Options for ABB drives, converters and inverters

Quick installation and start-up guide

FPNO-21 PROFINET adapter module

Safety instructions

WARNING! Obey the safety instructions. If you ignore them, injury or death, or damage to the

equipment can occur. See the user’s manual.

Mechanical installation

Electrical installation

Layout of the module

1. Pull out the lock.

2. Install the module carefully to an option

module slot of the drive. See the drive

hardware manual.

3. Push in the lock.

4. Tighten the screw to torque 0.8 N·m using

a Torx TX10 screwdriver.

WARNING! Do not use excessive force,

or leave the screw too loose. Over-

tightening can damage the screw or

module. A loose screw decreases the EMC

performance, and can even cause an operation

failure.

13

4

No. Description

1Lock

2 Mounting and grounding screw

3 RJ-45 connector [X1] to Ethernet

4 RJ-45 connector [X2] for chaining another module

5 Diagnostic LEDs

6 MAC ID

5

3

2

4

1

6

Start-up

When the module is connected to the drive, the drive control program sets the applicable parameters.

See the appropriate drive manual.

Basic parameter settings

To take the settings into use, validate and refresh the parameters with parameter 51.27 FBA par refresh.

Connectivity configuration

The FPNO-21 adapter module has a web page for connectivity configuration.

To access the web page:

1. Open a web browser and type the IP address of the adapter module in the address field.

The IP address is visible in group 51, parameters 5...8

Example: http://192.168.0.24/

2. Log in with a user name and a password.

The default user name: admin

Password: The last six digits of the MAC address of the adapter module, in upper case letters,

without hyphens. The MAC ID is visible on the front cover of the adapter module.

Example: If the MAC address of the adapter module is 00-1C-01-00-2F-73, the password is 002F73.

Further information

Index Name Value

20.01 Ext1 commands Fieldbus A

22.11 Speed ref1 source FBA A ref 1

28.11 Frequency ref1 source FBA A ref 1

50.01 FBA A enable Enable (or select the option slot in which the module is installed).

This activates the communication module. The HOST LED becomes green.

50.02 FBA A comm loss func Fault

51.02 Profile The ABB Drives communication profile is the default value.

52.01 FBA A data in1 SW 16bit

52.02 FBA A data in2 Act 16bit

53.01 FBA A data out1 CW 16bit

53.02 FBA A data out2 Ref1 16bit

See the latest version of FPNO-21 PROFINET adapter

module user's manual (3AXD50000158614 [English]) in

ABB library (www.abb.com/drives/documents).

For more information on fieldbus options and protocols

provided by ABB Drives, see the fieldbus

communications web page

(new.abb.com/drives/connectivity/fieldbus-connectivity).

3AXD50000158577 Rev A (EN) 2017-11-23

FPNO-21 manual

Fieldbus communications web page
