ACM-4000 Installation And Operation Manual
DE-4000 Series Configurable Safety Shutdown and Control System
Form DE-4000 OCM 02-22
DE-4000 OCM 02-22
All rights reserved © ALTRONIC, LLC 2022 i
This manual contains information on the operation and configuration of a DE-4000 Safety Shutdown and
Control System. This manual supplements the DE-4000 Safety Shutdown and Control System Installation
Instructions, Form DE-4000 II.
DE-4000 OCM 02-22
All rights reserved © ALTRONIC, LLC 2022 ii
Table of Contents
ACM-4000 Installation And Operation Manual 1 ..................................................................................
OVERVIEW 1 ............................................................................................................................................
AFR-500 2 ................................................................................................................................................
DUAL BANK 2 .........................................................................................................................................
DE-4000 OCM 02-22
All rights reserved © ALTRONIC, LLC 2022 iii
DE-4000 OCM 02-22
All rights reserved © ALTRONIC, LLC 2022 iv
ACM-4000 Installation And Operation Manual
OVERVIEW
The Altronic Compute Module - 4000 (ACM-4000) is a device used for connectivity, graphical displays,
and high end computational power. It provides a flexible path to meet the demands of many applications.
24V Nominal Power
3 Ethernet Ports
2 HDMI Connectors
2 USB C
2 USB A
4 Isolated Relay Outputs
4 Digital Inputs
DE-4000 OCM 02-22
All rights reserved © ALTRONIC, LLC 2022 1
AFR-500
For full AFR-500 documentation this information can be found at AFR-500 Documentation
DUAL BANK
With an ACM-4000 mounted all that is required to use the ACM is input power to the board, and to
connect the ethernet ports of each AFR-500 board to any of the three ethernet ports on the ACM-4000. If
using a display, connect an HDMI cable from either of the HDMI ports on the ACM-4000 to the HDMI port
of the display. When the display is also a touch screen connect a USB cable from any of the USB ports on
the ACM-4000 to the USB port of the touch screen display.
From:
https://altronic.a2hosted.com/ - Documentation Wiki
Permanent link:
https://altronic.a2hosted.com/doku.php?id=documents:acm-4000
Last update: 2022/04/08 09:10
DE-4000 OCM 02-22
All rights reserved © ALTRONIC, LLC 2022 2
