Asus ROG STRIX GS-AX3000 Manuale utente

ROG STRIX GS-AX3000 Dual-band Gaming Router

Q18254

Table of contentsTable of contents

Package contents ........................................................................3

A quick look at GS-AX3000 ......................................................3

Position your wireless router...................................................4

Preparing your modem.............................................................5

Setting up your GS-AX3000..................................................... 6

A. Wired connection .............................................................................6

B. Wireless connection.........................................................................6

FAQ ...................................................................................................8

This QSG contains these languages:

English

Français

Português

Español

English

A quick look at GS-AX3000A quick look at GS-AX3000

WAN (Internet) LED USB 3.2 Gen 1 port

5GHz LED LAN 1 ~ 4 ports

2.4GHz LED WAN (Internet) port

Power LED WPS button

Power (DC-IN) port Reset button

Power switch

Package contentsPackage contents

GS-AX3000 Wireless Router AC adapter

Network cable (RJ-45) Quick Start Guide

English

Position your wireless routerPosition your wireless router

For optimal wireless transmission between the wireless router and connected

wireless devices, ensure that you:

• Place the wireless router in a centralized area for a maximum wireless coverage

for the network devices.

• Keep the wireless router away from metal obstructions and away from direct

sunlight.

• Keep the wireless router away from 802.11g or 20MHz only Wi-Fi devices,

2.4GHz computer peripherals, Bluetooth devices, cordless phones, transformers,

heavy-duty motors, uorescent lights, microwave ovens, refrigerators, and other

industrial equipment to prevent signal interference or loss.

• Always update to the latest rmware. Visit the ASUS website at

http://www.asus.com to get the latest rmware updates.

• To ensure the best wireless signal, orient the four non-detachable antennas as

shown i n the drawings below.

NOTES:

• Use only the adapter that came with your package. Using other

adapters may damage the device.

• Specications:

DC Power adapter DC Output: +12V with 2A current

Operating Temperature 0~40oC Storage 0~70oC

Operating Humidity 50~90% Storage 20~90%

English

Preparing your modemPreparing your modem

1. Unplug the power cable/DSL modem. If it has a battery

backup, remove the battery.

NOTE: If you are using DSL for Internet, you will

need your username/password from your Inter-

net Service Provider (ISP) to properly congure

the router.

2. Connect your modem to the router

with the bundled network cable.

3. Power on your cable/DSL modem.

4. Check your cable/DSL modem LED lights to ensure

the connection is active.

Unplug

English

Setting up your GS-AX3000Setting up your GS-AX3000

You can set up your router via wired or

wireless connection.

A. Wired connection

1. Plug your router into a power outlet

and power it on. Connect the network

cable from your computer to a LAN

port on your router.

2. The web GUI launches automatically when you open a web browser. If it does

not auto-launch, enter http://router.asus.com.

3. Set up a password for your router to prevent unauthorized access.

B. Wireless connection

1. Plug your router into a power outlet and

power it on.

Laptop

Tablet

Smart phone

Wall Power Outlet

Modem

LINE LAN RESET PWR

Power WAN

Wall Power Outlet

Modem

LINE LAN RESET PWR

Laptop

Power WAN

LAN

English

2. Connect to the network with SSID shown on the product label on the back side

of the router. For better network security, change to a unique SSID and assign

a password.

ASUS router

ASUS_XX

Wi-Fi Name (SSID): ASUS_XX

* XX refers to the last two digits of 2.4GHz

MAC address. You can nd it on the label

on the back of your router.

3. You can choose either the web GUI or ASUS Router app to set up your router.

a. Web GUI Setup

•

Once connected, the web GUI launches automatically when you open a

web browser. If it does not auto-launch, enter http://router.asus.com.

•

Set up a password for your router to prevent unauthorized access.

English

b. App Setup

Download ASUS Router App to set up your

router via your mobile devices.

•

Turn on Wi-Fi on your mobile devices

and connect to your router’s network.

•

Follow ASUS Router App setup

instructions to complete the setup.

ASUS Router

ASUS

Router

Remembering your wireless router settings

• Remember your wireless settings as you complete the router setup.

Router Name: Password:

2.4 GHz network SSID: Password:

5GHz network SSID: Password:

FAQFAQ

1. Where can I nd more information about the wireless router?

• Technical support site: https://www.asus.com/support

• Customer hotline: refer to the Support Hotline section in this Quick Start

Guide

• You can get the user manual online at https://www.asus.com/support

Français

Aperçu rapide de votre routeur GS-AX3000Aperçu rapide de votre routeur GS-AX3000

Voyant réseau étendu (WAN) (Internet) Port USB 3.2 Gen1

Voyant de bande 5 GHz Ports réseau local (LAN) 1 à 4

Voyant de bande 2,4 GHz Port réseau étendu (WAN) (Internet)

Voyant LED d'alimentation Bouton WPS

Port d'alimentation (CC) Bouton de réinitialisation

Interrupteur d'alimentation

Contenu de la boîteContenu de la boîte

Routeur Wi-Fi GS-AX3000 Adaptateur secteur

Câble réseau (RJ-45) Guide de démarrage rapide

Manufacturer ASUSTeK Computer Inc.

Tel: +886-2-2894-3447

Address: 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112, Taiwan

華碩電腦股份有限公司

電話 : +886-2-2894-3447

地址 : 臺北市北投區立德路 15 號 1 樓

Authorised

representative in

Europe

ASUS Computer GmbH

Address: HARKORT STR. 21-23, 40880 RATINGEN, GERMANY

Authorised

distributors in

Turkey

BOGAZICI BILGISAYAR TICARET VE SANAYI A.S.

Tel./FAX No.: +90 212 331 10 00 / +90 212 332 28 90

Address: ESENTEPE MAH. BUYUKDERE CAD. ERCAN HAN B BLOK

NO.121 SISLI, ISTANBUL 34394

CIZGI Elektronik San. Tic. Ltd. Sti.

Tel./FAX No.: +90 212 356 70 70 / +90 212 356 70 69

Address: GURSEL MAH. AKMAN SK.47B 1 KAGITHANE/ISTANBUL

KOYUNCU ELEKTRONiK BiLGi iSLEM SiST. SAN. VE DIS TIC. A.S.

Tel. No.: +90 216 5288888

Address: EMEK MAH.ORDU CAD. NO:18, SARIGAZi, SANCAKTEPE

ISTANBUL

ENDEKS BİLİŞİM SAN VE DIŞ TİC LTD ŞTİ

Tel./FAX No.: +90 216 523 35 70 / +90 216 523 35 71

Address: NECIP FAZIL BULVARI, KEYAP CARSI SITESI, G1 BLOK, NO:115

Y.DUDULLU, UMRANIYE, ISTANBUL

PENTA TEKNOLOJI URUNLERI DAGITIM TICARET A.S

Tel./FAX No.: +90 216 528 0000

Address: ORGANIZE SANAYI BOLGESI NATO YOLU 4.CADDE NO:1

UMRANIYE, ISTANBUL 34775

India RoHS

This product complies with the "India E-Waste (Management) Rules, 2016"

and prohibits use of lead, mercury, hexavalent chromium, polybrominated

biphenyls(PBBs) and polybrominated diphenyl ethers (PBDEs) in concentrations

exceeding 0.1 % by weight in homogenous materials and 0.01 % by weight

in homogenous materials for cadmium, except for the exemptions listed in

Schedule II of the Rule.
