Adaptec SATA RAID FOR ADAPTEC Manuale utente

USER’SGUIDE

ADAPTEC EMBEDDED SERIAL ATA RAID

reproduced, stored in a retrieval system, or transmitted in any form or by any

means, electronic, mechanical, photocopying, recording or otherwise, without the

prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.

Trademarks

Adaptec, the Adaptec logo, Adaptec Storage Manager, and HostRAID are

trademarks of Adaptec, Inc., which may be registered in some jurisdictions.

Windows 2000, Windows Server 2003, and Windows XP are trademarks of

Microsoft Corporation in the US and other countries, used under license.

All other trademarks are the property of their respective owners.

Changes

The material in this document is for information only and is subject to change

without notice. While reasonable efforts have been made in the preparation of this

document to assure its accuracy, Adaptec, Inc. assumes no liability resulting from

errors or omissions in this document, or from the use of the information contained

herein.

Adaptec reserves the right to make changes in the product design without

reservation and without notification to its users.

Disclaimer

IF THIS PRODUCT DIRECTS YOU TO COPY MATERIALS, YOU MUST HAVE

PERMISSION FROM THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID

VIOLATING THE LAW WHICH COULD RESULT IN DAMAGES OR OTHER

REMEDIES.

iii

Contents

1 Introduction

Overview 1-1

What is HostRAID? 1-1

Operating System Compatibility 1-2

Storage Requirements 1-2

Features 1-2

Storage Management Software Overview 1-3

2 Installing the Driver

Installing the Driver in a New Windows System 2-2

Installing the Driver in an Existing Windows System 2-3

Installing Red Hat or SuSE Linux 2-3

Installing the Red Hat Driver in a New Linux System 2-3

Installing the SuSE Driver in a New Linux System 2-4

Installing or Updating the Driver in an Existing Red Hat

or SuSE Linux System 2-5

Installing the Netware Driver in a New NetWare System 2-6

Installing or updating device drivers after installing

NetWare 2-7

Updating the Device Drivers 2-7

Installing the Device Drivers 2-7

3 Installing and Starting Adaptec Storage Manager

Installing Storage Manager on Windows 3-2

Installing Storage Manager on Linux 3-3

Installing Storage Manager on NetWare 3-4

Starting Storage Manager 3-5

Logging into Remote Systems 3-5

Contents

4 Understanding Adaptec Storage Manager

Introduction 4-1

Features 4-1

Overview 4-2

Physical Devices View 4-3

Logical Devices View 4-3

Changing How Drives are Displayed 4-4

Collapsed and Expanded Views 4-4

Component Views 4-5

5 Adaptec RAID Configuration Utility

Using the Array Configuration Utility 5-2

Managing Arrays 5-2

Creating Arrays 5-3

Add/Delete Hotspares 5-6

Initializing Disk Drives 5-6

Rebuilding Arrays 5-7

Verifying Drives 5-8

Using the Disk Utilities 5-8

Glossary

Index

1-1

Introduction

In this Chapter...

Overview

Adaptec Embedded Serial ATA RAID with HostRAID® adds RAID

functionality to the Serial ATA I/O controller by supporting RAID

levels 0, 1, and 10.

What is HostRAID?

HostRAID adds entry level RAID support to the Serial ATA I/O

controller. With HostRAID, you can add reliable performance and

full data protection.

Overview 1-1

Operating System Compatibility 1-2

Storage Requirements 1-2

Features 1-2

Storage Management Software Overview 1-3

1-2

Introduction

Operating System Compatibility

Note: The HostRAID embedded software product supports

the following operating systems. However, depending on the

vendor and specific configuration of your system, it is

possible that only some of these operating systems are

supported. Consult your hardware vendor to clarify

operating system support.

■Microsoft®Windows®2000, Windows Server®2003,

Windows XP, and IA-32

■Linux

■Red Hat Advanced Server 2.1 and 3.0

■SuSE SLES 8.0 and 8.2

■SuSE 9.0

■United Linux 1.0

■Miracle Linux 2.1

■Novell NetWare 6.5

Storage Requirements

Device drivers and storage management software require

approximately 20 MB of disk space.

Features

Adaptec Embedded Serial ATA RAID supports:

■RAID levels 0, 1, and 10 using Adaptec’s HostRAID technology.

■Operating system independent configuration and RAID

creation using Adaptec RAID Configuration (ARC).

■Easy array configuration and status using Adaptec Storage

Manager.

Install Adaptec Storage Manager as described in Chapter 3,

Installing and Starting Adaptec Storage Manager.

1-3

Introduction

■Hot swap rebuild of fault tolerant arrays through the operating

system.

■Event logging and broadcasting, including messaging for

alphanumeric pagers.

Storage Management Software Overview

Adaptec Embedded Serial ATA RAID includes the following

software tools to manage your storage subsystem:

■Adaptec Storage Manager—A storage management application

that provides you with an easy-to-use graphical interface to

manage your storage subsystem. For details, see Chapters 3

and 4.

■Adaptec RAID Configuration (ARC) Utility—Part of the

controller’s built-in BIOS code. You start ARC by pressing

Ctrl+A during BIOS startup. For details, see Chapter 5, Adaptec

RAID Configuration Utility.

■Array Configuration Utility (ACU)—A DOS/BIOS application

used to create, configure, and manage arrays. For details, see

Chapter 5, Adaptec RAID Configuration Utility.

Note: You must have the most recent versions of Adaptec

Storage Manager and ARC utility installed to run the Adaptec

Embedded SATA RAID drivers.

2-1

Installing the Driver

In this Chapter...

This chapter describes installing the driver and setting up the new

array for the drives attached to your controller. Before you get

started, you need to select from the following scenarios for

installing the controller driver on Windows, Linux, or NetWare

systems:

■Installing the Driver in a New Windows System on page 2-2

■Installing the Driver in an Existing Windows System on page 2-3

■Installing Red Hat or SuSE Linux on page 2-3

■Installing the Netware Driver in a New NetWare System on

page 2-6

■Installing or updating device drivers after installing NetWare on

page 2-7

Note: You must have the most recent versions of Adaptec

Storage Manager and ARC utility installed to run the Adaptec

Embedded SATA RAID drivers.

Installing the Driver in a New Windows System 2-2

Installing the Driver in an Existing Windows System 2-3

Installing Red Hat or SuSE Linux 2-3

Installing the Netware Driver in a New NetWare System 2-6

Installing or updating device drivers after installing NetWare 2-7

2-2

Installing the Driver

Installing the Driver in a New Windows System

In this scenario, you are installing the driver in a new system that

has no operating system. To install the driver:

1Create a driver disk by following the instructions from the Web

site or the product CD.

2Restart the computer.

3If creating an array, press Ctrl+A when prompted to enter the

ARC utility. For instructions on creating an array from the BIOS,

see Chapter 5, Adaptec RAID Configuration Utility.

4When the array is finished building, insert the Windows setup

CD and restart the system.

5Press F6 when prompted to install a third-party driver.

Note: When F6 is active, a prompt appears at the bottom of

the screen. Press F6 immediately—you only have

5 seconds. If you miss your chance, restart this Windows

installation to complete it correctly. Otherwise, Windows

will not recognize your controller.

6Insert the driver disk you created in Step 1 and wait until

prompted to install a driver.

7Press Sto specify that the driver is on the floppy disk, then

press Enter.

Windows searches the disk for a suitable driver.

8When the Adaptec Embedded Serial ATA HostRAID driver is

found, press Enter. Follow the remaining on-screen instructions

to complete your installation.

2-3

Installing the Driver

Installing the Driver in an Existing Windows

System

In this scenario, you are installing a driver in a system that already

has a Windows operating system. To install the driver:

1Create a driver disk by following the instructions from the Web

site or the product CD.

2Start Windows. Windows launches the Found New Hardware

Wizard, which searches for the controller driver.

3Insert the driver disk you created in Step 1, select the floppy

disk drive as the source then click Next.

4If necessary, select the appropriate driver for your operating

system.

5Click Next as needed to complete the controller installation.

6Remove the driver disk.

7If prompted, restart the computer.

8Your installation is complete. If you want to create an array

from the BIOS, see Chapter 5, Adaptec RAID Configuration

Utility. If you want to create an array from the operating

system, see Chapter 4, Understanding Adaptec Storage Manager.

Installing Red Hat or SuSE Linux

Installing the Red Hat Driver in a New Linux System

In this scenario, you are installing the driver in a new Red Hat

Linux system. To install the driver:

1Create a driver disk by following the instructions from the Web

site or the product CD.

2Restart the computer.

3If creating an array, press Ctrl+A when prompted to enter the

ARC utility. For instructions on creating an array from the BIOS,

see Chapter 5, Adaptec RAID Configuration Utility.

4When the array is finished building, insert the Red Hat CD

Disk 1 in the CD-ROM drive then restart the system.
