ZyXEL Communications GS-105B Manuale utente

5/8-port Desktop Gigabit Switch

GS-105B

GS-108B

Benefits

Up to 2000 Mbps Bandwidth Per Port

ZyXEL’s GS-105B/GS-108B 10/100/1000 Mbps desktop switches are

designed for reliable high-performance networks.Thanks to the non-

blocking switching fabric in full-duplex mode, the maximum speed can

reach up to 2000 Mbps per port; the Store-and-Forward service brings low-

latency and error-free packet delivery.With these features,the transmission

efficiency can be boosted dramatically.

Hassle-free Installation

With the N-way auto-negotiation function, the GS-105B/GS-108B

automatically connects to its network counterparts with the highest

possible network speed and activates duplex mode automatically. All it

takes to enliven your network is just plugging in the cable, and no manual

configuration is required.

Compact Stylish Design

The stylish compact metal housing fits any working environment.

GS-105B/GS-108B comes with different port configurations for affordable

and reliable SOHO network expansion needs.

WIT

Easy and Reliable Gigabit

Network Expansion for SOHO

Ŝ

5/8 Auto-sensing 10/100/1000 Mbps Full-duplex, Auto

MDI/MDI-X Ports

Ŝ

Full Wire-speed Store-and-Forward Technology Support

Ŝ

True Plug-and-Play Installation

5/8-port Desktop Gigabit Switch

GS-105B

GS-108B

System Specifications

dard

tanda

Sta

•

EE 802.3

IEEE

•

EEE 802.3u

•

EEE 802.3a

IEEE 802.3x stan

•

10/100/1000 Mbps RJ-45 switchin

ports

(

GS-105B

)

•

8 10/100/1000 Mbps RJ-45 switchin

ports

(

GS-108B

)

•

Way Protoco

Support

•

0 Mbps: Full/Hal

duplex

•

00 Mb

s: Full/Half du

lex

•

000 Mbps: Full duplex onl

Emission

ch LED

cators

•

wer

reen

•

ink/Act: Gree

Hardware Specifications

• Power Supply

• External switching power: 5 V DC 1 A (GS-105B),

12 V DC 1 A (GS-108B)

Physical Specifications

GS-105B

• Dimensions: 121 (W) x 75 (D) x 26 (H) mm

• Weight: 271 g

GS-108B

• Dimensions: 154.5 (W) x 85 (D) x 26 (H) mm

• Weight: 382 g

Environmental Specifications

• Operating temperature: 0ºC ~ 40ºC (32ºF ~ 104ºF)

• Operating humidity: 10% ~ 90% (non-condensing)

Certification

• FCC Class A, CE,VCCI

Specifications

For more product information, visit us on the web at www.ZyXEL.com

65-100-108013B 06/08

product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.
