Yolink YS5002-UC Manuale operativo
Smart Motorized
Valve
SET
Installation & User Guide
YS5002-UC
Revision Dec. 16, 2022
. Welcome!
. Before You Begin
. In the Box
. Required Items
. Get to Know Your Smart Motorized Valve
. Install the App
. Add Your Valve to the App
. Installation
. About Control-D2D
. Using the App & 3rd-Party Services
. Battery Replacement
. Factory Reset
. Firmware Update
. Troubleshooting
. Warnings
. Warranty
. FCC Statement
. Contact Us
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
01
01
03
03
04
05
06
08
10
12
13
14
15
16
17
18
19
21
Contents
01
Or by scanning the QR code:
Welcome!
Before You Begin
Visit our Smart Motorized Valve support page on
our website, for the latest installation guides,
additional resources, information and videos by
visiting:
www.shop.yosmart.com/pages/smart-
motorized-valve-product-support
Thank you for purchasing YoLink products! We
appreciate you trusting YoLink for your smart
home & automation needs. Your 100% satisfac-
tion is our goal. If you experience any problems
with your installation, with our products or if you
have any questions that this manual does not
answer, please contact us right away. See the
Contact Us section for more info.
Thank you!
Eric Vanzo
Customer Experience Manager
A
B
02
Download the most current version of the user
guide by scanning the QR code:
NOTE:
These instructions are not intended to be inclu-
sive of all possible pipe and fitting types, nor are
they intended to be comprehensive instructions
for inexperienced installers. If you are not com-
fortable with an installation like this, please
consult or hire a qualified plumber. Instructions
in this guide are based on a new installation, on
copper pipe, with push-fit threaded adapters.
The Smart Motorized Valve can be installed on
CPVC or PEX pipe using the appropriate male
NPT thread to compression or push-fit copper,
CPVC or PEX adapters. YoLink recommends
SharkBite brand fittings. Visit sharkbite.com or
find additional information on our Smart Motor-
ized Valve Support page.
Local plumbing/building codes may require a
standard non-electric or non-motorized valve for
the main water shut-off - do not replace a
non-electric shut-off valve with this motorized
valve without first consulting with the applicable
code authorities. If installing this valve to shut
off the main water line, we suggest installing this
adjacent to the (non-electric) shut-off valve.
Please use care when working with cutting and
other tools than can cause bodily harm if not
used properly!
03
Model:YS5002-UC
Battery: AA x 2
FCC ID: 2ATM75002
Made in China
Motorized Valve
O
S
PULL UP BEFORE
MANUALLY OPEN/SHUT
SET
Smart Motorized Valve Batteries (Installed)
In the Box
C
Locking Pliers
Pipe Wrench Copper Pipe
Cutting Tool
SandpaperThread Seal Tape
Pipe Fittings
/Adapters
These tools or items may be required:
Required Items
D
04
LED Behaviors
SET
The YoLink Smart Motorized Valve is a motor-
ized valve with an integrated YoLink valve con-
troller. To get to know your new Smart Motorized
Valve, refer to the illustrations below.
Manual Control Knob
Lift, then turn either clockwise to
shut the valve or counterclock-
wise to open the valve
SET Button
Multifunction button
LED Indicator
See “LED Behaviors” below
Valve Position Indicator
Window indicates the current
position of the valve. “O”
indicates open, “S” indicates
shut.
Blinking Red Once,
Then Green Once
Device start-up
Blinking Red And Green
Alternately
Restoring to factory
defaults
Blinking Red Once
Valve closing
Quick Blinking Red
Twice
Valve is closed
Blinking Green Once
Valve opening
Quick Blinking Green
Twice
Valve is open
Slow Blinking Green
Twice
Connecting to hub
Quick Blinking Green
Pairing
Quick Blinking Red
Unpairing
Slow Blinking Green
Updating
Fast Blinking Red Every
30 Seconds
Low battery, replace
batteries soon
Get to Know Your Smart
Motorized Valve
E
05
Open the app and tap Sign up for an account.
You will be required to provide a username and a
password. Follow the instructions, to set up a
new account. Allow notifications, when prompt-
ed.
You will immediately receive a welcome email
information. Please mark the yosmart.com
domain as safe, to ensure you receive important
messages in the future.
Log in to the app using your new username and
password.
The app opens to the Favorite screen. This is
where your favorite devices and scenes will be
shown. You can organize your devices by room,
in the Rooms screen, later.
If you are new to YoLink, please install the app
on your phone or tablet, if you have not already.
Otherwise, please proceed to the next section.
Scan the appropriate QR code below or find the
“YoLink app” on the appropriate app store.
Apple phone/tablet
iOS 9.0 or higher
Android phone/tablet
4.4 or higher
Install the App
F
06
1. Tap Add Device (if shown) or tap the scanner
icon:
Scanner icon
2. Approve access to your phone’s camera, if
requested. A viewfinder will be shown on the
app.
3. Hold the phone over the QR code so that the
code appears in the viewfinder. If successful, the
Add Device screen will be displayed.
Model:YS5002-UC
Battery: AA x 2
FCC ID: 2ATM75002
Made in China
Motorized Valve
O
S
PULL UP BEFORE
MANUALLY OPEN/SHUT
SET
Add Your Valve to the App
G
07
You can change the device name and assign it to
a room later. Tap Bind device.
If successful, the screen will appear as shown.
Tap Done.
4. If the Smart Motorized Valve is not already
on, press the SET button for a moment, until the
LED illuminates briefly.
08
1. Shut-off the water serving the pipe where the
valve is to be installed. Drain the water from the
pipe, by turning on a faucet, or by other method
as required.
2. Depending on the adapter fitting used, mea-
sure the length of pipe that must be cut, and
mark the cut lines on the pipe, as shown below.
3. Cut the water pipe through the mark using a
pipe cutting tool, then remove the cut section of
pipe, as shown below.
SET
4. Sand both ends of cut pipe, removing any
burrs or rough edges. Use care handling the cut
edges, which may be sharp! Wipe off the cut
section of pipe with a clean cloth.
Installation
