ASROCK EPC602D8A Manuale utente

Version 1.1

Published July 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Rack Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished

for informational use only and subject to change without notice, and should not

be constructed as a commitment by ASRock Rack. ASRock Rack assumes no

responsibility for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock Rack does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable

for any indirect, special, incidental, or consequential damages (including damages

for loss of prots, loss of business, loss of data, interruption of business and the

like), even if ASRock Rack has been advised of the possibility of such damages

arising from any defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Rack’s Website: www.ASRockRack.com

Contact Information

If you need to contact ASRock Rack or want to know more about ASRock Rack,

you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you

may contact your dealer for further information.

ASRock Rack Incorporation

6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,

Taipei City 112, Taiwan (R.O.C.)

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 6

1.4 Motherboard Layout 7

1.5 I/O Panel 11

1.6 Block Diagram 13

Chapter 2 Installation 14

2.1 Screw Holes 14

2.2 Pre-installation Precautions 15

2.3 Installing the CPU 16

2.4 Installing the CPU Fan and Heatsink 19

2.5 Installation of Memory Modules (DIMM) 20

2.6 Expansion Slots (PCI and PCI Express Slots) 22

2.7 Jumper Setup 24

2.8 Onboard Headers and Connectors 25

2.9 Dr. Debug 32

2.10 Driver Installation Guide 33

2.11 Dual LAN and Teaming Operation Guide 34

Chapter 3 UEFI Setup Utility 35

3.1 Introduction 35

3.1.1 UEFI Menu Bar 35

3.1.2 Navigation Keys 36

3.2 Main Screen 37

3.3 OC Tweaker Screen 38

3.3.1 CPU Conguration 38

3.3.2 DRAM Timing Conguration 39

3.3.3 Voltage Conguration 40

3.3.4 Saving Current Settings as User Defaults 40

3.4 Advanced Screen 41

3.4.1 Easy RAID Installer 42

3.4.2 ACPI Conguration 43

3.4.3 Intel TXT(LT-SX) Conguration 44

3.4.4 WHEA Conguration 45

3.4.5 CPU Conguration 46

3.4.6 North Bridge Conguration 48

3.4.7 South Bridge Conguration 51

3.4.8 USB Conguration 53

3.4.9 ME Subsystem 54

3.4.10 Clock Generator Conguration 55

3.4.11 Storage Conguration 56

3.4.12 Super IO Conguration 58

3.4.13 Serial Port Console Redirection 59

3.4.14 Voltage Control 61

3.4.15 Instant Flash 62

3.5 H/W Monitor Screen (Hardware Health Event Monitoring) 63

3.6 Server Mgmt (Server Management) 65

3.7 Boot Screen 66

3.8 Security Screen 68

3.9 Exit Screen 69

3.10 Event Logs 70

Chapter 4 Software Support 72

4.1 Install Operating System 72

4.2 Support CD Information 72

4.2.1 Running The Support CD 72

4.2.2 Drivers Menu 72

4.2.3 Utilities Menu 72

4.2.4 Contact Information 72

Chapter 5 Troubleshooting 73

5.1 Troubleshooting Procedures 73

5.2 Technical Support Procedures 75

5.3 Returning Merchandise for Service 75

EPC602D8A / EPC602D8A-V+

English

Chapter 1 Introduction

ank you for purchasing ASRock Rack EPC602D8A/EPC602D8A-V+ motherboard,

a reliable motherboard produced under ASRock Rack’s consistently stringent quality

control. It delivers excellent performance with robust design conforming to ASRock

Rack’s commitment to quality and endurance.

In this manual, chapter 1 and 2 contains introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration

guide to BIOS setup and information of the Support CD.

1.1 Package Contents

•ASRock Rack EPC602D8A / EPC602D8A-V+ Motherboard

(ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm)

•Support CD

•User Manual

•4 x SATA3 cables (50cm)

•2 x SATA3 cables (60cm)

•1 x I/O Shield

If any items are missing or appear damaged, contact your authorized dealer.

Because the motherboard specications and the BIOS soware might be updated, the con-

tent of this manual will be subject to change without notice. In case any modications of

this manual occur, the updated version will be available on ASRock Rack website without

further notice. You may nd the latest memory and CPU support lists on ASRock Rack

website as well. ASRock Rack’s Website: www.ASRockRack.com

If you require technical support related to this motherboard, please visit our website for

specic information about the model you are using.

www.asrock.com/support/index.asp

English

1.2 Specications

EPC602D8A / EPC602D8A-V+

MB Physical Status

Form Factor ATX

Dimension 12'' x 9.6'' (30.5 cm x 24.4 cm)

Processor System

CPU - Intel® Xeon processor E5-1600/2600/4600 & v2 series

- Supports Hyper-reading Technology

Socket Single Socket R (LGA2011)

Chipset Intel® C602

System Memory

Capacity - 8 x 240-pin DDR3 DIMM slots

- Support up to 256GB DDR3 R/LR DIMM ; 64GB ECC/non-

ECC unbuered UDIMM

Type - Quad Channel DDR3 memory technology

- Supports DDR3 1600/1333/1066 R/LR ECC and UDIMM

Voltage 1.5V, 1.35V

Expansion Slot (Slot 1 is the closest to the CPU)

Slot 1 x8

Slot 2 x16 (x16/x0 or x8/x8 with Slot 1)

Slot 3 x8

Slot 4 x16 (x16/x0 or x8/x8 with Slot 3)

Slot 5 x8 slot with EE x8/x0 or x4/x4 with Slot 6

Slot 6 x8 slot with EE x4

Slot 7 x8 (EEx2 from C602, Gen2)

Storage

SATA

Controller

Intel® C602 : 2 x SATA3 6.0 Gb/s, 8 x SATA2 3.0 Gb/s (4 from

SATA ports; the others from mini SAS port), support RAID 0, 1,

5, 10 and Intel® Rapid Storage 3.0, NCQ, AHCI and "Hot Plug"

functions

Additional

SATA

Controller

Marvell SE9172: 2 x SATA3 6.0 Gb/s

Ethernet

Interface Gigabit LAN 10/100/1000 Mb/s

LAN Controller - 2 x Intel® i210

- Supports Wake-On-LAN

- Supports Energy Ecient Ethernet 802.3az

- Supports Dual LAN with Teaming function

- Supports PXE

EPC602D8A / EPC602D8A-V+

English

Management

BMC Controller For EPC602D8A only:

ASPEED AST2300

For EPC602D8A-V+ only:

N/A

IPMI Dedicated

GLAN

For EPC602D8A Only:

1 x Realtek RTL8211E for dedicated management GLAN

For EPC602D8A-V+ Only:

N/A

Features - Watch Dog

- NMI

Gracphics

Controller For EPC602D8A only:

ASPEED AST2300

For EPC602D8A-V+ only:

ASPEED AST1300

VRAM DDR3 16MB

Output Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

Audio

Audio code 7.1 CH HD Audio with Content Protection (Realtek ALC892

Audio Codec)

*To congure 7.1 CH HD Audio, it is required to use an HD front panel

audio module and enable the multi-channel audio feature through the audio

driver.

Rear Panel I/O

VGA Port 1 x D-Sub

USB 2.0 Port 2

USB 3.0 Port 2

Lan Port - 2 x RJ45 Gigabit Ethernet LAN ports

- LAN Ports with LED (ACT/LINK LED and SPEED LED)

For EPC602D8A only:

- 1 x RJ45 Dedicated IPMI LAN port

COM Port 1 (COM1)

Audio 3 Jack

1394 port 1

English

Internal Connector

COM Port

Header

1 (COM2)

Auxiliary Panel

Header

1 (includes chassis intrusion, location button & LED, front

LAN LED)

TPM Header 1

ermal Sensor

Header

IPMB Header 1

Buzzer 1

Fan Header 5 x 4-pin

ATX Power 1 (24-pin) + 1 (8-pin)

USB 3.0 Header 1 (each supports 2 USB 3.0 ports)

USB 2.0 Header 1 (each supports 2 USB 2.0 ports)

Type A USB 2.0

Port

Front Audio

panel

SPDIF Header 1

1394 Header 1

Front Panel 1

Speaker 1

Dr. Debug with

LED

System BIOS

BIOS Ty pe 64Mb AMI UEFI Legal BIOS

BIOS Features - Plug and Play (PnP)

- ACPI 1.1 Compliance Wake Up Events

- SMBIOS 2.3.1 Support

- DRAM Voltage Multi-adjustment

- ASRock Instant Flash

Hardware Monitor

Temperature - CPU Temperature Sensing

- System Temperature Sensing

Fan - CPU/Rear/Front Fan Tachometer

- CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU

Temperature)

- CPU/Rear/Front Fan Multi-Speed Control

Voltage Voltage Monitoring: CPU1/2, DRAM1/2, VCCM, VCCSA1/2,

3V/5V/ 12V, +1.05V_PCH, +BAT, 3VSB, 5VSB
