Zonet ZEW2500P Manuale utente

is the registered trademark of Zonet Technology Inc. All the

products and product names mentioned herein are the trademarks or registered

trademarks of their respective holders. Copyright of the whole product as

integration, including its accessories and software, belongs to Zonet Technology

Inc. ithout the permission of Zonet Technology Inc., any individual or party is

not allowed to copy, plagiarize, imitate or translate it into other languages.

802.11g ireless USB Adapter

Table of Content

Chapter 1. Introduction……………………………………………………………2

1.1 Welcome…………………………………………….…………………………2

1.2 Product Feature…………………………………………………………………2

1.3 Content of Package……………….…………………….……………………2

Chapter 2. Installation…………………………………………………………………3

Chapter 3. Configuration………………………………………………………..……

3.1 Station Mode…….………………………………………………………..……

3.1.1 Profile…….……........……………………………………………..……7

3.1.1.1 Add/Edit Profile…………………………………………......……7

3.1.2 Network.......………………………………………………………………9

3.1.3 Link Status…………………………………………………………..…...9

3.1.4 Advanced……………..……….…………………………………………10

3.1.5 Statistics……………..……….…………………………………………10

3.1. WMM….......................………........………………..………………11

3.1.7 WPS….......................………........………………..………………12

3.2 AP Mode………………..…....……………………………….…………..13

3.2.1 Configuration………..……………………………………………...….13

3.2.2 Access Control…......………..………………………...………..……15

3.2.3 MAC Table...........………..…………………………....………………1

3.2.4 Switch to Working Station Mode..………………………………1

3.3 Use Zero Configuration................................….……….…………..17

Chapter 4. How to connect with PSP………………………………………….20

4.1 Configure PSP with Ad-Hoc mode……………………………….………20

4.2 Configure XLink Kai…………………………………………………………22

Chapter 5. Product Specifications………….........................……………….23

Chapter . TroubleShooting………….........................………….............24

802.11g ireless USB Adapter

Chapter 1 Introduction

1.1 Welcome

Thank you for purchasing Zonet ZE 2500P-802.11g wireless USB adapter.

ZE 2500P connects you with 802.11g networks at up to an incredible 54Mbps!

And for added versatility, it can also interoperate with all the up to 11Mbps

802.11b products found in homes, businesses, and public wireless hotspots

around the country.

Soft AP supported by ZE 2500P can help you establish wireless LAN networking

with lowest cost. Besides, PS ( i-Fi Protected Setup) simplify the security

setup and management of i-Fi networks. Supports MM for Multimedia

Applications with Quality of Service in i-Fi® Networks. Especially supporting

PS3, PSP, Nintendo DS and ii connections with XLink Kai software will be your

best choice to enjoy on-line gaming.

1.2 Product Feature

Complies with IEEE 802.11g and IEEE 802.11b standards

Provides USB2.0 port

Provides up to 54Mbps transmission rate and up to 300 meters

transmission distance

Auto-detects and changes the network transmission rate

Provides two work modes: Infrastructure and Ad-Hoc

Supports Soft AP to establish your wireless LAN networking

supports PS3, PSP, ii and Nintendo DS connecting with Internet and

XLink Kai to enjoy on-line gaming

Supports 64/128-bit EP, PA, PA2 encryption methods and 802.1x

security authentication standard

Supports ireless Roaming function

PS ( i-Fi Protected Setup) simplify the security setup and management

of i-Fi networks.

Supports MM for Multimedia Applications with Quality of Service in

i-Fi® Networks

Supports indows 2000 / XP / 2003 / Vista

1.3 Contents of Package

One ZE 2500P

One Installation CD w/User Manual

One Quick Installation Guide

One USB Cable

Contact your local authorized reseller or the store purchased from for any items

damaged and/or missing.

802.11g ireless USB Adapter

Chapter 2 Installation

NOTE:

For future driver upgrading, please visit our website at www.zonetusa.com

Snap-shot screens of the following installation procedure are based on Windows

X . Installation procedures will be similar for other windows operating systems.

1. Insert ZE 2500P into a USB

slot of your computer.

2. Select Cancel when Found

New Hardware window

appears.

Insert Installation CD to your

CD-ROM drive. B

owse CD and

double-click

Setup.exe

Driver folder to execute it. The

wizard will run and install all

necessary files to your

computer automatically.

802.11g ireless USB Adapter

4. C

lick

to accept the

Agreement. Or click

Cancel

cancel the installation

Select

Install driver and

Ralink W AN Utility

Install driver only

then click

Select

Ralink

Configuration

Tool

Microsoft Zero

Configuration Tool

then click

It’s recommended to select

Ralink Configuration Tool,

which provides fully access to

all function of ZE 2500P.

b. If you prefer to use the

wireless configuration tool

provided by indows XP or

Vista, please select

Microsoft

Zero Configuration Tool.

802.11g ireless USB Adapter

Click

Install

to start

installation. Or click

Cancel

to cancel the installation

8. Click Finish to complete the

software installation.

You will see a tray icon appear in your system tray at the bottom of the

screen after the software and hardware installation completed successfully.

802.11g ireless USB Adapter

Chapter 3 Configuration

3.1 Station Mode

Station Mode is the default access mode for ZE 2500P.

In this mode, ZE 2500P serves as a client to receive the wireless signals to

access the Internet.

Double-click the tray icon to launch the configuration utility.

Or right click the tray icon and select aunch Config Utility.

802.11g ireless USB Adapter

3.1.1 Profile

Profile can keep your favorite wireless setting among your home, office, and

other public hotspot. You may save multiple profiles and activate the one at your

preference.



Add:

to create a new profile



Edit:

to edit/modify/change parameter of an existing profile



Delete:

to delete an existing profile



Activate:

to make an existing profile become active and to connect

3.1.1.1

Add/Edit Profile

a. System Configuration



Power Save Mode:

CAM

(Constantly Awake Mode) – ZE 2500P will stay power-ON as long

as the computer is connected to a power outlet.

PSM

(Power Saving Mode) – ZE 2500P will hibernate when the

computer is hibernating.

802.11g ireless USB Adapter



Network Type:

Infrastructure

– A wireless Router and/or Access Point is required.

Ad-hoc

– Peer-to-Peer network, no base station required.



TX Power:

Amount of transmit power used by the radio transceiver to send out signal.

User can choose different value in the drop down menu



Preamble:

Only available under Ad-hoc mode. Value can be chose from Auto, Long, or

Short



Threshold:

Frame size when RTS/CTS handshake performs before attempt to transmit.

RTS Threshold:

Default value = 2347

Fragment Threshold:

Default value = 2346

Authentication and Encryption







Authentication:

Open, Shared, Leap, PA, PA-PSK, PA2 and

PA2-PSK.







Encryption:

Algorithm used in BSS or IBSS, EP, TKIP, AES, and None

c. 802.1X
