Analog Devices EZ-KIT Lite ADSP-BF537 Manuale utente

ADSP-BF537 EZ-KIT Lite®

Evaluation System Manual

Revision 2.5, July 2012

Part Number

82-000865-01

Analog Devices, Inc.

One Technology Way

Norwood, Mass. 02062-9106

ment may not be reproduced in any form without prior, express written

consent from Analog Devices, Inc.

Printed in the USA.

Disclaimer

Analog Devices, Inc. reserves the right to change this product without

prior notice. Information furnished by Analog Devices is believed to be

accurate and reliable. However, no responsibility is assumed by Analog

Devices for its use; nor for any infringement of patents or other rights of

third parties which may result from its use. No license is granted by impli-

cation or otherwise under the patent rights of Analog Devices, Inc.

Trademark and Service Mark Notice

The Analog Devices logo, Blackfin, CrossCore, EngineerZone,

EZ-Extender, EZ-KIT Lite, and VisualDSP++ are registered trademarks of

Analog Devices, Inc.

All other brand and product names are trademarks or service marks of

their respective owners.

Regulatory Compliance

The ADSP-BF537 EZ-KIT Lite is designed to be used solely in a labora-

tory environment. The board is not intended for use as a consumer end

product or as a portion of a consumer end product. The board is an open

system design which does not include a shielded enclosure and therefore

may cause interference to other electrical devices in close proximity. This

board should not be used in or near any medical equipment or RF devices.

The ADSP-BF537 EZ-KIT Lite has been certified to comply with the

essential requirements of the European EMC directive 89/336/EEC

amended by 93/68/EEC and therefore carries the “CE” mark.

The ADSP-BF537 EZ-KIT Lite has been appended to Analog Devices,

Inc. Technical Construction File (TCF) referenced ‘DSPTOOLS1’ dated

December 21, 1997 and was awarded CE Certification by an appointed

European Competent Body as listed below.

Technical Certificate No: Z600ANA1.021

Issued by: Technology International (Europe) Limited

60 Shrivenham Hundred Business Park

Shrivenham, Swindon, SN6 8TY, UK

The EZ-KIT Lite evaluation system contains ESD (electrostatic discharge)

sensitive devices. Electrostatic charges readily accumulate on the human

body and equipment and can discharge without detection. Permanent

damage may occur on devices subjected to high-energy discharges. Proper

ESD precautions are recommended to avoid performance degradation or

loss of functionality. Store unused EZ-KIT Lite boards in the protective

shipping package.

ADSP-BF537 EZ-KIT Lite Evaluation System Manual v

CONTENTS

PREFACE

Product Overview ......................................................................... xi

Purpose of This Manual .............................................................. xiii

Intended Audience ....................................................................... xiv

Manual Contents ......................................................................... xiv

What’s New in This Manual .......................................................... xv

Technical Support ......................................................................... xv

Supported Processors .................................................................... xvi

Product Information .................................................................... xvi

Analog Devices Web Site ........................................................ xvi

EngineerZone ........................................................................ xvii

Related Documents .................................................................... xviii

Notation Conventions ................................................................ xviii

USING THE ADSP-BF537 EZ-KIT LITE

Package Contents .......................................................................... 1-3

Default Configuration ................................................................... 1-3

CCES Install and Session Startup .................................................. 1-4

Session Startup ........................................................................ 1-6

Contents

vi ADSP-BF537 EZ-KIT Lite Evaluation System Manual

VisualDSP++ Install and Session Startup ....................................... 1-8

CCES Evaluation License ........................................................... 1-10

VisualDSP++ Evaluation License ................................................. 1-11

Memory Map ............................................................................. 1-11

SDRAM Interface ....................................................................... 1-13

Flash Memory ............................................................................ 1-15

CAN Interface ............................................................................ 1-15

Ethernet Interface ....................................................................... 1-16

ELVIS Interface .......................................................................... 1-17

Audio Interface ........................................................................... 1-17

LEDs and Push Buttons .............................................................. 1-18

Board Design Database ............................................................... 1-19

Example Programs ...................................................................... 1-19

ADSP-BF537 EZ-KIT LITE HARDWARE REFERENCE

System Architecture ...................................................................... 2-2

External Bus Interface Unit ..................................................... 2-3

SPORT0 Audio Interface ........................................................ 2-4

SPI Interface ........................................................................... 2-4

Programmable Flags (PFs) ....................................................... 2-4

UART Port ............................................................................. 2-7

Expansion Interface ................................................................. 2-7

JTAG Emulation Port ............................................................. 2-8

ADSP-BF537 EZ-KIT Lite Evaluation System Manual vii

Contents

Jumper and Switch Settings ........................................................... 2-9

CAN Enable Switch (SW2) ...................................................... 2-9

Ethernet Mode Select Switch (SW3) ...................................... 2-10

UART Enable Switch (SW4) .................................................. 2-11

Push Button Enable Switch (SW5) ......................................... 2-11

Flash Enable Switch (SW6) .................................................... 2-12

Audio Enable Switch (SW7) .................................................. 2-12

Boot Mode Select Switch (SW16) .......................................... 2-13

3V Power Selection Jumper (JP3) ........................................... 2-13

Expansion Interface Voltage Selection Jumper (JP5) ............... 2-14

UART Loop Jumper (JP9) ..................................................... 2-15

ELVIS Oscilloscope Configuration Switch (SW1) ................... 2-15

ELVIS Function Generator Configuration Switch (SW8) ........ 2-16

ELVIS Voltage Selection Jumper (JP6) ................................... 2-16

ELVIS Select Jumper (JP8) .................................................... 2-17

LEDs and Push Buttons .............................................................. 2-18

Reset Push Button (SW9) ...................................................... 2-18

Programmable Flag Push Buttons (SW10–13) ........................ 2-19

Power LED (LED7) ............................................................... 2-19

Reset LED (LED8) ................................................................ 2-19

User LEDs (LED1–6) ............................................................ 2-20

USB Monitor LED (ZLED3) ................................................. 2-20

Contents

viii ADSP-BF537 EZ-KIT Lite Evaluation System Manual

Connectors ................................................................................. 2-21

Audio Connectors (J9 and J10) ............................................. 2-22

CAN Connectors (J5 and J11) .............................................. 2-22

Ethernet Connector (J4) ....................................................... 2-22

RS-232 Connector (J6) ......................................................... 2-23

Power Connector (J7) ........................................................... 2-23

Expansion Interface Connectors (J1–3) .................................. 2-24

JTAG Connector (ZP4) ......................................................... 2-24

SPORT0 Connector (P6) ...................................................... 2-25

SPORT1 Connector (P7) ...................................................... 2-25

PPI Connector (P8) .............................................................. 2-25

SPI Connector (P9) ............................................................... 2-26

2-Wire Interface Connector (P10) ......................................... 2-26

TIMERS Connector (P11) .................................................... 2-26

UART1 Connector (P12) ...................................................... 2-27

ADSP-BF537 EZ-KIT LITE BILL OF MATERIALS

ADSP-BF537 EZ-KIT LITE SCHEMATIC

INDEX

ADSP-BF537 EZ-KIT Lite Evaluation System Manual ix

PREFACE

Thank you for purchasing the ADSP-BF537 EZ-KIT Lite®, Analog

Devices, Inc. evaluation system for Blackfin®processors.

Blackfin processors embody a type of embedded processor designed specif-

ically to meet the computational demands and power constraints of

today’s embedded audio, video, and communications applications. They

deliver breakthrough signal-processing performance and power efficiency

within a reduced instruction set computing (RISC) programming model.

Blackfin processors support a media instruction set computing (MISC)

architecture. This architecture is the natural merging of RISC, media

functions, and digital signal processing (DSP) characteristics. Blackfin

processors deliver signal-processing performance in a microprocessor-like

environment.

Based on the Micro Signal Architecture (MSA), Blackfin processors com-

bine a 32-bit RISC instruction set, dual 16-bit multiply accumulate

(MAC) DSP functionality, and 8-bit video processing performance that

had previously been the exclusive domain of very-long instruction word

(VLIW) media processors.

x ADSP-BF537 EZ-KIT Lite Evaluation System Manual

The evaluation board is designed to be used in conjunction with the

CrossCore®Embedded Studio (CCES) and VisualDSP++®development

environments to test the capabilities of the ADSP-BF537 Blackfin proces-

sors. The development environment gives you the ability to perform

advanced application code development and debug, such as:

• Create, compile, assemble, and link application programs written

in C++, C, and ADSP-BF537 assembly

• Load, run, step, halt, and set breakpoints in application programs

• Read and write data and program memory

• Read and write core and peripheral registers

• Plot memory

Access to the ADSP-BF537 processor from a personal computer (PC) is

achieved through a USB port or an optional JTAG emulator. The USB

interface gives unrestricted access to the ADSP-BF537 processor and the

evaluation board peripherals. Analog Devices JTAG emulators offer faster

communication between the host PC and target hardware. Analog Devices

carries a wide range of in-circuit emulation products. To learn more about

Analog Devices emulators and processor development tools, go to

http://www.analog.com/dsp/tools.

The ADSP-BF537 EZ-KIT Lite provides example programs to demon-

strate the capabilities of the evaluation board.

Altri manuali per EZ-KIT Lite ADSP-BF537

Indice

Altri manuali Analog Devices Hardware per computer

Analog Devices

Analog Devices EVAL-ADA4351-2 Manuale utente

Analog Devices

Analog Devices ADM8611 Manuale utente

Analog Devices

Analog Devices SHARC ADSP-2136 Series Guida all'applicazione

Analog Devices

Analog Devices ADSP-SC573 EZ-KIT Manuale utente

Analog Devices

Analog Devices Blackfin ADSP-BF537 Guida all'applicazione

Analog Devices

Analog Devices EVAL-ADA4570SDZ Manuale utente

Analog Devices

Analog Devices ADRV902 Series Manuale utente

Analog Devices

Analog Devices EVAL-LTC7067-AZ Manuale utente

Analog Devices

Analog Devices LTC3728EG Manuale utente

Analog Devices

Analog Devices Blackfin Audio EZ-Extender Manuale utente

Analog Devices

Analog Devices ADAV4622 Manuale utente

Analog Devices

Analog Devices AD9883A Manuale utente

Analog Devices

Analog Devices EVAL-ADAU1772Z Manuale utente

Analog Devices

Analog Devices ADSP-BF535 Blackfin Guida all'applicazione

Analog Devices

Analog Devices EZ-KIT Lite ADSP-BF537 Manuale utente

Analog Devices

Analog Devices EVAL-ADPA1106 Manuale utente

Analog Devices

Analog Devices ADuCM355 Guida rapida

Analog Devices

Analog Devices EVAL-ADN4650EB1Z Manuale utente

Analog Devices

Analog Devices SHARC Series Manuale utente

Analog Devices

Analog Devices EVAL-ADAQ8088EBZ Manuale utente

Analog Devices

Analog Devices MAX77831 Manuale utente

Analog Devices

Analog Devices SHARC ADSP-21367 Manuale utente

Analog Devices

Analog Devices ICE-100B Manuale utente

Analog Devices

Analog Devices Blackfin Manuale utente

Manuali Hardware per computer popolari di altre marche

EMC2

EMC2 VNX Series Manuale del proprietario

Panasonic

Panasonic DV0PM20105 Manuale utente

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuale utente

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuale utente

Raidon

Raidon iT2300 Manuale utente

National Instruments

National Instruments PXI-8186 Manuale utente

Hauppauge

Hauppauge WinTV-HVR-2250 Manuale utente

Kontron

Kontron CP6002 Manuale utente

Manhattan

Manhattan 702843 Manuale utente

Aphex

Aphex 230 Manuale utente

AMD

AMD Phenom II Manuale operativo

Intel

Intel NUC 12 Pro Manuale utente

dbx

dbx Zone Pro 1260 Manuale utente

Galaxy

Galaxy GHDX2-2430S-24F4D Manuale utente

Intel

Intel AXXRMFBU4 Manuale utente

Kontron

Kontron DIMM-PC/MD Manuale utente

ST X-NUCLEO-SAFEA1B Istruzioni operative

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuale utente
