Xiaomi Mi phone Manuale utente
This version is for private use only and should not be distributed.
Mi Bluetooth Speaker
This version is for private use only and should not be distributed.
01
Controls
3.5mm audio input
Microphone
Charging port
Volume up
Long press: Next song
Volume down
Long press: Previous song
Baery level
Long press: Bluetooth search
Play/Pause
Answer/End phone call
| Connect
Speaker
1
Connect new mobile device
More
Mobile devices
2
Turn on Bluetooth on your mobile device and choose Mi Bluetooth Speaker. Aer the
speaker is connected, you will hear a notification sound and LED light will turn blue.
Turn on Bluetooth on your mobile device next time, and the speaker will connect
automatically.
Long press for 2 seconds to make the speaker's Bluetooth visible. Then connect
the speaker from a new device.
Press for 2 seconds untill you hear a
notification sound. The speaker will turn on
Bluetooth automatically.
This version is for private use only and should not be distributed.
02
| Features
More
Charging
*Audio will be played via Bluetooth if
connection is established.
Bluetooth speaker
Wired speaker
Phone
Connect your speaker via 3.5mm
cable to play music.
Connect via Bluetooth to control
the speaker from your phone.
LED light is red when the speaker is charging. It will go out when the baery is
fully charged.
When connected via Bluetooth, the
speaker will pause the music and play a
ringtone for incoming calls. Press to
answer/end calls.
This version is for private use only and should not be distributed.
03
Maximum output
Speaker
Microphone
Frequency range
Baery
Charge time
USB power input
Product dimensions
Operating temperature range
2.5W x 2 ( 4ohms, THD<0.1% )
Φ36mm, Driver X 2
4.0
Hands Free Microphone × 1
85Hz-20KHz
1500mAh 3.8V
2.5h
168 X 58 X 24.5 mm
0°C-45°C
| Product specifications
Bluetooth
| Warranty & Support
Model: MDZ-26-DB Xiaomi Inc.
All rights reserved by Xiaomi Inc.
By using Mi Bluetooth Speaker you agree to be bound by the terms
and conditions set forth at hp://www.mi.com/en/agreement, which
including but not limited to the Xiaomi user agreement, collectively,
the “Agreements”. . By using Mi Bluetooth Speaker you agree to be
bound by the terms and conditions of the Agreements.
5V 2A
