Xerox WorkCentre Pro 255 Manuale utente

Page 1

Microsoft Windows (NetBEUI) Peer-to-Peer Networks Quick Install Card

Xerox Document Centre 240/255/265 LP/ST

b) On the keypad enter 1111 or the

current password. Press the Enter

button when finished. If your printer is

an ST model press the Go to Tools

button, otherwise skip to the next step.

c) The Touch Screen will be used for the

remainder of the data entry.

3. Enable Microsoft Network printing.

a) Press the Connectivity and Network

Setup button.

b) At the next screen, press the Network

Setup button.

4. Enable the Protocol and Media.

a) At the next screen, press the

Microsoft Networking button.

b) At the next screen, press the

Transport and Media button.

c) At the next screen, press the Enable

button to enable the Microsoft Network

protocols.

d) Once enabled the Physical Media

portion of the screen will appear. Press

the corresponding button to select one

of the following NetBEUI or Ethernet,

NetBEUI/Token Ring. After making

your selection press Save.

5. Assign the Workgroup and Host Names

a) You will be returned to the previous

screen, press the Workgroup and

Host button.

b) At the next screen, press the

Workgroup Name button. Using the

Touch Screen keys, enter the name of

the workgroup in which you want the

printer to appear then press Save.

c) You will be returned to the previous

screen. Press the SMB Host Name

button. Using the touch panel keys,

enter the desired text for this item then

press Save.

d) OPTIONAL STEP: Press the SMB

Host Description button, enter the

desired text then press Save. You will

be returned to the previous screen.

e) Press Save again to return to the

previous screen.

6. Assign a Printer Name and Description

a) Press the Printer Description button.

b) Press the Printer Name button, using

the touch panel keys, enter the

desired text for this item then press

Save. Press Save again to return to

the previous screen.

Before You Start

If your printer is equipped with a Token Ring

interface, use the Token Ring Quick Install

Card supplied in this Quick Install Card set to

set the Ring Speed and Source Routing settings

for your environment.

Record the following information:

Network Interface Type ___________________

Workgroup Name _______________________

SMB Host Name ________________________

Printer Name ___________________________

OPTIONAL INFORMATION:

SMB Host Description ____________________

Printer Description _______________________

Go to the printer and...

1. Connect your Document Centre to the net-

work with the appropriate cabling.

2. Enter the Tools pathway

a) Press the Access () button.

For assistance, contact your local Xerox Customer Support Center:

USA: 1-800-821-2797 Canada: 1-800-939-3769

Page 2

Microsoft Windows (NetBEUI) Peer-to-Peer Networks Quick Install Card

Xerox Document Centre 240/255/265 LP/ST

next section of this procedure called Go to

the workstations and.

Go to the workstations and...

11. Verify that the NetBEUI protocol is loaded

(ALL Windows 3.11 or greater versions).

12. Use the CentreWare Network Services

CD-ROM (CD-ROM 2) to install print

drivers on a Windows-based workstation.

Details for this are found in the document

supplied with your printer entitled Getting

Started with Print and Fax Services.

13. On the Configuration Report review the

NetBIOS: area and note the Workgroup,

Host Name, and Printer Name.

Windows for Workgroups Users

•Open the Control Panel and double-click

the Printers icon.

•Select the printer driver you just installed

and click Connect.

•Select an available port and click Network.

•Double-click the name of the WorkGroup for

the printer.

•Double-click the Host Name of the printer.

•Click once on the Printer Name then click

OK.

Windows 95, Windows 98 and Windows

NT 4.X Workstation Users

•Click the Start button and select Settings.

•From the cascade menu select Printers.

•Select a printer with the right mouse button.

•Select the Properties entry in the cascade

menu.

•Select the Details tab on the Properties

dialog.

•Click the Add Port button and browse to the

Workgroup.

•Double-click the name of the WorkGroup for

the printer as shown on the Configuration

Report.

•Double-click the Host Name of the printer as

shown on the Configuration Report.

•Click once on the Printer Name then click

OK.

14. Open an application and print a test page

to verify operation.

15. If your print job does not print, refer to the

Troubleshooting section of the Network

Installation and Troubleshooting Guide

to solve the problem.

c) OPTIONAL STEP: Press the Printer

Description button, using the Touch

Screen keys, enter the desired text for

this item then press Save.

d) Press the Connections button.

7. Set Maximum Connections and Timeout

a) Touch the Maximum Connections

soft button on the touch screen and on

the keypad enter the desired

maximum connection number

between 1 and 30. It is recommended

that this value should be set at the

default.

b) Touch the Connection Timeout soft

button on the Touch Screen. On the

keypad enter the desired number of

second between 0 and 9999. Press

Save to exit the Connections Screen.

c) Press the Exit Tools button.

8. Wait a MINIMUM of 7 minutes for the

printer to reset.

9. Obtain a Configuration Report from the

printer to use in the remainder of the

installation.

10. Fromthedocumentationpackagesupplied

with your printer, retrieve the CentreWare

Network Services CD-ROM and the

document entitled Getting Started with

Print and Fax Services. Proceed to the
