Acorp 7KMA Manuale utente

The information presented in this publication has been

made carefully for reliability; however, no responsibility

is assumed for inaccuracies. Specifications are subject

to change without notice.

IBM, PC/AT, and PC/XT are trademarks of Interna-

tional Business Machines Corporation.

Athlon is a trademark of AMD Corporation

AWARD is a registered trademark of Phoenix

Sofftware Inc.

MS-DOS and WINDOWS NT are registered trade-

marks of Microsoft Corporation.

Trademarks and/or registered trademarks are the

properties of their respective owners.

User's Manual Version 1.0

7KMA

Table of Contents

IntroductionIntroduction

Introduction

1. Motherboard Description1. Motherboard Description

1. Motherboard Description

1.1 Features

1.1.1 Hardware 2

1.1.2 Software 4

1.1.3 Attachments 4

1.2 Motherboard Installation

1.2.1 Layout of Motherboard 5

1.3 Motherboard Connectors

1.3.1 Front Panel Connectors(J1) 7

1.3.2 Floppy Disk Connector(FDD1) 8

1.3.3 Hard Disk Connectors(IDE1/IDE2) 8

1.3.4 ATX 20-pin Power Connector(PW1) 9

1.4 Back Panel Connectors

1.4.1 PS/2 Mouse/Keyboard CONN. 10

1.4.2 USB Connectors (RJ45+USB) 10

1.4.3 VGA Interface Connector(VGA1) 11

1.5 Serial and Parallel Interface ports 12

1.6 CPU Installation

1.6.1 CPU Installation Product(Socket 462) 14

1.6.2 CPU Clock Setting(SW1) 15

1.7 Jumper Setting

1.7.1 CPU Fan Connector(FAN1/2/3) 16

1.7.2 Wake-On-Modem Header(WOM1) 17

1.7.3 Wake-On-LAN Header(WOL1) 17

1.7.4 AMR Code Select(JP1) 18

1.7.5 CMOS Function Selection(JP2) 18

1.8 DRAM Installation

1.8.1 DIMM 19

1.8.2 How to install a DIMM Module 19

1.9 Audio Subsystem

1.9.1 CD-Audio-IN Connectors(CDIN1/CDIN2) 20

Table of Contents

2. BIOS Setup2. BIOS Setup

2. BIOS Setup

2.1 Main Menu 24

2.2 Standard CMOS Features 27

2.3 Advanced BIOS Features 30

2.4 Advanced Chipset Features 34

2.5 Integrated Peripherals 38

2.6 Power Management Setup 43

2.7 PnP/PCI Configurations 48

2.8 PC Health Status 52

2.9 Frequency/Voltage Control 53

2.10 Load Fail-Safe Defaults 54

2.11 Load Optimized Defaults 55

2.12 Set Supervisor/user Password 56

2.13 Save & Exit Setup 58

2.14 Exit Without Saving 59

iii

Chapter 1 Motherboard Description /1Chapter 1 Motherboard Description /1

Chapter 1 Motherboard Description /1

Introduction

System Overview

This manual was written to help you start using this product

as quickly and smoothly as possbile. Inside you will find

adequate explanations to solve most problems. In order for

this reference material to be of greatest use,refer to the “ex

panded table of contents” to find relevant topics. This board

incorporates the system board, I/O ,and PCI IDE into one

board that provides a total PC solution. The mainboard,AMD

Athlon and Duron processor based PC ATX system,support

single processors with ISA Bus, PCI Local Bus, and AGP

Bus to support upgrades to your system performance. It is

ideal for multi-tasking and fully supports MS-DOS, Windows,

Windows NT , Windows 2000, Windows ME , Novell, OS/2,

Windows95/98 , UNIX , SCO UNIX etc.

This manual also explains how to install the mainboard for

operation, and how to setup your CMOS configuration with

the BIOS setup program.

2 / Chapter 1 Motherboard Description2 / Chapter 1 Motherboard Description

2 / Chapter 1 Motherboard Description

1.Motherboard Description

1.1 Features

1.1.1 Hardware

CPU

-Single AMD Socket 462 Athlon/Duron.

-200MHz System Interface speed.

Speed

-Supports 33MHZ PCI Bus speed.

-Supports 2X/4X AGP Bus.

DRAM Memory

-Supports 8/16/32/64....MB DIMM module socket.

-Supports Synchronous DRAM(3.3V)

-Supports a maximum memory size of 1.536GB with SDRAM.

Shadow RAM

-A memory controller provide shadow RAM and supports

8-bit ROM BIOS.

Green Function

-Support power management operation via BIOS.

-Power down timer from 1 to 15 mins.

-Wakes from power saving sleep mode at the press of

any key or any mouse activity.

Bus Slots

-Provide one AGP slot and one AMR.

-Five 32-bit PCI bus and one 16-bit ISA.

Universal Serial Bus

-Supports two back Universal Serial Bus(USB)Ports

and two front Universal serial Bus(USB)Ports.

Hardware Monitor Function

-CPU Fan Speed Monitor.

-System (Optional) and CPU Temperature Monitor.

-System Voltage Monitor.

Chapter 1 Motherboard Description /3Chapter 1 Motherboard Description /3

Chapter 1 Motherboard Description /3

Flash Memory

-Support flash memory.

-support ESCD Function.

IDE Bulit-in On Board

-Supports four IDE hard disk drives.

-Supports PIO Mode 4,Master Mode,high performance hard disk

drives.

-Support Ultra DMA 33,66 Bus Master Mode.

-Supports IDE interface with CD-ROM.

-Supports high capacity hard disk drives.

-Support LBA mode.

PCI-Based AC 97 Digital Audio Processor(Optional)

-AC 97 2.1 interface.

-16 channels of high-quality sample rate conversion.

-16x8 channel digital mixer.

-Stereo 10 band graphic equalizer.

-Sound Blaster and Sound Blaster Pro emulation.

-S/PDIF output (allows standard interface to consumer electronics).

-64-voice wavetable.

I/O Bulit-in On Board

-Supports one multi-mode Parallel Port.

(1)Standard & Bidirection Parallel Port

(2)Enhanced Parallel Port(EPP)

(3)Extended Capabilities Port

-Supports two serial ports,16550 UART.

-Supports one Infrared transmission(IR).

-Supports PS/2 mouse and PS/2 Keyboard.

-Supports 360KB, 720KB, 1.2MB, 1.44MB, and 2.88MB floppy disk

drivers.

4 / Chapter 1 Motherboard Description4 / Chapter 1 Motherboard Description

4 / Chapter 1 Motherboard Description

1.1.2 Software

BIOS

-AWARD legal BIOS.

-Supports APM 1.2.

-Supports USB Function.

-Supports ACPI

Operation System

-Offers the highest performance forMS-DOS,Windows,

Windows NT , Windows 2000, Windows ME , Novell, OS/2,

Windows95/98, UNIX, SCO UNIX etc.

1.1.3 Attachments

-HDD UDMA66 Cable.

-FDD Cable.

-Flash Memory Written for BIOS Update.

-USB2 Cable (Optional).

-COM2 Cable.

-Fully Setup Driver CD build in Utility(Ghost, Anitivirus,

Adobe Acrobat...).

Chapter 1 Motherboard Description /5Chapter 1 Motherboard Description /5

Chapter 1 Motherboard Description /5

1.2 Motherboard Installation

1.2.1 Layout of Motherboard

USB1

FAN2

JP2

FAN1

JACK1

JACK2

JACK3

GAME1

VIA

FAN3

LAN CHIP

AMR SLOT

AGP SLOT

JP1

ISA SLOT

PCI1

PCI2

PCI3

PCI4

PCI5

DIMM3

DIMM2

DIMM1

462

BIOS

COM1

VGA1

Printer

6 / Chapter 1 Motherboard Description6 / Chapter 1 Motherboard Description

6 / Chapter 1 Motherboard Description

1.3 Motherboard Connectors

USB1

FAN2

JP2

FAN1

JACK1

JACK2

JACK3

GAME1

VIA

FAN3

LAN CHIP

AMR SLOT

AGP SLOT

JP1

ISA SLOT

PCI1

PCI2

PCI3

PCI4

PCI5

DIMM3

DIMM2

DIMM1

462

BIOS

COM1

VGA1

Printer

4,5

1.Back Pannel I/O Connectors1.Back Pannel I/O Connectors

1.Back Pannel I/O Connectors 2.CD Audio-In Connector2.CD Audio-In Connector

2.CD Audio-In Connector2.CD Audio-In Connector

2.CD Audio-In Connector

3.AMR CODEC Fuction(JP1)3.AMR CODEC Fuction(JP1)

3.AMR CODEC Fuction(JP1) 4.Wake-On MODEM Connector4.Wake-On MODEM Connector

4.Wake-On MODEM Connector4.Wake-On MODEM Connector

4.Wake-On MODEM Connector

5.Wake-On-LAN Connector5.Wake-On-LAN Connector

5.Wake-On-LAN Connector 6.Front Two USB Connector6.Front Two USB Connector

6.Front Two USB Connector6.Front Two USB Connector

6.Front Two USB Connector

7.Front Panel Connector7.Front Panel Connector

7.Front Panel Connector 8.Fan connectors(Fan1/2/3)8.Fan connectors(Fan1/2/3)

8.Fan connectors(Fan1/2/3)8.Fan connectors(Fan1/2/3)

8.Fan connectors(Fan1/2/3)

9.IDE Connectors9.IDE Connectors

9.IDE Connectors 10.Floppy Connector10.Floppy Connector

10.Floppy Connector10.Floppy Connector

10.Floppy Connector

11.CPU Clock Selection(SW1)11.CPU Clock Selection(SW1)

11.CPU Clock Selection(SW1) 12.IR Connector12.IR Connector

12.IR Connector12.IR Connector

12.IR Connector

13.ATX Power Connector13.ATX Power Connector

13.ATX Power Connector

14.CMOS Function Selection(JP2)14.CMOS Function Selection(JP2)

14.CMOS Function Selection(JP2)

15.Front Two COM Connector15.Front Two COM Connector

15.Front Two COM Connector

Chapter 1 Motherboard Description /7Chapter 1 Motherboard Description /7

Chapter 1 Motherboard Description /7

1.3.1 Front Panel Connector(J1)

J1 PANEL Connector

Speaker Connector (SPEAKER)

An offboard speaker can be installed onto the motherboard as a

manufacturing option.An offboard speaker can be connected to

the motherboard at the front pannel connector. The speaker

(onboard or offboard) provides error beep code information dur-

ing the Power Self-Test when the computer cannot use the vedio

interface. The speaker is not connected to the audio subsystem

and does not receive output from the audio subsystem.

Hard Drive LED Connector (HD_LED)

This connector supplies power to the cabinet IDE activity LED.

Read and write activity by devices connected to the Primary or

Secondary IDE connectors will cause the LED to light up.

SMI Suspend Switch Lead (SMI)

This allows the user to manually place the system into a suspend

mode or Green mode where systematic activity will be instantly

decreased to save electricity and expand the life of certain com-

ponents when the system is not in use. This 2-pin connector

(see the figure below) connects to the case-mounted suspend

switch. If you do not have a switch for the connector, you may

use the Turbo Switch” instead since it does not have a function.

SMI is activated when it detects a short to open moment and

therefore leaving it shorted will not cause any problems. It may

require one or two pushes depending on the position of the

switch. Wake-up can be controlled by settings in the BIOS but

the keyboard will always allow wake-up (the SMI lead cannot

wake-up the system). If you want to use this connector, "Sus-

pend Switch" in the Power Management Setup of the BIOS SOFT-

WARE section should be on the default setting of Enable.

SPEAK

PW_BN

RST

SMI

HD_LED PW_LED

SMI_LED
