ZyXEL Communications ZYWALL OTPV2

Key Benefits

Strong Two-Factor Authentication Solution

The starting point of security is to ensure that only authorized people can remotely access the

protected network applications and resources. However, given enough time for attempts, it’s

relatively easy for unauthorized intruders to crack a static password.With a one-time password, the

risk can be greatly reduced by constantly altering the combination.The ZyWALL OTPv2

authentication token is a chip-based, 6-digit numeric PIN to be used alongside a password for strong

two-factor authentication.The ZyWALL OTPv2 solution,along with the SafeWord 2008 management

application, can be easily integrated with existing ZyWALL security solutions.

One token for many applications

The SafeWord 2008 is a network security application that provides LAN, Web,VPN, and remote access

with strong authentication capability.The SafeWord 2008 resides on the network and is managed by

network administrators,while the ZyWALL OTPv2 is operated on client computers.Together, they

provide a highly robust one-time password authentication mechanism to protect network

resources; the most common implementation using the two-factor authentication technology is

remote VPN authentication. Working with the powerful SafeWord 2008, the ZyWALL OTPv2 token

can be used universally in the authentication processes of LAN,Web and OWA applications.

Deploys easily and quickly

SafeWord 2008, SafeNet’s simple-to-deploy and easy-to-use authentication package,allows you to

set up a strong two-factor authentication solution in minutes.SafeWord 2008’s seamless integration

with Microsoft infrastructure makes it simple to deploy two-factor authentication for VPNs, Citrix

applications,Web applications,Webmail, and Outlook Web Access.

Intuitive and easy to install, use and manage

There are various ways to implement the authentication schemes. However many small- to

medium-sized businesses, enterprises and organizations need a two-factor authentication system

that is easy to understand,install, and administer; and it must be reliable once installed.With the

combination of driverless ZyWALL OTPv2 tokens and the SafeWord 2008, this solution provides

everything customers needed to deploy the two-factor authentication capability into network

environments.

Seamless integration with ZyWALL security products

The ZyWALL OTPv2 can be easily deployed along with ZyWALL security products and integrated into

the existing network infrastructure.These combinations provide customers with Two-Factor

Authentication, an optimum security methodology, to significantly elevate the safety level of the

authentication process.

ZyXEL’s OTPv2 (One-time Password) authentication solution has been enhanced to offer

more security when there are authorized individuals accessing your organization’s sensitive

information from a remote location, enabling business, protecting data confidentiality,

lowering IT costs, and boosting user productivity.

Key Features

Ł

Strong two-factor

authentication solution

Ł

One token for many

applications

Ł

Deploys easily and quickly

Ł

Intuitive and easy to install,use,

and manage

Ł

Seamless integration with

ZyWALL security products

Ł

Highly secure and

straightforward implementation

using SafeWord 2008

Enterprise

Security

Security Accessory —

ZyWALL OTPv2

Enterprise

Security

Security Accessory —

ZyWALL OTPv2

65-100-002008B 10/10

For more product information, visit us on the web at www.ZyXEL.com

ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their

respective owners. All specifications are subject to change without notice.

LAN

Network

Extend

Remote

Desktop

OA, ERP System

CRM System

File

Server

System

Web-based

Application

Application Server

(Inventory, Store...)

Employee on

Home Computer

ZyWALL OTPv2

Employee Laptop in

Airport Kiosk or in

Hotel

ZyWALL OTPv2

ZyWALL

SafeWord 2008

Authentication

Server

WAN LAN

Encrypted Decrypted

ZyWALLUSG100

LAN1/LAN2/DMX

WAN1

USB

WAN2

PWR

SYS

AUX

RESET

CARD

P1P2P3P4P5P6P7

Internet

Enter PIN code

displayed on

the ZyWALL

OTPv2 token

jackyliu

zyxel

705571

Authorized Partner

Authorized Customer

ZyWALL OTPv2

System Specifications

Chip-based Authentication Token

• Power: Internal battery

• Driverless

OTP Number Generation

• OATH-compliant (Based on HMAC-SHA1)

Supported Software

• Remote Access (With SafeNet SafeWord 2008

Authentication Server):

- SSL VPN

- VPN with: OTP-capable VPNs

- Dial-up to a remote server with RADIUS

- Web access with RADIUS

Physical Specifications

• Power: Internal battery

• Casing: Polycarbonate

• Dimensions: 55 (L) x 12.2 (D) x 25 (W) mm

• Weight:13 g

Environmental Specifications

Operation Environments

• Temperature: 0°C~ 70°C

• Humidity:10% ~ 100%

Storage Environments

• Temperature: -40°C ~ 85°C

• Humidity:10% ~ 100%

ZyXEL Appliances Supported

• All ZyWALL USG products

SafeWord 2008 Software

• Protects your most important information assets

and applications

• Positively identifies remote VPN,Citrix and

Outlook Web Access users

• Designed for Windows environments, offers

seamless Microsoft AD integration

• Delivers an easy, fast installation experience: runs

on existing servers

SafeWord 2008 Server Requirements*

Hardware

• CPU: Single processor with 1.4 GHz (x64

processor) or 1.3 GHz (Dual Core)

• RAM: 512 MB or Higher

• Disk Space: 32 GB or greater

• Display: Super VGA (800 × 600) or higher

resolution monitor

• Other: DVD Drive, Keyboard and Microsoft

Mouse (or compatible pointing device),

Internet access (fees may apply)

Software

• Operation System: Microsoft Windows Server

2000, 2003 and 2008

* Note:

• Actual requirements will vary based on your system configuration,

and the applications and features you choose to install.

• Processor performance is dependent upon not only the clock

frequency of the processor, but the number of cores and the size of

the processor cache.

• Disk space requirements for the system partition are approximate.

Additional available hard disk space may be required if you are

installing over a network.

Specifications

Application Diagram

Enterprise Security

Security Accessory —

ZyWALL OTPv2

Enterprise Security

Security Accessory —

ZyWALL OTPv2
