SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE 8200-0181-04, REV. B

INSTALLATION GUIDE 1 of 10

SpeedDome®Optima LT

Camera Dome Indoor

Pendant Mounting

Structure

Installation Guide

FOR INDOOR USE ONLY!

Figure 1. Optima LT camera dome (in housing)

About this Guide

This guide explains how to prepare the camera

dome for installation to an indoor mounting

structure and assumes that the mounting structure

is in place and that data and power cables have

been pulled to the installation site.

This guide does not explain how to install the

mounting structure. For this information, see

information shipped with the mounting structure.

About the Indoor Housing

The indoor housing (Figure 1) is used to attach the

SpeedDome Optima LT camera dome to an indoor

mounting structure. This housing can attach to

mounting structures shown in Table 1.

Table 1. Indoor mounting structures

RHOPN

Pendant Mount

RHIUIBM

I-Beam Mount

RHOSW/RHOLW

Short/Long

Wall Mount

RHOWCA

Corner Mount

RHOWPA

Pole Mount

ROENDC

End Cap

SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE 8200-0181-04, REV. B

INSTALLATION GUIDE 2 of 10

Warnings and Cautions

Please review the following warnings and cautions

before you begin installation or service.

WARNINGS

WARNING!

ALWAYS USE:

• Proper safety equipment for the

location and type of installation.

• Proper lift equipment to reach the

installation.

• Safety features of the lift equipment.

BE SURE:

• Electrical power is not connected to

the dome when connecting wires.

Dome will move when power is

applied.

• Electrical power is not connected to

nearby fixtures that you might touch

during installation.

WARNING!

The camera dome used in this

housing runs on 24Vac. DO NOT

connect line voltage to this dome.

Worldwide power requirements: A

certified limited power source is required.

North America power requirements:

This device is intended to be supplied

from a Class 2 power supply.

This installation should be made by a

qualified service person and should

conform to all local codes.

WARNING!

DO NOT install this housing in

hazardous areas where highly

combustible or explosive products are

stored or used.

WARNING!

EU power requirements: This product

runs on 24Vac. In the EU, it is intended

to be powered from a Limited Power

Source. A limited power source is a

certified source of SELV, and if

inherently limited, with 8 amps maximum

output current, and a maximum of 100VA

available; or if not inherently limited,

fused with a maximum value of 3.3

Amps, meeting section 2.11 of IEC950,

and a maximum of 250VA available. The

power supply can be obtained through

Sensormatic or through another source

where the provider can furnish the

verification. This is required to assure

electrical safety in the product.

Stromanforderungen in der EU:

Dieses Produkt wird mit 24 V

Wechselstrom betrieben. In der EU ist es

für den Betrieb durch eine begrenzte

Stromquelle vorgesehen. Eine begrenzte

Stromquelle ist eine zertifizierte SELV-

Quelle (Schutzkleinspannung), bei

inhärenter Begrenzung mit einem

maximalen Ausgangsstrom von 8 A und

100 VA maximaler Verfügbarkeit, bei

nicht inhärenter Begrenzung mit einer

maximalen Sicherung von 3,3 A gemäß

Abschnitt 2.11 der IEC950 und 250 VA

maximaler Verfügbarkeit. Das Netzteil

kann über Sensormatic oder eine andere

Quelle bezogen werden, wobei der

Anbieter den Nachweis der Konformität

bereitstellen sollte. Dies ist zur

Gewährleistung der elektrischen

Sicherheit des Produktes erforderlich.

SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE 8200-0181-04, REV. B

INSTALLATION GUIDE 3 of 10

Before You Begin

To ensure a smooth and successful installation,

observe the following requirements.

General Requirements

• Have electrical work comply with latest national

electrical code, national fire code, and all

applicable local codes and ordinances.

• Coordinate work with other trades to avoid

interference.

• Verify existing site conditions and coordinate

with the owner’s representative and appropriate

utilities as required.

• Obtain copies of all related plans, specifications,

shop drawings and addenda to schedule and

coordinate related work.

• Thoroughly review the project to ensure that all

work meets or exceeds the above requirements.

Bring alleged discrepancies to the attention of

the CCTV Project Coordinator.

Mounting Requirements

Structural members: Verify that ceiling members

can support the camera dome and mounting

structure, if used.

Weight: 2.5kg (5.5 lbs)

Cable Requirements

Data cables: Table 2 shows cable requirements

for SensorNet and Manchester networks. For more

information about communication protocols and

cable networks, see Communication Protocols and

Cable Networks, 8000-2573-19.

Table 2. Data cable requirements

SensorNet RS-422

Simplex

Manchester

Cable type 1

unshielded,

twisted

pair*

1 shielded,

twisted

pair*, **

shielded

twisted

pair***

Wire gauge 22 AWG 22AWG 18 AWG

Connection Non-

polarized

Polarized Polarized

Max.

devices per

cable run

32 10 3

* Power, data, and video cables can be ordered

separately or within a composite cable that can be

ordered in various lengths. Plenum-rated cables must

be used in indoor ceilings used for environmental air

return (called "other air space" in the National

Electrical Code). Order parts through your distribution

network.

Note: If you order cable from an outside source, wire

colors may be different.

** The RS-422 Simplex connection only uses a single

twisted pair allowing the dome to receive only.

RS-422 transmit from the dome is not supported.

*** Belden 88760 (plenum), or Belden 8760 cable (non-

plenum) cable is recommended. Plenum-rated cables

must be used in indoor ceilings used for

environmental air return (called "other air space" in

the National Electrical Code). Order cable

directly from Belden by calling 1-800-235-3361.

WARNING! Do not run cables adjacent

to or in the same conduit as line voltage

mains power.

Power cables. Make power cable lengths as short

as possible to minimize the affects of low line

voltages and outdoor cold temperature perform-

ance. Maximum cable length between a Class 2

LPS (low voltage) ac source, such as a J-box, and

the dome depends on the ac line voltage. See the

tables below for maximum cable lengths based on

the worst-case low line voltages.

The line voltage must not go below the voltage

shown for the dome to be able to power up and

operate at the corresponding distances shown.

Typically cable distances are used that provide a

15% margin between nominal and low line

conditions. For example, if the nominal voltage

measures 120Vac, restrict the cable length to the

distance for 0.85 x 120 or approximately 100Vac.

SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE 8200-0181-04, REV. B

INSTALLATION GUIDE 4 of 10

Power cable requirements

Table 3 shows the maximum cable distance for

several worst-case low line voltages between

various indoor power sources and the indoor

SpeedDome Optima LT camera dome. These

distances are for Sensormatic composite cables,

which use 18 AWG ac power wires.

Table 3. Power cable requirements

Indoor Dome Worst-Case Meters

AC Power Source Low Line V (Feet)

28 VA 117 130 (425)

Transformer 100 80 (250)

5604-0006-01 90 60 (200)

50 VA 117 160 (525)

Transformer 100 100 (325)

5604-0044-01 90 60 (200)

1-position SensorNet 117 160 (525)

RJ1SNUD 100 100 (325)

90 80 (250)

1-position SensorNet 240 160 (525)

RJ1SNUD-1 200 100 (325)

180 80 (250)

117 210 (675)

6-position SensorNet 100 130 (425)

Indoor J-Box 90 80 (250)

RJ6SN 240 210 (675)

200 130 (425)

180 80 (250)

Universal Transformer 117 130 (425)

0300-0914-01 100 100 (325)

90 60 (200)

Universal Transformer 240 160 (525)

0300-0914-03 200 100 (325)

180 80 (250)

SensorNet Line Termination

SensorNet communication protocols require line

termination. Accessing slide switch S1 through the

hole in the top of the dome, terminate the dome

furthest from the video controller or junction box by

moving the switch to the “terminated” position. All

other domes along the line must be unterminated.

Manchester and RS-422 protocols do not require

line termination.

Setting the Camera Address

At the top of the dome are rotary switches SW1,

SW2, and SW3 used to set the dome address.

Protocol address ranges are as follows:

SensorNet 1-255

Manchester 1-64

RS-422 1-99

For example, for address 107, set SW3 to 1, SW2

to 0 (black dot), and SW1 to 7.

Compatibility with the VM96 Controller

If using a VM96 controller, the controller must be

Version 5.2 or higher.

Power-Up Routine

After power is connected to the dome, the dome

performs a homing routine. During the homing

process, the camera will pan and then either:

• Go to the start point of the “apple peel” pattern,

• If powered up once before, to the last position in

memory.

Once the camera stops, the camera is online and

is ready to be controlled.

Synchronizing Domes

To prevent picture rolling when switching from

camera to camera, all domes can be synchronized

to the ac source. A V-phase adjustment at the

control console enables the dome to sync to any

line phase.

Save Packaging Material

Should the camera dome need to be sent to a

repair center, use the packaging that the dome was

shipped in.

SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE 8200-0181-04, REV. B

INSTALLATION GUIDE 5 of 10

Procedure

Parts Supplied

Housing Assy. 1 0404-0103-01

Bubble Assembly, Clear/Smoked 1 0400-1402-01/-02

Chassis Assy., NTSC/PAL 1 0101-0075-01/-02

Install Kit 1 0352-0126-01

Connector, 3-Pos., Power 1 2109-0254-02

Connector, 2-Pos., Data 1 2109-0756-01

Purchase or Supply Separately

- Male BNC connector

- RULOB Indoor I/O Board

Tools Required

- 6mm (.25in) fixed-handle nut driver for Torx bit

- Small screwdriver for tightening connectors

- Wire cutters and strippers

WARNING! Turn power off at the source

before beginning this procedure.

The following steps refer to Figure 2 and Figure 3.

1. To expose connectors and settings at the top

of the dome assembly, loosen three captive

screws securing the dome to the housing,

press in the three latches, and remove the

dome from the housing.

2. Run cables exiting the mounting structure

down through the hole in the housing.

Figure 2. Screws and latches securing dome

assembly to housing

Figure 3. Optima LT connections and switches

Set the camera address.

s an example, address

107 is shown.

Address Switches

Ter m in a t e d

Un-Terminated

Line

Termination

Switch

(S1)

x100 x10 x1

SW3 SW2 SW1

SensorNet / Manchester:

Switch 6 & 7 "On", all others "Off"

Off

7 6 5 4 3 2 1

Comm. Select (S2)

ideo

24Vac (P10)

Off

7 6 5 4 3 2 1

RS-422-Simplex:

Switch 6 & 7 "Off", all others "On"

SNet 1 - No Polarity

2 - No Polarity

Manch. 1 - WHT

2 - BLK

Comm. (P9)

RS422 2 - Rx–

3. On the PC board, set switches SW1, SW2, and

SW3 for the camera address (example: 001–

016 for VM16, 001–096 for VM96).

4. If daisy-chaining domes, the dome furthest

from the video controller requires that switch

S1 remain in the “terminated” position (resistor

symbol). Set all other domes along the chain to

“un-terminated”.

5. Check DIP switch S2 for correct communica-

tions settings.

• For SensorNet and Manchester, ensure

switches 6 and 7 are “On”. Other switches

should be “Off”.

• For RS-422, ensure that switches 6 and 7

are “Off”. Other switches should be “On”.

6. Connect power and communications cables.

WARNING! Ensure power is off at

the source when connecting cables.

Otherwise, the dome will operate

during installation.

a. Remove 2.5-3.8cm (1–1.5in.) of jacket

from the ends of power and data cables.

b. Attach the orange 3-pin plug to the power

cable and the gray 2-pin plug to the

communications cable. Use a small

screwdriver to tighten the connector

screws. DO NOT over tighten connectors!

c. On the PC board, plug the orange 3-pin

plug into receptacle P10 and the gray 2-pin

plug into receptacle P9.

7. Attach a BNC connector to the video cable and

plug it into the video receptacle.

Screw (3)

Latch (3)

SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE 8200-0181-04, REV. B

INSTALLATION GUIDE 6 of 10

8. Push cables back into the mounting structure.

Then reinsert the dome assembly into the

housing unit it clicks in place and tighten the

three captive screws (Figure 2).

9. Apply power to the camera dome.

CAUTION:

Dome moves when power is applied.

Note: When power is applied, the dome

checks its function by performing a homing

routine during which the camera pans and then

either goes to the start point of the “apple peel”

pattern or if powered up once before, to the

last position in memory. Once the camera

stops, the camera is online and is ready to be

controlled.

Also, green, red, and yellow LEDs will light in

various patterns to indicate status. Typically,

you do not need to view these LEDs unless a

failure occurs during or after the routine. See

“Troubleshooting” for an explanation of the

LED patterns.

Referring to Figure 4.

10. Remove the bubble assembly from the

package and ensure the bubble is clean and

free of debris.

11. Attach the coiled lanyard from the bubble to

the threaded stud on the housing using the

thumbnut supplied.

12. Attach trim bubble assembly.

a. Discard the red “CAUTION: Remove slot

covers” tag. There is no need to remove

the slot covers for indoor applications.

b. Align the key on the inside of the bubble

assembly with the detent on the edge of

the housing.

CAUTION: To maintain the integrity

of the gasket seal between the

housing flange and the trim ring, do

not let the lanyard get caught

between these two pieces as you

secure the bubble assembly to the

housing.

c. Use the drive (taped inside bubble) to

tighten the four tamper-proof screws on the

bubble assembly. To compress the gasket

evenly, tighten each screw in clockwise

formation until slight resistance is felt, then

retighten each screw again in clockwise

formation until all screws are evenly tight.

13. See instructions for the mounting structure for

how to attach the housing assembly.

Figure 4. Attaching bubble assembly

(bottom view)

Sun Shield

Detent

Key

(inside

bubble

assy.)

Lanyard

Stud

Detent

SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE 8200-0181-04, REV. B

INSTALLATION GUIDE 7 of 10

Troubleshooting

If a failure cannot be easily fixed, send the dome to

a repair center.

No power (no LEDs light).

Check for power coming in from J-box or controller.

Homing routine does not complete.

Green, red, and yellow LEDs are visible through

small holes in the dome housing that surround the

camera yoke. After power up, LEDs light as shown

in Table 4:

Table 4. Dome status/LED response

GREEN

(DS1)

RED

(DS2)

YELLOW

(DS3)

PLD Loading

(approx. 20 sec)

On Off Off

Homing Process Off Blink On

Looking for Network* On Off On

Online Waiting for 1st

Command**

Blink Blink On

* If the dome remains in this state, it cannot locate the

SensorNet, RS-422, or Manchester network.

** The yellow LED remains on until it receives a PTZ movement

command, then goes off. Further PTZ commands will cause

the LED to blink; otherwise, the LED is off.

Connected to RS-422 but no communication.

Check RS-422 wiring by doing the following.

1. Set the dome address to 901; observe the

green, red, and yellow LEDs through the

housing.

LED Indication Cause

Yellow blinks Wiring OK.

Red flickers,

Green blinks*

RS-422 wired

backwards.

Red blinks.

Green flickers*

A wire is not

connected.

*Fix wiring.

2. Reset the dome to the desired address.

No video.

1. Check the video cable and its connection to

the dome. If not OK, fix or replace the cable.

2. Check the iris setting. Open iris or set to auto

iris.

3. If the problem cannot be corrected, send the

dome to a repair center.

Video rolls when switching cameras.

Perform V-phase adjustment at the controller.

Contrast or color off.

1. Check the iris setting. Open iris or set to auto

iris.

2. If the problem cannot be corrected, send the

dome to a repair center.

Pan control absent or improper, but other

control OK.

Send the dome to a repair center.

Tilt control absent or improper, but other

control OK.

1. Check tilt belt operation. Fix the belt if

necessary.

2. If the problem cannot be corrected, send the

dome to a repair center.

Zoom, focus, and iris control is absent.

Check the flex cable connecting the camera the

housing. If you see damage, send the dome to a

repair center.

Only some camera control (for example, zoom

and focus works, iris doesn’t).

Send the dome to a repair center.

Parts List for

Authorized Users

Only parts below can be ordered, and only by

authorized users. To become authorized, contact

your sales representative.

Table 5. Parts list

1 Bubble Assy. Clear 0400-1402-01

2 Bubble Assy. Smoked 0400-1402-02

3 Housing Assembly

SpeedDome Optima

Pendant

0404-0103-01

4 Chassis Assy. NTSC 0101-0075-01

5 Chassis Assy. PAL 0101-0075-02

6 T20 Tamperproof

Torx Bit

1400-0149-01

SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE 8200-0181-04, REV. B

INSTALLATION GUIDE 8 of 10

Specifications

Operation

Manual pan speed ..................1–50° per second

Target pan speed....................100° per second max.

Pan travel ...............................360° continuous, no end

stop

Manual tilt speed.....................1–50° per second.

Target tilt speed ......................50° per second max.

Tilt travel .................................>90°

Optical zoom...........................22X

Digital zoom............................11X

Bubble density ........................Clear, f0

Tilt/Pan accuracy ....................±0.5°

Zoom/Focus accuracy ............±0.5%

Quick View™ access ..............< 2 seconds to pan and tilt

position

< 3 seconds to full zoom

position

< 1 second focus on

VM16 and VideoManager

controllers

< 7 seconds focus on

VM96 and RV2715

controllers.

Synchronization ......................Automatically selected

Line locked .............................Remote V-phase

adjustment

Internal....................................Built-in sync generator

Program storage.....................256K bytes of electrically

programmable Flash

Memory

Data storage ...........................128kB of SRAM

Video output connector...........Female BNC

Product life..............................5 years operation

500,000 position changes

Color Camera Specifications

Type........................................Interline Transfer ¼" CCD

array

Scanning system ....................2:1 interlace

Horizontal resolution ............... 470 lines at center

Video out ................................1.0 Vp-p / 75 ohms

composite

Signal/Noise ...........................48dB (typical)

Minimum illumination ..............1.5 lux (20 IRE)

Gain control ............................Automatic (AGC)

White balance ........................ Through the Lens (TTL)

Automatic Tracing White

Balance (ATW)

NTSC version:

Pickup device.................. 768 (H) x 494 (V) pixels

Scanning ......................... 525 lines, 60 fields,

30 frames

Horizontal........................ 15.734 kHz

Vertical............................ 59.9Hz

PAL version:

Pickup device.................. 752 (H) x 582 (V) pixels

Scanning ......................... 625 lines, 50 fields,

25 frames

Horizontal........................ 15.625 kHz

Vertical............................ 50Hz

Lens

Design.................................... Aspherical

Focal length ........................... 4 to 64 mm

Aperture ................................. f1.4 (wide), f2.2 (tele)

Scanning area ........................ 3.2mm (H) x 2.4mm(V)

Viewing angle:

4 mm............................... 47.0°H x 35.2°V

48 mm............................. 4.0°H x 2.25°V

Field-of-View Formulas:

3.2 mm* x distance from camera (m)

Focal length (mm) = Horizontal view (m)

2.4 mm** x distance from camera (m)

Focal length (mm) = Vertical view (m)

* Horizontal scanning area of pickup device (mm) in camera.

** Vertical scanning area of pickup device (mm) in camera.

Example: Wide angle view with lens at 6mm and viewed

object at 10m.

3.2mm x 10m

6mm = 5.33m Horizontal view (m)

2.4mm x 10m

6mm = 4.0m Vertical view (m)

SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE 8200-0181-04, REV. B

INSTALLATION GUIDE 9 of 10

Electrical Specifications

Power Line

Input voltage ....................... 18–30Vac,

Class 2

Certified Limited

Power Source

Design tolerance................. 16–36Vac

Line frequency .................... 50/60Hz

Power consumption ............ 21W max.

Power on inrush current...... 3A

Allowable drop out: ............. 33ms

Connector: .......................... Plug-in Euro-style terminal

block 5.08mm

Max. cable distance ............ See chart on page 4.

Surge Protection

Video output ....................... Gas discharge tube rated at:

• 8/20µs impulse

discharge current:

10kA

• Ten 8/20µs impulses

discharge current:

5kA

• 3.9 ohm series

resistors

• Low capacitance

Zener suppressor

6.5V 1500W

Power line........................... Gas discharge tube rated at:

• 8/20µs impulse

discharge current:

10kA

• Ten 8/20µs impulses

discharge current:

5kA

• TVS rated at 60V,

250A, 1.5 Joules,

8/20µs impulse

SensorNet/Manchester ....... Gas discharge tube rated at:

• 8/20µs impulse

discharge current:

10kA

• Ten 8/20µs impulses

discharge current:

5kA

• Isolation transformer

coupled, 2000Vrms

• PTC resettable fuse

protects transformer

• TVS rated at 5.6V,

40A, 0.1 Joules,

8/20µs impulse

EIA-422 comm .......Gas discharge tube impulse rated at:

• 8/20µs Impulse

discharge current: 10kA

• Ten 8/20 µs Impulses

Discharge Current: 5kA

• 33 ohm series resistors

• TVS rated at 5.6V, 40A,

0.1 Joules, 8/20µs

impulse

SensorNet Communications

Address range.....................0 to 255

Network distance.................1 km

Maximum loads ...................32 per node

Node repeaters ...................SensorNet junction boxes

Cable topologies .................Daisy chain

Backbone

Star

Transmission medium .........Single non-polarized

unshielded twisted pair UTP

22AWG

Wire configuration ...............Single unshielded twisted

pair UTP 22AWG non-

polarized

Connector: ..........................Plug-in Euro-style terminal

block 5.08mm

Terminating resistor ...........120 ohms, switch selectable

EIA-422 Communications

Address range....................................................... 1 to 99

Network Distance ...................................................... 1km

Maximum Loads.................................................. 10/node

Cable topologies ............................................Daisy chain

Star

Wire configuration ....................One twisted pair 22AWG,

polarized, shielded

Connector ............................................Plug-in Euro-style

terminal block 3.81mm

Manchester Communications

Address range.....................1 to 64

Network distance.................1.5 km

Maximum loads ...................32 per node

Node repeaters ...................SensorNet junction boxes

Cable topology ....................Daisy chain

Transmission medium .........Single polarized twisted pair

18AWG (Beldon 8760)

Connector ...........................Plug-in Euro-style terminal

block 5.08mm

Terminating resistor ...........120 ohms, switch selectable

SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE 8200-0181-04, REV. B

INSTALLATION GUIDE 10 of 10

Mechanical Specifications

Camera Dome

Housing diameter....................190mm (7.5in)

Housing height

(above ceiling) ........................210mm (8.26in)

Bubble diameter......................178mm (7.0in)

Bubble depth

(below ceiling).........................94mm (3.7in)

Weight ....................................2.7kg (5.9 lbs)

Environmental Specifications

Operating temperature:

Indoor .....................................–10°C to 50°C

(14°F to 122°F)

Humidity..................................0–95% non-condensing

Storage temperature...............–20°C to 65°C

(–4°F to 149°F)

Declarations

Regulatory Compliance

REG ID: SV SDUW

Emissions ...............................47 CFR, Part 15

EN 50130-4

ICES-003

EN 55022

Safety .....................................UL1950

CSA C22.2 No 950

EN 60 950

FCC COMPLIANCE: This equipment complies with Part 15

of the FCC rules for intentional radiators and Class A digital

devices when installed and used in accordance with the

instruction manual. Following these rules provides reasonable

protection against harmful interference from equipment

operated in a commercial area. This equipment should not be

installed in a residential area as it can radiate radio frequency

energy that could interfere with radio communications, a

situation the user would have to fix at their own expense.

EQUIPMENT MODIFICATION CAUTION: Equipment

changes or modifications not expressly approved by

Sensormatic Electronics Corporation, the party responsible for

FCC compliance, could void the user's authority to operate the

equipment and could create a hazardous condition.

Other Declarations

Thank you for using American Dynamics products. We support

our products through an extensive and worldwide network of

dealers. The dealer, through whom you originally purchased

this product, is your point of contact if you have a need for

service or support. Our dealers are fully empowered to provide

the very best in customer service and support. Dealers should

contact American Dynamics at (800) 507-6268 or

(561) 912-6259 or on the web at www.americandynamics.net.

WARRANTY DISCLAIMER: Sensormatic Electronics

Corporation makes no representation or warranty with respect

to the contents hereof and specifically disclaims any implied

warranties of merchantability or fitness for any particular

purpose.

NOTICE: The information in this manual was current when

published. The manufacturer reserves the right to revise and

improve its products. All specifications are therefore subject to

change without notice.

LIMITED RIGHTS NOTICE: For units of the Department

of Defense, all documentation and manuals were developed at

private expense and no part of it was developed using

Government Funds. The restrictions governing the use and

disclosure of technical data marked with this legend are set

forth in the definition of “limited rights” in paragraph (a) (15)

of the clause of DFARS 252.227.7013. Unpublished - rights

reserved under the Copyright Laws of the United States.

TRADEMARK NOTICE: American Dynamics and

Sensormatic are trademarks or registered trademarks of

Sensormatic Electronics Corporation. Other product names

mentioned herein may be trademarks or registered trademarks

of Sensormatic or other companies.

manual may not be copied, photocopied, reproduced,

translated or reduced to any electronic medium or machine-

readable form, in whole or in part, without prior written

consent of Sensormatic Electronics.

MDR (bsl) 5/04

Altri manuali per SpeedDome Optima LT

Indice

Altri manuali American Dynamics Telecamera di sicurezza

American Dynamics

American Dynamics SpeedDome Ultra Manuale

American Dynamics

American Dynamics illustra 600 Istruzioni operative originali

American Dynamics

American Dynamics IP speedDome Ultra 8 Manuale

American Dynamics

American Dynamics Illustra Flex Series Manuale utente

American Dynamics

American Dynamics IP speedDome Ultra 8 Manuale

American Dynamics

American Dynamics ADSDUPIHC Manuale utente

American Dynamics

American Dynamics SensorRail IIIe ADRL3TRK Series Manuale utente

American Dynamics

American Dynamics SpeedDome Ultra VII Manuale utente

American Dynamics

American Dynamics ADCDW Series Manuale utente

American Dynamics

American Dynamics SpeedDome Optima LT Manuale utente

American Dynamics

American Dynamics illustra 400 Manuale utente

American Dynamics

American Dynamics ADCDH Manuale utente

American Dynamics

American Dynamics ADC722WP Manuale utente

American Dynamics

American Dynamics SpeedDome RHODULP-01 Istruzioni di installazione e manutenzione

American Dynamics

American Dynamics ADCIPE3312ISN Manuale utente

American Dynamics

American Dynamics SpeedDome Ultra VIIE Istruzioni di installazione e manutenzione

American Dynamics

American Dynamics ADCSHR2412N Manuale utente

American Dynamics

American Dynamics AD615 Manuale utente

American Dynamics

American Dynamics SpeedDome Optima LT Manuale utente

American Dynamics

American Dynamics RASO series Manuale utente

American Dynamics

American Dynamics Illustra Flex Series ADCi600F-W012** Manuale utente

American Dynamics

American Dynamics SpeedDome Ultra VI Istruzioni di installazione e manutenzione

American Dynamics

American Dynamics SpeedDome RASEL Series Istruzioni di installazione e manutenzione

American Dynamics

American Dynamics illustra 600 Manuale utente

Manuali Telecamera di sicurezza popolari di altre marche

Okina USA

Okina USA SIR36-870VF650LP Manuale utente

Divio

Divio NDR155PA Manuale utente

Canon

Canon VB-C500D Manuale utente

Easy Access

Easy Access EasyGuard Manuale utente

Vivotek

Vivotek FD9389-EHV-v2 Manuale utente

TUYA

TUYA COSMO W2 Manuale utente

Eusso

Eusso UNC7500-IR Guida all'installazione

urmet domus

urmet domus 1096/204 Manuale utente

VC VC20 series Manuale utente

Axis

Axis Q1614 Manuale utente

ieGeek

ieGeek DD201 Manuale utente

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuale utente

Vicon

Vicon V662-D-1 Istruzioni operative

Grundig

Grundig GCH-K0274P Manuale utente

Lorex

Lorex VANTAGE LBC7032 Manuale utente

4xem

4xem WPT Manuale utente

Samsung

Samsung SCV-3082 Manuale utente

Vitek

Vitek VTC-C544 Manuale utente
