Part 1: AC7015 Core Board Introduction

The AC7015 (core board model, the same below) core board is an FPGA

development board based on the Zynq chip

XC7Z015-2CLG485I

of the XILINX

ZYNQ7000 series. The ZYNQ chip's PS system integrates two ARM CortexTM-A9

processors, AMBA® interconnects, internal memory, external memory interfaces

and peripherals. The ZYNQ FPGA chip contains a wide range of programmable

logic cells, DSP and internal RAM.

The core board uses two SK Hynix DDR3 chips (H5TQ4G63AFR-PBI), each

with a DDR capacity of 4Gbit; two DDR chips form a 32-bit data bus width, and the

read and write data clock frequency between ZYNQ FPGA and DDR3 is up to

533Mhz; such a configuration can meet the system's high bandwidth data

processing needs

In order to connect to the expansion board, the four board-to-board connectors

of the core board extend the USB interface of the PS side, the Gigabit Ethernet

interface, the SD card interface and other remaining MIO ports. Extend ZynQ's 4-

pair high-speed transceiver GTP interface. Almost all IO ports (84) of BANK13,

BAN34 and BANK35 on the PL side, the level of IO of BANK35 can be modified by

replacing the LDO chip on the core board to meet the requirements of users with

different level interfaces. For users who need a lot of IOs, this core board will be a

good choice. Moreover, the IOs connection part, the routing between the ZYNQ

FPGA chip and the interface is equal length and differential processing. The core

board size is only 60*60 (mm), which is very suitable for secondary development.

5/31

ZYNQ FPGA Development Platform AC7015 User Manual

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]m

Figure 1-1: AC7015

Core board Front View

Figure 1-2: AC7015 Core Board Rear View

6/31

ZYNQ FPGA Development Platform AC7015 User Manual

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]m

Part 2: ZYNQ Chip

The development board uses Xilinx's Zynq7000 series chip, model XC7Z015-

2CLG485I. The chip's PS system integrates two ARM CortexTM-A9 processors,

AMBA® interconnects, internal memory, external memory interfaces and

peripherals. These peripherals mainly include USB bus interface, Ethernet

interface, SD/SDIO interface, I2C bus interface, CAN bus interface, UART interface,

GPIO etc. The PS can operate independently and start up at power up or reset.

Figure 2-1 detailed the

Overall Block Diagram of the ZYNQ7000 Chip.

Figure 2-1: Overall Block Diagram of the ZYNQ7000 Chip

The main parameters of the PS system part are as follows:

ARM dual-core CortexA9-based application processor, ARM-v7

architecture, up to 1GHz

32KB level 1 instruction and data cache per CPU, 512KB level

2 cache 2 CPU shares

On-chip boot ROM and 256KB on-chip RAM

External storage interface, support 16/32 bit DDR2, DDR3

7/31

ZYNQ FPGA Development Platform AC7015 User Manual

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]m

interface

Two Gigabit NIC support: divergent-aggregate DMA, GMII,

RGMII, SGMII interface

Two USB2.0 OTG interfaces, each supporting up to 12 nodes

Two CAN2.0B bus interfaces

Two SD card, SDIO, MMC compatible controllers

2 SPIs, 2 UARTs, 2 I2C interfaces

4 groups of 32bit GPIO, 54 (32+22) as PS system IO, 64

connected to PL

High bandwidth connection within PS and PS to PL

The main parameters of the PL logic part are as follows:

LogicCells: 85K

Look-up-tables (LUTs):53,200

Flip-flops:106,400

18x25MACCs：220;



BlockRAM：4.9Mb

Two AD converters for on-chip voltage, temperature sensing

and up to 17 external differential input channels, 1MBPS

XC7Z015-2CLG485I chip speed grade is -2, industrial grade, package is

BGA484, pin pitch is 0.8mm, the specific chip model definition of ZYNQ7000 series

is shown in Figure 2-2

Figure 2-2: The Specific Chip Model Definition of ZYNQ7000 Series

8/31

ZYNQ FPGA Development Platform AC7015 User Manual

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]m

Figure 2-3: TheXC7Z020 chip used on the Core Board

Part 3: DDR3 DRAM

The AC7015 core board is equipped with two SK Hynix DDR3 SDRAM chips (1GB total),

model H5TQ4G63AFR-PBI. The bus width of DDR3 SDRAM is 32 bits in total. DDR3 SDRAM

has a maximum operating speed of 533MHz (data rate 1066Mbps). The DDR3 memory system

is directly connected to the memory interface of the BANK 502 of the ZYNQ Processing System

(PS). The specific configuration of DDR3 SDRAM is shown in Table 3-1

Table 3-1: DDR3 SDRAM Configuration

The hardware design of DDR3 requires strict consideration of signal integrity.

We have fully considered the matching resistor/terminal resistance, trace

impedance control, and trace length control in circuit design and PCB design to

ensure high-speed and stable operation of DDR3.

The hardware connection of DDR3 DRAM is shown in Figure 3-1:

Bit Number

Chip Model

Capacity

Factory

U5,U6

H5TQ4G63AFR-PBI

256M x 16bit

SK Hynix

9/31

ZYNQ FPGA Development Platform AC7015 User Manual

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]m

Figure 3-1: The Schematic part of DDR3 DRAM

Figure 3-2: DDR3 DRAM on the Core Board

DDR3 DRAM Pin Assignment

Signal Name

ZYNQ Pin Name

Pin Number

DDR3_DQS0_P

PS_DDR_DQS_P0_502

C21

DDR3_DQS0_N

PS_DDR_DQS_N0_502

D21

DDR3_DQS1_P

PS_DDR_DQS_P1_502

H21

DDR3_DQS1_N

PS_DDR_DQS_N1_502

J21

DDR3_DQS2_P

PS_DDR_DQS_P2_502

N21

DDR3_DQS2_N

PS_DDR_DQS_N2_502

P21

10 /31

ZYNQ FPGA Development Platform AC7015 User Manual

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]m

DDR3_DQS3_P

PS_DDR_DQS_P3_502

V21

DDR3_DQS4_N

PS_DDR_DQS_N3_502

W21

DDR3_D0

PS_DDR_DQ0_502

D12

DDR3_D1

PS_DDR_DQ1_502

C20

DDR3_D2

PS_DDR_DQ2_502

B21

DDR3_D3

PS_DDR_DQ3_502

D20

DDR3_D4

PS_DDR_DQ4_502

E20

DDR3_D5

PS_DDR_DQ5_502

E22

DDR3_D6

PS_DDR_DQ6_502

F21

DDR3_D7

PS_DDR_DQ7_502

F22

DDR3_D8

PS_DDR_DQ8_502

G21

DDR3_D9

PS_DDR_DQ9_502

G22

DDR3_D10

PS_DDR_DQ10_502

L22

DDR3_D11

PS_DDR_DQ11_502

L21

DDR3_D12

PS_DDR_DQ12_502

L20

DDR3_D13

PS_DDR_DQ13_502

K22

DDR3_D14

PS_DDR_DQ14_502

J22

DDR3_D15

PS_DDR_DQ15_502

K20

DDR3_D16

PS_DDR_DQ16_502

M22

DDR3_D17

PS_DDR_DQ17_502

T20

DDR3_D18

PS_DDR_DQ18_502

N20

DDR3_D19

PS_DDR_DQ19_502

T22

DDR3_D20

PS_DDR_DQ20_502

R20

DDR3_D21

PS_DDR_DQ21_502

T21

DDR3_D22

PS_DDR_DQ22_502

M21

DDR3_D23

PS_DDR_DQ23_502

R22

DDR3_D24

PS_DDR_DQ24_502

A20

DDR3_D25

PS_DDR_DQ25_502

U22

DDR3_D26

PS_DDR_DQ26_502

AA22

DDR3_D27

PS_DDR_DQ27_502

U21

DDR3_D28

PS_DDR_DQ28_502

W22

DDR3_D29

PS_DDR_DQ29_502

W20

DDR3_D30

PS_DDR_DQ30_502

V20

DDR3_D31

PS_DDR_DQ31_502

Y22

DDR3_DM0

PS_DDR_DM0_502

B22

DDR3_DM1

PS_DDR_DM1_502

H20

DDR3_DM2

PS_DDR_DM2_502

P22

DDR3_DM3

PS_DDR_DM3_502

AA21

DDR3_A0

PS_DDR_A0_502

M19

DDR3_A1

PS_DDR_A1_502

M18

DDR3_A2

PS_DDR_A2_502

K19

DDR3_A3

PS_DDR_A3_502

L19

DDR3_A4

PS_DDR_A4_502

K17

DDR3_A5

PS_DDR_A5_502

K18

DDR3_A6

PS_DDR_A6_502

J16

DDR3_A7

PS_DDR_A7_502

J17

DDR3_A8

PS_DDR_A8_502

J18

DDR3_A9

PS_DDR_A9_502

H18

DDR3_A10

PS_DDR_A10_502

J20

DDR3_A11

PS_DDR_A11_502

G18

DDR3_A12

PS_DDR_A12_502

H19

DDR3_A13

PS_DDR_A13_502

F19

DDR3_A14

PS_DDR_A14_502

G19

Indice

Altri manuali Alinx Scheda madre

Alinx

Alinx ARTIX-7 FPGA Manuale utente

Alinx

Alinx KINTEX-7 FPGA Manuale utente

Alinx

Alinx ZYNQ7000 FPGA Manuale utente

Alinx

Alinx ZYNQUltraScale+ AXU3EGB Manuale utente

Alinx

Alinx Zynq UltraScale+MPSoC Manuale utente

Alinx

Alinx AX516 Manuale utente

Alinx

Alinx ZYNQ UltraScale+ Manuale utente

Alinx

Alinx AX7202 Manuale utente

Alinx

Alinx ACU3EG Manuale utente

Alinx

Alinx AXU4EVB-E Manuale utente

Alinx

Alinx ZYNQ UltraScale+ AXU2CG-E Manuale utente

Alinx

Alinx AXU4EV-E Manuale utente

Alinx

Alinx ZYNQ UltraScale+ Manuale utente

Alinx

Alinx AXKU041 Manuale utente

Alinx

Alinx ZYNQ7000 FPGA Manuale utente

Alinx

Alinx AC7200 Manuale utente

Alinx

Alinx ZYNQ UltraScale+ AXU9EGB Manuale utente

Alinx

Alinx ZYNQ7000 FPGA Manuale utente

Alinx

Alinx AX301 Manuale utente

Alinx

Alinx AX7035 Manuale utente

Alinx

Alinx AXU2CGB-E Manuale utente

Alinx

Alinx KINTEX UltraScale FPGA AXKU042 Manuale utente

Alinx

Alinx AV4040 Manuale utente

Alinx

Alinx AXKU040 Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente
