ASROCK H81TM-ITX Manuale utente

User Manual

Version 1.0

Published December 2013

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 6

1.4 Motherboard Layout 9

1.5 I/O Panel 11

Chapter 2 Installation 12

2.1 Installing the CPU 13

2.2 Installing the CPU Fan and Heatsink 16

2.3 Installing Memory Modules (SO-DIMM) 17

2.4 Expansion Slots (PCI Express Slots) 19

2.5 Jumpers Setup 20

2.6 Onboard Headers and Connectors 21

Chapter 3 Software and Utilities Operation 26

3.1 Installing Drivers 26

3.2 A-Tuning 27

3.3 Intel® Smart Connect Technology 30

3.4 Intel® Remote Wake Technology 35

3.4.1 Conguring and Using MeshCentral 35

3.4.2 Conguring and Using Splashtop 40

3.5 Start8 43

Chapter 4 UEFI SETUP UTILITY 46

4.1 Introduction 46

4.1.1 UEFI Menu Bar 46

4.1.2 Navigation Keys 47

4.2 Main Screen 48

4.3 OC Tweaker Screen 49

4.4 Advanced Screen 57

4.4.1 CPU Conguration 58

4.4.2 Chipset Conguration 60

4.4.3 Storage Conguration 63

4.4.4 Intel® Smart Connect Technology 64

4.4.5 Super IO Conguration 65

4.4.6 ACPI Conguration 66

4.4.7 USB Conguration 68

4.5 Tools 69

4.6 Hardware Health Event Monitoring Screen 72

4.7 Boot Screen 73

4.8 Security Screen 76

4.9 Exit Screen 77

H81TM-ITX

PB 1

English

Chapter 1 Introduction

ank you for purchasing ASRock H81TM-ITX motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• ASRock H81TM-ITX Motherboard (in Mini-ITX Form Factor)

• ASRock H81TM-ITX Quick Installation Guide

• ASRock H81TM-ITX Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x SATA 1 to 1 Power Cable (Optional)

• 2 x I/O Panel Shields

• 1 x WiFi Module Screw

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this documentation occur, the updated version will be available on ASRock’s

website without further notice. If you require technical support related to this mother-

board, please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com.

2 3

English

1.2 Specications

Platform • in Mini-ITX Form Factor (Compatible with Mini-ITX)

• Solid Capacitor for CPU power

A-Style • Home Cloud

CPU • Supports 4th Generation Intel® CoreTM i7 / i5 / i3 / Xeon® /

Pentium® / Celeron® processors with up to 65W TDP in an

LGA1150 package

• Supports Intel®Turbo Boost 2.0 Technology

Chipset • Intel®H81

Memory • Dual Channel DDR3 Memory Technology

• 2 x DDR3 SO-DIMM Slots

• Supports DDR3 1600/1333/1066 non-ECC, un-buered

memory

• Max. capacity of system memory: 16GB

(see CAUTION)

• Supports Intel®Extreme Memory Prole (XMP)1.3/1.2

Expansion

Slot

• 1 x PCI Express 2.0 x4 Slot

• 1 x mini-PCI Express Slot

Graphics • Intel® HD Graphics Built-in Visuals and the VGA outputs can

be supported only with processors which are GPU integrated.

• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick

Sync Video with AVC, MVC (S3D) and MPEG-2 Full

HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® HD Graphics 4400/4600

• Pixel Shader 5.0, DirectX 11.1

• Max. shared memory 1792MB

• ree graphics output options: HDMI, DVI-I and LVDS

• Supports Triple Monitor

• Supports HDMI Technology with max. resolution up to 4K ×

2K (4096x2304) @ 24Hz

• Supports DVI-I with max. resolution up to 1920x1200 @

60Hz

H81TM-ITX

2 3

English

• Supports LVDS with max. resolution up to 1920x1200 @

60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port (Compliant

HDMI monitor is required)

• Supports HDCP function with HDMI

• Supports Full HD 1080p Blu-ray (BD) playback with HDMI

Audio • 7.1 CH HD Audio with Content Protection (Realtek ALC892

Audio Codec)

• Premium Blu-ray audio support

LAN • Gigabit LAN 10/100/1000 Mb/s

• Giga PHY Intel® I217V

• Supports Intel® Remote Wake Technology

• Supports Wake-On-LAN

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x DC Jack

• 1 x DVI-I Port

• 1 x HDMI Port

• 2 x USB 2.0 Ports

• 2 x USB 3.0 Ports

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jacks: Front Speaker / Microphone

Storage • 2 x SATA3 6.0 Gb/s connectors, support NCQ, AHCI and Hot

Plug

Connector • 1 x CIR Header

• 1 x COM Port Header

• 1 x SPDIF Out Connector

• 1 x Backlight Power Jumper

• 1 x Panel Power Jumper

• 1 x Backlight & Amp Volume Control Header

4 5

English

• 1 x Power LED Header

• 1 x LVDS Connector

• 1 x LPC Debug Header

• 1 x Home eater PC Header

• 1 x CPU Fan Connector (4-pin)

• 1 x Chassis Fan Connector (4-pin)

• 1 x Front Panel Audio Connector

• 1 x Analog Surround Audio Header

• 1 x Digital MIC Header

• 1 x 3W Audio AMP Output Wafer Header

• 1 x SATA Power Connector

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)

BIOS

Feature

• 32Mb AMI UEFI Legal BIOS with multilingual GUI support

• ACPI 1.1 Compliant wake up events

• SMBIOS 2.3.1 support

• CPU, DRAM Voltage multi-adjustment

Support

• Drivers, Utilities, AntiVirus Soware (Trial Version), Google

Chrome Browser and Toolbar, Start8 (30 days trial), Mesh-

Central, Splashtop Streamer

Hardware

Monitor

• CPU/Chassis temperature sensing

• CPU/Chassis Fan Tachometer

• CPU/Chassis Quiet Fan (Auto adjust chassis fan speed by

CPU temperature)

• CPU/Chassis Fan multi-speed control

• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

OS • Microso® Windows® 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-

bit / 7 32-bit / 7 64-bit

Certica-

tions

• FCC, CE, WHQL

• ErP/EuP Ready (ErP/EuP ready power supply is required)

* For detailed product information, please visit our website: http://www.asrock.com

H81TM-ITX

4 5

English

Due to limitation, the actual memory size may be less than 4GB for the reservation for sys-

tem usage under Windows® 32-bit operating systems. Windows® 64-bit operating systems

do not have such limitations. You can use ASRock XFast RAM to utilize the memory that

Windows® cannot use.

6 7

English

1.3 Unique Features

ASRock A-Tuning

A-Tuning is ASRock’s multi purpose soware suite with a new interface, more new

features and improved utilities, including XFast RAM, Dehumidier, Good Night

LED, FAN-Tastic Tuning, OC Tweaker and a whole lot more.

ASRock Instant Flash

ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM. is conve-

nient BIOS update tool allows you to update the system BIOS in a few clicks without

preparing an additional oppy diskette or other complicated ash utility. Just save

the new BIOS le to your USB storage and launch this tool by pressing <F6> or

<F2> during POST to enter the BIOS setup menu to access ASRock Instant Flash.

Please be noted that the USB ash drive or hard drive must use FAT32/16/12 le

system.

ASRock APP Charger

Simply by installing the ASRock APP Charger makes your iPhone/iPad/iPod Touch

charge up to 40% faster than before on your computer. ASRock APP Charger allows

you to quickly charge many Apple devices simultaneously and even supports

continuous charging when your PC enters into Standby mode (S1), Suspend to RAM

(S3), hibernation mode (S4) or power o (S5).

ASRock XFast LAN

ASRock XFast LAN provides faster internet access, which includes the benets

listed below. LAN Application Prioritization: You can congure your application’s

priority ideally and add new programs to the list. Lower Latency in Game: Aer

setting online game’s priority higher, it can lower the latency in games. Trac

Shaping: You can watch Youtube HD videos and download simultaneously. Real-

Time Analysis of Your Data: With the status window, you can easily recognize

which data streams you are currently transferring.

ASRock XFast RAM

ASRock XFast RAM is included in A-Tuning. It fully utilizes the memory space

that cannot be used under Windows® 32-bit operating systems. ASRock XFast RAM

shortens the loading time of previously visited websites, making web surng faster

than ever. And it also boosts the speed of Adobe Photoshop 5 times faster. Another

advantage of ASRock XFast RAM is that it reduces the frequency of accessing your

SSDs or HDDs in order to extend their lifespan.

Altri manuali per H81TM-ITX

Indice

Altri manuali ASROCK Scheda madre

ASROCK

ASROCK X370 GAMING Manuale utente

ASROCK

ASROCK Z87 Extreme9 Manuale utente

ASROCK

ASROCK P45X3 DELUXE - Manuale utente

ASROCK

ASROCK P81 Pro3 Manuale utente

ASROCK

ASROCK 4CORE1333-VIIV - V1.0 Manuale utente

ASROCK

ASROCK PV530-ITX - V1.0 Manuale utente

ASROCK

ASROCK PRO Series Manuale utente

ASROCK

ASROCK J5040-ITX Manuale utente

ASROCK

ASROCK B150M-DVS R2.0 Manuale utente

ASROCK

ASROCK G31M-GS - R2.0 Manuale utente

ASROCK

ASROCK X99 Extreme11 Manuale utente

ASROCK

ASROCK H510M-HDV Manuale utente

ASROCK

ASROCK SP55 DELUXE Manuale utente

ASROCK

ASROCK H81 Pro BTC Manuale utente

ASROCK

ASROCK H77M-ITX Manuale utente

ASROCK

ASROCK B550M Steel Legend Manuale utente

ASROCK

ASROCK K10N78D Manuale utente

ASROCK

ASROCK 890FX Deluxe5 Manuale utente

ASROCK

ASROCK H61M-VG3 Manuale utente

ASROCK

ASROCK H55M Manuale utente

ASROCK

ASROCK 870 EXTREME3 Manuale utente

ASROCK

ASROCK 760GM-GS3 Manuale utente

ASROCK

ASROCK N3700M Manuale utente

ASROCK

ASROCK PENRYN1600SLIX3-WIFI Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuale utente
