QUICK GUIDE
II
Copyright
This manual is designed for PS701 Pro Intelligent
Diagnosis System and only applies to it. Any company
or person can’t copy and backup this introduction book
in any form (Electronic, mechanical, photocopy,
record, or other forms) without the written permission
of Xtool. This introduction book is via the product’s
existing configuration and function to compile, if the
product adds a new configuration and function, this
introduction book will be changed accordingly,
without prior notice. The right of final interpretation of
this introduction book belongs to Xtool.
QUICK GUIDE
IV
Disclaimer
This electronic control system diagnostic unit is
provided for vehicle repairing professionals, this
product has higher reliability, but does not exclude the
loss and damage caused by customers’ technical
matters, vehicle problems, or other reasons, Xtool
assumes no liability or responsibility for those.
To know more about related products information, you
can visit Shenzhen Xtooltech Intelligent Co., Ltd’s
official website：http://www.xtooltech.com
Safety instruction
Keep ventilation：When the engine is
running, please keep the repair zone good
ventilation or connect the exhaust system
of the engine and building carefully.
QUICK GUIDE
V
Caution
⚫Always keep safe conditions to diagnosing vehicle
⚫Wear the goggles in accord with ANSI standard
⚫Keep clothes, hair hand, tool, tester, etc. away
from running or calorific engine
⚫Before starting the engine, you should confirm
parking braking is working, put a barrier on the
front wheels, and put the gear shift lever in neutral
gear or park to avoid hurting people on the spot
when start engine, the vehicle speeds up suddenly
⚫Be extremely careful when working around the
ignition coil, distributor cap, ignition circuit, and
ignition plug. The voltage generated by these
components when the engine is running is very
dangerous
⚫Equipped with special fire extinguishers for
QUICK GUIDE
VI
gasoline, chemical, electrical fires in the working
area
⚫When the ignition switch is turned on or the
engine is running, don’t connect or disconnect the
diagnostic equipment
⚫Keep the diagnostic device dry and clean, away
from gasoline, water, and grease. If necessary, use
a clean cloth coated with a mild detergent to clean
the surface of the device
⚫Don’t operate the diagnostic equipment while
driving the vehicle to avoid distractions and cause
accidents
⚫Please refer to the repair manual when servicing
the vehicle and strictly follow the diagnostic
procedures and precautions. Otherwise, it may
cause personal injury or damage to the diagnostic
device
QUICK GUIDE
VII
⚫To avoid damaging the diagnostic device or
generating incorrect data, please ensure that the
vehicle battery is sufficiently charged and the
connection of the vehicle diagnostic socket is
clean and safe
⚫Don’t put the diagnostic device on the vehicle
distributor. Strong electromagnetic interference
will cause damage to the device
Aftersales-services
support1@xtooltech.com
support2@xtooltech.com
+86 755 21670995 / +86 755 86267858
Monday through Friday
09:00~18:30 [UTC/GMT+08:00]
www.xtooltech.com
QUICK GUIDE
i
Content
Product Brief Page 1
In this part, you can know about the basic features of the product
Product Specification Page 2
In this part, you can know about the specification of the product
Start Diagnosis Page 10
In this part, you can know about the functions of the product
FAQs Page 43
In this part, provide answers to frequently questions during
using
QUICK GUIDE
1
1. Product Brief
PS701 Pro intelligent diagnosis system is a
professional vehicle diagnosis device for Japanese
automobiles. It supports the detection and bi-
directional control test for vehicle drive, chassis, and
body systems. It has basic diagnostic functions such as
reading fault code, clearing fault code, reading live
data, freezing frame, etc. At the same time, the user
could experience the complete OBD Ⅱ function and
full system diagnosis. It can help maintenance staff
locate faults for vehicles and improve work efficiency.
QUICK GUIDE
2
2. Product Specification
2.1. Appearance
PS701 Pro series Intelligent Diagnosis System.
Front view
Back view
