Allied Telesis AT-GS900/8 Manuale utente

Allied Telesis www.alliedtelesis.com

AT-GS900/8

Unmanaged Gigabit Ethernet Switch

Datasheet | Switches

T-GS900/8

8port 10/100/1000T unmanaged switch

High Performance

Designed for medium enterprises and

educational networks, the Allied Telesis GS900

series of unmanaged Gigabit switches delivers

the high-speed and high-performance

demanded by today’s high-bandwidth

applications such as video, graphics, and

industrial design.

Flexibility

Available in 8, 16 and 24 port models, Allied

Telesis lets you decide which size is best for

your network. Reduces your cost by allowing

you to only pay for the ports you need.

Simplified Installation

The GS900 series switches require minimal

configuration and can be installed in minutes

for use in network racks or on desktops.The

10/100/1000T copper ports on the GS900

series are fully auto-negotiating, allowing the

switches to connect to all other 10Mbps

Ethernet, 100Mbps Fast Ethernet, or 1000Mbps

Gigabit Ethernet devices. Equipped with

MDI/MDI-X ports for easy connection to other

hubs and switches, the GS900 series offers

anatural migration path from legacy networks

and a cost-effective introduction to Gigabit

Ethernet. Finally, easy to read front panel LEDs

show ongoing switch status and simplify

troubleshooting.

Quality and Reliability

Allied Telesis is a worldwide leader in

unmanaged Ethernet switches. Shipping more

than 250,000 unmanaged switches every year,

Allied Telesis offers proven reliability and

industryrecognized quality.

Applications

Connected to managed Gigabit switches such

as the AT-9424T or the AT-9748TS/XP or

unmanaged Fast Ethernet switches such as the

AT-FS724L or the AT-LE700, the GS900 series

remains the ideal fit for Gigabit migration in

Local Area Networks (LANs).The GS900 series

of unmanaged Gigabit switches can

forward both standard sized packets and

VLAN-tagged packets throughout LANs. For

those applications requiring Gigabit to the

desktop, an ideal design combines Allied Telesis

GS900 series switches with any of our full line

of Gigabit Network Interface Cards (NICs) —

whether it’sthe AT-2916T for copper Gigabit or

the AT-2931SX for fiber Gigabit.

Key Features

•Wirespeed performance

•Non-blocking architecture

•Auto-negotiation Gigabit ports

•Auto MDI/MDI-X on TX ports

•Transparent to VLAN packets

•Full-duplex flowcontrol

•Sturdy metal case

•Silent operation, fanless

USA Headquarters |19800 North Creek Parkway |Suite 100 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2008 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-00572 Rev. D

AT-GS900/8 |Unmanaged Gigabit Ethernet Switch

Performance

14,880pps for 10Mbps Ethernet

148,800pps for 100Mbps Ethernet

1,488,000pps for 1000Mbps Ethernet

Switching capacity Up to 12Mpps

MAC addresses Up to 4K

Packet buffer 128KB

Half/full-duplex

Auto-negotiation

MDI/MDI-X

Interface Connections

10/100/1000T RJ-45

Power Characteristics

Voltage 100-240V AC

Frequency 50/60Hz

Current 0.3A

Power consumption max 15W

Environmental Specifications

Operating temp. 0°C to 40°C (32°F to 104°F)

Non-operating temp. -25°C to 70°C (-13°F to 158°F)

Operating humidity 5% to 90% non-condensing

Storage humidity 5% to 95% non-condensing

Technical Specifications

Physical Characteristics

Dimensions 3.8cm x 24.9cm x 11.4cm

(1.5” x 9.80” x 4.49”)

Weight .90kg (1.98lbs)

Wall-mount or Desktop

All units come with wall and 19" rack-mount brackets

Standards and Compliance

IEEE 802.3 10T Ethernet

IEEE 802.3u 100TX Fast Ethernet

IEEE 802.3ab 1000T Gigabit Ethernet

IEEE 802.3z Full-duplex

IEEE 802.3x Flow control

Electrical/Mechanical Approvals

UL 1950

FCC/EN55022 Class A

VCCI Class A

C-Tick

EN60950 (TUV)

EN55024

Ordering Information

AT-GS900/8

8port 10/100/1000T unmanaged switch

Where xx = 10 for U.S. power cord

20 for no power cord

30 for U.K. power cord

40 for Australian power cord

50 for European power cord
