ASROCK X570S PG Riptide Manuale utente

Version 1.0

Published May 2021

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law. You are entitled to a replacement or refund for a major failure and

compensation for any other reasonably foreseeable loss or damage caused by our

goods. You are also entitled to have the goods repaired or replaced if the goods fail

to be of acceptable quality and the failure does not amount to a major failure. If

you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard

International call charges apply)

e terms HDMI® and HDMI High-Denition Multimedia Interface, and the

HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the

United States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 8

1.4 I/O Panel 10

1.5 Graphics Card Holder 12

Chapter 2 Installation 13

2.1 Installing the CPU 14

2.2 Installing the CPU Fan and Heatsink 16

2.3 Installing Memory Modules (DIMM) 24

2.4 Expansion Slots (PCI Express Slots) 28

2.5 Onboard Headers and Connectors 30

2.6 Smart Buttons 36

2.7 Post Status Checker 38

2.8 CrossFireXTM and Quad CrossFireXTM Operation Guide 39

2.8.1 Installing Two CrossFireXTM-Ready Graphics Cards 39

2.8.2 Driver Installation and Setup 41

2.9 M.2 2230 WiFi/BT PCIe WiFi module Installation

Guide (M2_WIFI) 42

2.10 M.2_SSD (NGFF) Module Installation Guide (M2_1) 44

2.11 M.2_SSD (NGFF) Module Installation Guide (M2_2) 48

Chapter 3 Software and Utilities Operation 51

3.1 Installing Drivers 51

3.2 ASRock Motherboard Utility (Phantom Gaming Tuning) 52

3.2.1 Installing ASRock Motherboard Utility (Phantom Gaming

Tuning) 52

3.2.2 Using ASRock Motherboard Utility (Phantom Gaming Tuning)52

3.3 ASRock Live Update & APP Shop 55

3.3.1 UI Overview 55

3.3.2 Apps 56

3.3.3 BIOS & Drivers 59

3.3.4 Setting 60

3.4 Nahimic Audio 61

3.5 ASRock Polychrome SYNC 62

Chapter 4 UEFI SETUP UTILITY 65

4.1 Introduction 65

4.1.1 UEFI Menu Bar 65

4.1.2 Navigation Keys 66

4.2 Main Screen 67

4.3 OC Tweaker Screen 68

4.4 Advanced Screen 72

4.4.1 CPU Conguration 73

4.4.2 PCIConguration 74

4.4.3 Onboard Devices Conguration 75

4.4.4 Storage Conguration 77

4.4.5 ACPI Conguration 78

4.4.6 Trusted Computing 79

4.4.7 AMD PBS 80

4.4.8 AMD Overclocking 81

4.4.9 AMD CBS 82

4.5 Tools 83

4.6 Hardware Health Event Monitoring Screen 84

4.7 Security Screen 87

4.8 Boot Screen 88

4.9 Exit Screen 90

English

X570S PG Riptide

Chapter 1 Introduction

ank you for purchasing ASRock X570S PG Riptide motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the

motherboard and step-by-step installation guides. Chapter 3 contains the operation

guide of the soware and utilities. Chapter 4 contains the conguration guide of

the BIOS setup.

1.1 Package Contents

• ASRock X570S PG Riptide Motherboard (ATX Form Factor)

• ASRock X570S PG Riptide Quick Installation Guide

• ASRock X570S PG Riptide Support CD

• 1 x I/O Panel Shield

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x Graphics Card Holder (Optional)

• 3 x Screws for M.2 Socket (Optional)

• 1 x Stando for M.2 Socket (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this documentation occur, the updated version will be available on ASRock’s

website without further notice. If you require technical support related to this mother-

board, please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com.

English

1.2 Specications

Platform • ATX Form Factor

• Solid Capacitor design

• 2oz Copper PCB

CPU • Supports AMD AM4 Socket RyzenTM 2000, 3000, 4000

G-Series and 5000 Series Desktop Processors

• Digi Power design

• 10 Power Phase design

Chipset • AMD X570

Memory • Dual Channel DDR4 Memory Technology

• 4 x DDR4 DIMM Slots

• AMD Ryzen series CPUs (Vermeer) support DDR4

5000+(OC)/4933(OC)/4866(OC)/4800(OC)/4733(OC)/4666

(OC)/4600(OC)/4533(OC)/4466(OC)/4400(OC)/4333(OC)/4

266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800

(OC)/3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/

2400/2133 ECC & non-ECC, un-buered memory*

• AMD Ryzen series CPUs (Matisse) support DDR4 5000+

(OC)/4933(OC)/4866(OC)/4800(OC)/4733(OC)/4666(OC)/

4600(OC)/4533(OC)/4466(OC)/4400(OC)/4333(OC)/4266

(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/

3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133

ECC & non-ECC, un-buered memory*

• AMD Ryzen series APUs (Renoir) support DDR4 5000+

(OC)/4933(OC)/4866(OC)/4800(OC)/4733(OC)/4666(OC)/

4600(OC)/4533(OC)/4466(OC)/4400(OC)/4333(OC)/4266

(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/

3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133

ECC & non-ECC, un-buered memory*

• AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4

3600+(OC)/3466(OC)/3200(OC)/2933/2667/2400/2133 ECC

& non-ECC, un-buered memory*

English

X570S PG Riptide

• AMD Ryzen series APUs (Picasso) support DDR4 3466+

(OC)/3200(OC)/2933/2667/2400/2133 non-ECC, un-buered

memory*

* For Ryzen Series APUs (Picasso), ECC is only supported with

PRO CPUs.

* Please refer to Memory Support List on ASRock’s website for

more information. (http://www.asrock.com/)

* Please refer to page 24 for DDR4 UDIMM maximum

frequency support.

• Max. capacity of system memory: 128GB

• Supports Extreme Memory Prole (XMP) memory modules

• 15μ Gold Contact in DIMM Slots

Expansion

Slot

AMD Ryzen series CPUs (Vermeer, Matisse)

• 1 x PCI Express 4.0 x16 Slot (x16 (PCIE1))*

AMD Ryzen series CPUs (Renoir, Pinnacle Ridge)

• 1 x PCI Express 3.0 x16 Slot (x16 (PCIE1)*

AMD Ryzen series APUs (Picasso)

• 1 x PCI Express 3.0 x16 Slot (x8 (PCIE1))*

AMD X570 Chipset

• 2 x PCI Express 4.0 x16 Slots (x4 (PCIE4) / x2 (PCIE6))*

* Supports NVMe SSD as boot disks

• 3 x PCI Express 4.0 x1 Slots

• Supports AMD Quad CrossFireXTM and CrossFireXTM

• 15μ Gold Contact in VGA PCIe Slot (PCIE1)

• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe

WiFi module

Graphics • Integrated AMD RadeonTM Vega Series Graphics in Ryzen

Series APU*

* Actual support may vary by CPU

• DirectX 12, Pixel Shader 5.0

• Shared memory default 2GB. Max Shared memory supports

up to 16GB.

* e Max shared memory 16GB requires 32GB system memory

installed.

• Supports HDMI 2.1 with max. resolution up to 4K x 2K

(4096x2160) @ 60Hz

English

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant

HDMI monitor is required)

• Supports HDR (High Dynamic Range) with HDMI 2.1

• Supports HDCP 2.3 with HDMI 2.1 Port

• Supports 4K Ultra HD (UHD) playback with HDMI 2.1 Port

• Supports Microso PlayReady®

Audio • 7.1 CH HD Audio (Realtek ALC897 Audio Codec)

• Supports Surge Protection

• Gold Audio Jacks

• Nahimic Audio

LAN • 2.5 Gigabit LAN 10/100/1000/2500 Mb/s

• 1 x Killer® E3100G (PCIE x1 Gigabit LAN 10/100/1000/2500

Mb/s)

• Supports Killer LAN Soware

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x Antenna Bracket

• 1 x PS/2 Mouse/Keyboard Port

• 1 x HDMI Port

• 1 x Optical SPDIF Out Port

• 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD

Protection)

• 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (Supports ESD

Protection)

• 4 x USB 3.2 Gen1 Ports (Supports ESD Protection)

* USB3_2 and USB31_TA_1 are the Lightning Gaming Ports.

• 2 x USB 2.0 Ports (Supports ESD Protection)

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• 1 x BIOS Flashback Button with LED

• HD Audio Jacks: Rear Speaker / Central / Bass / Line in /

Front Speaker / Microphone (Gold Audio Jacks)

Altri manuali per X570S PG Riptide

Indice

Altri manuali ASROCK Scheda madre

ASROCK

ASROCK A75M-HVS Manuale utente

ASROCK

ASROCK H55 PRO - V1.0 Manuale utente

ASROCK

ASROCK AD2550-ITX Manuale utente

ASROCK

ASROCK AD2550B-ITX Manuale utente

ASROCK

ASROCK Z790 PG SONIC Manuale utente

ASROCK

ASROCK 785G Pro Manuale utente

ASROCK

ASROCK B550 PG Riptide Manuale utente

ASROCK

ASROCK H61DEL Manuale utente

ASROCK

ASROCK Z490M PRO4 Manuale utente

ASROCK

ASROCK 775i65G Manuale utente

ASROCK

ASROCK Fatal1ty Z68 Professional Gen3 Manuale utente

ASROCK

ASROCK N68C-GS UCC - Manuale utente

ASROCK

ASROCK D1541D4I-2L2T Manuale utente

ASROCK

ASROCK ALIVEN570SLI-ESATA2 Manuale utente

ASROCK

ASROCK Fatal1ty B450 Manuale utente

ASROCK

ASROCK ION 330 - V1.1 Manuale utente

ASROCK

ASROCK Super Alloy H110M-HDV Manuale utente

ASROCK

ASROCK H570M-ITX/ac Manuale utente

ASROCK

ASROCK A520M Pro4 Manuale utente

ASROCK

ASROCK SOM-P101 Manuale utente

ASROCK

ASROCK NF6-GLAN Manuale utente

ASROCK

ASROCK P55 DELUXE3 - Manuale utente

ASROCK

ASROCK P55 DELUXE - V1.1 Manuale utente

ASROCK

ASROCK Z87M Extreme4 Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuale utente
