Allied Telesis WebSmart AT-FS750/24 Manuale utente

Allied Telesis www.alliedtelesis.com

AT-FS750/24

24 port Fast Ethernet WebSmart Switch

Datasheet | Switches

T-FS750/24-xx

24 port 10/100TX Websmart switch

with 2 SFP/1000T combo ports

Performance

Allied Telesis’ WebSmartswitch integrates

the simplicity of unmanaged switches with the

performance and reliability of managed switches

to provide a cost-effectivesolution for users

to integrate management at the edge of their

network.This WebSmart switch provides a

network manager some key features using

the simple web-based management function

such as; port-based VLANs, IEEE 802.1p QoS,

porttrunking/link aggregation, port mirroring,

priority queues and IEEE 802.1x security

support. With support of up to 8K MAC

addresses and a 512K packet buffer the

AT-FS750/24 WebSmart switch is an ideal

option for integrating management into your

network solution.

Value

Never thought you could afford managed

switches in your network? Always wanted to

provide management functionality at the edge?

Now's your chance. Allied Telesis’ WebSmart

switch truelyhelps networkmanagersget the

most value for their dollar. With industry

standard protocols, fiber media support via

the SFP’s, and simple Plug & Play usability

right out of the box, how can you go wrong

implementing this cost-effective solution into

your network?

Quality and Reliability

Allied Telesis is a worldwide leader in

unmanaged Ethernet switches. Shipping more

than 250,000 unmanaged switches each year,

Allied Telesis offers proven reliability and

industry recognized quality.

Key Features

•24 10/100TX ports

•2SFP/1000Tcombo ports

•100FX SFP support

•Non-blocking architecture

•Auto MDI/MDI-X

•Web-based management

•IEEE 802.1x security

•Up to 8K MAC addresses

•Port-based VLANs (up to 64 groups)

•IEEE 802.1Q tagged

VLANs

•Link aggregation

•Port setting (speed, availability, flow control)

•Port trunking

•Port mirroring

•IEEE 802.1p QoS

•Login ID/password

•Statistics and diagnostics

•RS232 CLI interface

•Rack-mount kit

USA Headquarters |19800 North Creek Parkway |Suite 100 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2008 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000106 Rev. G

AT-FS750/24 |24 port Fast Ethernet WebSmart Switch

Performance

14,880pps for 10Mbps Ethernet

148,800pps for 100Mbps Ethernet

1,488,000pps for 1000Mbps Ethernet

MAC addresses 8K

Packet buffer 512KB

Flash 1M

Power Characteristics

Voltage 100-240V AC

Frequency 50/60Hz

Current 0.3A

Interface Connections

10/100TX RJ-45

1000FX (SFP) 1000SX or 1000LX

1000T RJ-45

Environmental Specifications

Operating temp. 0°Cto 40°C

(32°F to 104°F)

Non-operating temp. -25°C to 70°C

(-13°Fto 158°F)

Operating humidity 5% to 90% non-condensing

Storage humidity 5% to 95% non-condensing

Technical Specifications

Physical Characteristics

Dimensions 44cm x 25.7cm x 4.32cm

(17.3 x 10.1 x 1.7 in)

Weight 3.24 kg (7.15 lbs)

Wall-mount or Desktop

All units come with wall and 19” rack-mount brackets

Standards and Compliance

IEE E802.3 CSMA/CD

IEEE 802.3u 100TX

IEEE 802.3z 1000SX

IEEE 802.3z/ab 1000T

IEEE 802.3x Flow control

IEEE 802.1p Prioritization (four queues)

IEEE 802.1x Authentication

IEEE 802.1d Bridging

IEEE 802.3ad Link aggregation

IEEE 802.1Q Tagged VLAN

Electrical/Mechanical Approvals

UL 1950

FCC/EN55022 Class A

VCCI Class A

C-Tick

EN60950 (TUV)

EN55024

Ordering Information

AT-FS750/24-xx

24 port 10/100TX WebSmart switch

with 2 SFP/1000T combo ports

Where xx = 10 for US power cord

20 for no power cord

30 for UK power cord

40 for Australian power cord

50 for European power cord

Product Contents

Switch unit

RS232 cable

Rack-mount/wall-mount brackets and screws

Power cord

User manual/install guide on CD

Rubber feet
