Anker Soundcore Motion Plus Manuale utente
User Manual
Soundcore Motion+
Benutzerhandbuch | Manual del usuario | Manuel de l'utilisateur
Manuale utente | Manual do Usuário | 取扱説明書 | 칺푷컲졓컪
欽䨪䩛ⱃ | ⢪欽䩛ⱁ | Руководство пользователя
ϡΩΧΗγϣϟϝϳϟΩ | ʹʮʺʹʮʬʪʩʸʣʮ
01 English
EN
Safety Instructions
• Avoid dropping.
• Do not disassemble.
• Soundcore Motion+ can be immersed in water up to 1m for up to 30 minutes.
• Avoid extreme temperatures.
• Do not use the device outdoors during thunderstorms.
• Do not use any corrosive cleaner / oil to clean.
What’s Included
English 02
EN
At a Glance
1Bass Indicator
Bass indicator
color White
2Bass Button
3Volume - Button
4Multi-function Button
5Volume + Button
6Bluetooth Button
7Bluetooth Indicator
Bluetooth indicator
color Blue / White
8Power Button / Power Indicator
Power indicator color Red / White
USB Type C Port
3.5mm Audio Input Port
03 English
EN
Using Your Soundcore Motion+
1. Turn On / O
ON Press once
OFF Press and hold for 2 seconds
Soundcore Motion+ is equipped with High-Resolution Audio. This specialty gives
the speaker a better sound quality by referring to digital processes that allow
playback of music using higher sampling rates.
Note: Soundcore Motion+ supports Qualcomm® aptX™.
English 04
EN
a. Bluetooth mode
Slowly Flashing Blue
(Fade in and out)
Bluetooth Pairing Mode
Note: starts to connect to previous connected
mobile device when speaker is turned on.
Solid Blue Connected to a device
05 English
EN
Enter True Wireless Stereo Group Mode / Disconnect True Wireless
Stereo
Slow Flashing White True Wireless Stereo Group Mode
Solid White（Secondary speaker）Connected to True Wireless Stereo
Solid Blue（Primary speaker)
With True Wireless Stereo technology, you can pair your Soundcore Motion+
with another Soundcore Motion+ to explore the best sound eects with le
and right sound channels separated on both speakers.
6
Music
Play / Pause
Play Next Song
Play Previous Song
Press to turn Bass on
English 06
EN
Press once to activate bass
Note: Press again to switch back to Normal Equalizer.
Activate Siri / Other Voice Control Soware
Volume Up / Down
Mobile phone
Answer Call / End Call
Reject Call / Switch between a call on hold and an active call
End current call and answer incoming call / End current call and switch
to call on hold
Switch audio source between Speaker and Phone
Solid Blue On a Call
Flashing Blue Incoming Call
When turned on, Soundcore Motion+ will automatically connect to the
last connected device if available. If not, press the Bluetooth button to
activate pairing mode.
To pair a dierent device, press the Bluetooth button to re-enter pairing
mode. Then repeat the pairing steps.
Having connection problems? Remove Soundcore Motion+ from your
device’s Bluetooth history and ensure it’s less than 3 feet away. Then try
pairing again. To get the best sound quality, make sure there is a clear
line of sight between the connected device and your speaker.
6
07 English
EN
b. AUX-In mode
Plugging in an audio cable will automatically switch to AUX mode.
When using AUX mode, control audio playback via the connected
device.
6
Charging your Soundcore Motion+
English 08
EN
Slow Flashing Red Low Battery
Solid Red Charging
O Fully Charged
Use the included USB cable to charge your Soundcore Motion+ and
make sure it is fully charged before its first use.
USB type C cable only supports charge in, it does not support charge
out.
Disconnect your speaker from the charger when fully charged. Do not
charge your speaker for extended periods.
When not in use, store your speaker in a cool place.
6
Specifications
Specifications are subject to change without notice.
6
Input: 5 V 2 A
Audio output: 30 W
Battery capacity : max.6700mAh
Charging time : Approximately 4 hours(When power is o and the adapter must
be at least 5V/2A)
Playtime (varies by volume level and music content): 12 hours
Size: 257 x 79 x 81 mm / 10.1 x 3.1 x 3.2 inch
Weight (without packaging): 1050 g / 37 oz
Bluetooth version: V 5.0
Bluetooth range: 30m/99
Sound Frequency Range: 50Hz~40kHz
09 English
EN
Soundcore App
