ADC advantage connect 6024N Manuale utente
Quick Start Guide
advantage connect®
Model 6024N
1.
Insert batteries,
observing polarity.
2. Insert the cuff connector
into the port on the
left side of the unit.
3. Apply cuff to bare upper arm. Artery mark should align
with brachial artery.
4. Sit comfortably in a chair with the
seat back and your feet resting on
the floor. Legs should not be crossed.
Arm should be supported yet relaxed
and positioned level with your heart.
Rest for two minutes before starting
measurement.
-
+
-
+
-
+
-
+
4 x AAA,
1.5V
i
See page 12 in the instructions for use to set date and time or press
the on/off button once to skip this step.
i
The monitor defaults to single measurement mode. See page 13 in
the instructions for use to change to three-reading average mode.
See page 14 in the instructions for use if you plan to use the
ADC@Home app and would like to get set up now.
3/4” to 1”
above elbow
Tube toward
lower arm
Artery
Mark
American Diagnostic Corporation
55 Commerce Drive, Hauppauge, New York 11788
Toll Free: 1-800-ADC-2670
Telephone: 631-273-9600
Fax: 631-273-9659
www.adctoday.com
5. Press ON/OFF button
to begin reading.
Remain still and quiet
during measurement.
When complete,
reading will display
and be stored
in memory.
6. Recall readings from memory
by pressing the memory button.
Advanced Bluetooth technology allows you to
pair your monitor with your smartphone or tablet
using our free ADC@Home app.
Once paired, data from your monitor will be sent
to the app automatically whenever you take
a reading.
You can then view, graph, annotate, and share
readings with your physician or other caregivers.
See page 14 in the instructions for use to
get started.
For detailed instructions or advanced settings, consult
instructions for use or visit www.adctoday.com/ADCatHome.
®
p/n: 93-6024NQS-00 rev 0
M
Systolic pressure,
diastolic pressure,
and pulse rate
appear on display
