Aplex VIKING-9 B Series Manuale utente

VIKING-9XXB Series

12.1”/19”/24” Intel 8th Core i3/i5 Marine Panel PC

User Manual

Release Date Revision

Jan 2024 V1.0

Aplex Technology, Inc.

15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235,Taiwan

Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com

URL: www.aplex.com.tw

VIKING-9XXB Series User Manual

Revision History

Reversion

Date

Description

1.0

2024/01/05

Official Version

VIKING-9XXB Series User Manual

Warning!________________________

Caution

Risk of explosion if the battery is replaced with an incorrect type.

Batteries should be recycled where possible. Disposal of used batteries must be in

accordance with local environmental regulations.

Electric Shock Hazard –Do not operate the machine with its back cover removed.

There are dangerous high voltages inside.

This equipment generates, uses and can radiate radio frequency energy and

if not installed and used in accordance with the instructions manual, it may cause

interference to radio communications. It has been tested and found to comply

with the limits for a Class A computing device pursuant to FCC Rules, which are

designed to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a

residential area is likely to cause interference in which case the user at his own

expense will be required to take whatever measures may be required to correct

the interference.

VIKING-9XXB Series User Manual

Packing List

Accessories (as ticked) included in this package are:

□Adaptor

□Driver & manual CD disc

□Other.___________________(please specify)

VIKING-9XXB Series User Manual

Safety Precautions

Follow the messages below to prevent your systems from damage:

◆Avoid your system from static electricity on all occasions.

◆Prevent electric shock. Don‘t touch any components of this card when

the card is power-on. Always disconnect power when the system is not

in use.

◆Disconnect power when you change any hardware devices. For instance,

when you connect a jumper or install any cards, a surge of power may

damage the electronic components or the whole system.

VIKING-9XXB Series User Manual


Table of Contents
Revision History…………………………………………………………………………………………………….1
Warning!/Caution…………………….............................................…………………………….…2
Packing List…………………………………….……………………………………………………………………..3
Safety Precautions…………………………………………………………………….…..……………………..4
Chapter 1 Getting Started
1 Features………………………..………………………...…………………………..8
2 Specifications…………………...………………………………………………….8
3 Dimensions………………………....…………………………………………….12
4 Brief Description of VIKING-9XXB Series………..…….……….……15
5 Yoke Mounting and VESA Mounting……………………………………16
Chapter 2 Hardware
1 Motherboard Introduction……………………...……………..………....17
2 Specifications…………………………..…………………………………………17
3 Jumpers and Connectors Location……………………………………...20
4 Jumpers Setting and Connectors…………………………………..……21
Chapter 3 BIOS Setup
1 System Test andInitialization.….....….……...…………………………40
2 AMI BIOS Setup…….…..……………………………………………………….41
3 Setup Submenu:Main…………….…………..………………………………42
4 Setup Submenu:Advanced.………………………………………………...42
5 Setup Submenu:Chipset….……………………….………………………...53
6 Setup Submenu:Security……….……………………….…………………..58
7 Setup Submenu:Boot….…………………………….……………………..62
8 Setup Submenu:Save & Exit………………………..…………………....63
Chapter 4 Installation of Drivers
1 Intel® 8th Generation Core Chipset………..…………….……………65
2 Intel® VGA Chipset……………………………………………….……........68
3 Intel® LAN Driver…….…………………………………..…………..……….71
4 Realtek Audio Driver……………………………………..…..……………..74
5 Intel Serial IO Driver………………………….……………………………..76
6 Resistive Touch  Driver……………………………………………………….79

VIKING-9XXB Series User Manual

Figures

Figure 1.1: Dimensions of VIKING-912BP(H)…………….…..……………………10

Figure 1.2: Dimensions of VIKING-919BP(H)……….….……….…………………11

Figure 1.3: Dimensions of VIKING-924BP(H)…………...….…..…………………12

Figure 1.4: Front View of VIKING-912BP(H)…………….……….…………………14

Figure 1.5: Rear View of VIKING-912BP(H)………………..……………………….14

Figure 1.6: Front View of VIKING-919BP(H)…………..…….……………………..15

Figure 1.7: Rear View of VIKING-919BP(H)…………..………………….……….15

Figure 1.8: Front View of VIKING-924BP(H)…..…….….……..…………….….16

Figure 1.9: Rear View of VIKING-924BP(H)………………….…………..………..16

Figure 1.10: VESA Mounting of VIKING-9XXB Series..............................16

Figure 2.1: Motherboard Dimensions………………………………………….…….19

Figure 2.2: Jumpers and Connectors Location-Board Top……………….….20

Figure 2.3: Jumpers and Connectors Location-Board Bottom…………..…20

VIKING-9XXB Series User Manual

Chapter 1 Getting Started

1.1 Features

⚫Intel® Core 8th Gen i3/i5 Processor

⚫12.1”/19”/24” TFT LCD

⚫Aluminum Enclosure (with Anti-Corrosion Coating)

⚫True Flat Bezel Design

⚫IP66 Front Panel

⚫1 x 260pin SO-DIMM, up to 32GB DDR4 2400MHz

⚫24V DC Power Input, isolated

⚫Meet CE/FCC/ IEC 60945

1.2 Specifications

VIKING-912BP/R(H)

VIKINGTAM-919BP/R(H)

VIKING-924BP(H)

System

CPU

Intel 8th Gen. Core i5-8365UE Processor(4C/8T, up to 1.60 GHz, 15W TDP)

Intel 8th Gen. Core i3-8145UE Processor(2C/4T, up to 2.20 GHz, 15W TDP)

Chipset

SoC

Memory

1 x 260-pin SO-DIMM up to 32GB DDR4 2400MHz

LVDS

18bit/24bit LVDS support

Outside IO Port –Front I/O

LED

1 x Power System LED (with Power Button ON/OFF)

Buzzer

Dimming Control

0.1%~100%

OSD Keypad

5-Keys OSD Capacitive Touch at front

Outside IO Port—Rear I/O

USB

4 x USB3.0 type A

Serial/Parallel

1 x RS-232 (COM1, 5 pin terminal block)

1 x RS-232/422/485 selectable (default RS-485) (COM2, 5pin terminal block, mode select

by BIOS setup.)

Display Port

1 x DP

Audio

1 x Line-out, phone jack

LAN

2 x GbE RJ-45

Power

1 x 2Pin terminal block connector (for remote power switch)

1 x 3pin terminal block connector

VIKING-9XXB Series User Manual

ESD

1 x ESD Ground

Storage Space

Storage

Default 1 x M.2 M-Key support 2242 SSD (2280 for option, can’t use TB-528 at the same

time)

1 x 2.5” HDD space (Option)

Expansion

Expansion Slot

1 x Full-size mPCIe slot onboard

1 x TB-528 expansion connector (CN3, for 19”/24”)

(option TB-528C2I for 2 x RS-422/485 isolation)

Display –Standard LCD

Display Type

12.1” TFT LCD

19”TFT LCD

24” TFT LCD

Max. Resolution

1024 x 768

1280 x 1024

1920 x 1080

Max. Color

16.7M

Luminance (cd/m2)

500

350

300

Contrast Ratio

1000:1

3000:1

Viewing Angle(H/V)

178/178

170/160

178/178

Backlight Lifetime

30,000hrs

50,000hrs

Option

Optical bonding

Display –High Brightness LCD (option)

Display Type

12.1” TFT LCD

19”TFT LCD

24” TFT LCD

Max. Resolution

1024 x 768

1280 x 1024

1920 x 1080

Max. Color

16.7M

Luminance (cd/m2)

1000

Contrast Ratio

3000:1

1000:1

5000:1

Viewing Angle(H/V)

176/176

170/160

178/178

Backlight Lifetime

70,000hrs

50,000hrs

Option

Optical bonding

Touch Screen

Type

Projected capacitive touch screen

Interface

USB

Light Transmission

Projected capacitive touch screen: over 90%

Power

Power Input

DC 24V/ 1 x 3pin terminal block connector by TB-323 (option AC 90~264V in)

Power Consumption

MAX: 50.88W-912BH

MAX: 52.85W-919BH

MAX: 69.94W-924BH

Mechanical

VIKING-9XXB Series User Manual

Construction

Black/Aluminum bezel and Aluminum housing (Anti-corrosion coating)

Mounting

Panel Mount/VESA mount

IP Rating

IP66/IP69K

Dimension (mm)

307 x 246 x 73.5

439 x 396 x 76.3

609 x 400 x 76.3

Net Weight

4.07 Kg

7.15 Kg

8.88 Kg

Environmental

Operating

temperature

0~50°C (-20~60°C for option)

Storage temperature

-30~70°C

Storage humidity

10 to 90% @ 40°C, non- condensing

Certification

Meet CE / FCC Class B / IEC 60945

IP Rating

Front Panel IP66 Design for Panel Mount

Operating System

Support

Windows 10 IoT ENT LTSC, Windows 11/Ubuntu 20.04
