client to ensure the system security.

APP Support

Smart phone video monitoring XIQCMS

Operating

Temperature/IP

Rating

-10 °C ~ 60 °C(14 °F ~ 140 °F –IP66 - below 90%RH

Note：

•IPC refers to Internet Protocol Camera.

•Default IP address of IP Camera：192.168.1.168

•IP Camera default Username: admin (lower case）, Password:

admin (lower case）

•Default web port：80，Default media port：9988

•LAN refers to Local Area Network (Inside your router)

•WAN refers to Wide Area Network (outside your

Router/Home/Office)

SAFETY INSTRUCTION

Do not install the equipment in an environment with too much

moisture, dust or smoke dust as this may result in fire or electric

shock.

In the unlikely event that the equipment should malfunction and emit

an abnormal smell of smoke, please immediately stop it, shut off the

power and contact your supplier.

Please do not place this equipment near a heat source to avoid risk of

fire.

Please do not store, install and use this product in danger areas with

inflammable or explosive substances.

Please make sure the power is turned off when installing the product.

Please do not use the IPC in an environment where temperatures that

exceed either -20°C to +55°C.

Introduction

This guide is for the Xvision Pro HD X2C4000 Range of IP Cameras.

It is recommended that the units are setup and tested before being mounted or installed.

These instructions are for guidance only detailed information is in accordance with the

product.

The instructions may include some technical inaccuracies or typographical errors, these

will be corrected in future updates.

The product or procedures described in the instructions may be changed or updated at

any time without prior notice. Screenshots used in the instruction are only for indications

and explanations.

Screenshots used in the instruction are only for indications and explanations.

This Manual will cover the following:

•Schematic Diagram of XC Cameras

•Basic setting setup

•Setting an IP address

•Active X Controls

•Viewing on IE

•Specifications

Pre-requisites

Note before you begin installation:

•Connect only one X2C400 range IPC at a time to your LAN, as all

cameras share the same defaultIP 192.168.1.168

•Screw Drivers

•Router/Switch/Hub for your LAN, this is needed to connect all Network IP

equipment together.

•A Windows PC/Laptop on site connected to the same LAN

(Router/Switch) as your equipment.

•Cat 5 Patch cables to connect your X2C4000 and Router/Switch all

together

IPC Description and Device Connection

Appearance Description

The X2C4000 cameras can be wall or ceiling mounted, so to install the camera you will need

to adjust it to the desired angle. Belowyou will see how to install each camera type

Schematic Diagram（X2C4000BP）

Items

Descriptions

①Front cover

Helps protect the IPC from sunlight and rain.

②Rear cover

Fixed with the front cover.

③Set screw

Secure the front cover and rear cover.

④Lens

Lens of IPC

⑤Infrared IR’s

Infrared IR’s behind glass cover

⑥Ball and sleeve

Rotatable, used to adjust the angle of view of the IPC.

⑦Locknut

Fix the ball sleeve and the base.

⑧Base

Base to be secured against wall.

⑨Fixing hole

Screw holes to secure IPC to wall.

Schematic Diagram（X2C4000BVP）

Items

Descriptions

① Front cover

Helps protect the IPC from sunlight and rain.

② Rear cover

Fixed with the front cover.

③Focusing lever

Adjust the focal length of the IPC.

④Lens

Lens of IPC

⑤ Infrared IR’s

Infrared IR’s behind glass cover

⑥ Ball and sleeve

Rotatable, used to adjust the angle of view of the IPC.

⑦ Locknut

Fix the ball sleeve and the base.

⑧Base

Base to be secured against wall.

⑨ Fixing hole

Screw holes to secure IPC to wall.

Schematic Diagram（X2C4000VAP）

①②③④

⑤

Items

Descriptions

① Transparent cover

Protects the IPC lens and IR’s.

② Infrared IR’s

Infrared IR LED’s

③ Lens

Lens of IPC

④ Black inner cover

Hides IPC mechanics.

⑤ Adapter disc

This will connect to the additional bracket.

Schematic Diagram（X2C4000VP）

①

②③

④

⑤

⑥

Items

Descriptions

① Lens

Lens of IPC

② Infrared lamp

Infrared LED lamp

③ Main housing

Rotatable and used to adjust the installation angle

④ Fixed guard

Secure the position of the Main housing.

⑤ Base

Secures the IPC to the wall.

⑥ Fixing hole

Secure with screws at the installation location.
