AurAir B2
Quick Start Guide
Overview
Display
All measured sensor values are displayed here. Several indicators are displayed on the right hand side,
like WiFi mode, measurement unit and countdown until next CO2 measurement indicator.
Display Button
Single click: Switch display off
Double click: Dim display
Long click: Update Firmware
Mode Button
Single click: Display graph
Double click: Display max/min values
Long click: Calibrate CO2 Sensor
Settings Button
Single click: Display cloud password
Double click: Disable password
Long click: Reset to factory settings
Wall Socket
This is a straight through wall
socket suitable for all countries
with a CEE 7/3 socket and
CEE7/7 plug. Countries like
Germany, the Netherlands,
Sweden, Norway and Finland.
Front Panel
When the AurAir is powered off,
only the side buttons are visible.
Flame Resistant Encasing
The AurAir encasing is flame resistant, making it
impossible to burn.
AurAir B2
Icons and Values
CO2 Value
All measured CO2 sensor values are displayed here. Healthy values are displayed in green, mediocre values in
yellow and unhealthy values in red.
WiFi Icon
Single click: Switch display off
Double click: Dim display
Long click: Update Firmware
Unit Icon
The unit for CO2 is PPM, parts per
million.
Measurement
Cadence Icon
After each CO2 measurement, the
green solid circle is displayed again.
The green circle gets smaller as
time passes until it has completely
vanished and the next
measurement is started.
Temperature Value
The temperature value is
displayed on the lower mid side,
followed by the metric unit
symbol Celcius (c). The
temperature has a single white
color.
Air Pressure Value
The air pressure is displayed on
the lower right side, followed by
the metric unit symbol (hPa). The
pressure has a single white color.
Relative Humidity Value
The relative humidity value is displayed on the lower left
side, followed by the symbol (%). Healthy values are
displayed in green, mediocre values in yellow and
unhealthy values in red.
AurAir B2
DISPLAY button
DISPLAY Button
Single click: Switch display OFF.
To switch display ON again, do
another single click.
Double click: Dim display. To
switch display to FULL again, do
another double click.
Long click: Update Firmware. On
the display the question is asked if
you want to update the firmware.
Pressing the mode button means
YES, pressing the settings button
means NO.
AurAir B2
MODE button
CO2 Graph
All measured CO2 sensor values of the past 25 hours are displayed here in graphical form. Healthy values are displayed in green,
mediocre values in yellow and unhealthy values in red.
MODE Button
Single click: Switch display to
“CO2 Graph” view.
To switch display to “CO2 Value”
view again, do another single click.
Double click: Display minimum,
maximum, average CO2 values of
the last 24 hours. To switch display
to “CO2 Value” view again, do
another double click.
Long click: Calibrate the CO2
Sensor. On the display the
question is asked if you want to
calibrate the CO2 Sensor. Pressing
the mode button means YES,
pressing the settings button means
NO. Calibrations takes 1300
seconds to complete!
WARNING: only do calibration
outdoor in dry conditions or well
ventilated indoor room.
AurAir B2
SETTINGS button
Settings
Various import network settings are displayed here, like admin password, cloud username and cloud password. In case you forgot
the admin password, it can be seen here. The cloud username and password are needed to login into the cloud. Go to
https://www.aurair.eu and login to see your history!
SETTINGS Button
Single click: Switch display to
settings page.
To switch display to “CO2 Value”
view again, do another single click.
Double click: Disable admin
password for the next 5 minutes,
enabling you to login without
password. To switch display to
“CO2 Value” view again, do
another double click.
Long click: Restores Factory
settings. On the display the
question is asked if you want to
restore factory settings. Pressing
the mode button means YES,
pressing the settings button means
NO.
AurAir B2
Troubleshooting
Here are some of the things to keep in mind when you encounter problems with the AurAir.
AurAir…
What happens?
What should I do?
Display the logo and waves
for more than 3 minutes.
Initialization of the AurAir failed.
Pull the AurAir from the wall socket, wait for 20 seconds and
put the AurAir back into the wall socket.
The background of the
CO2 countdown is garbled.
For some reason the screen has not been cleared.
Ignore it, when the countdown finishes it will clear the screen.
CO2 value pixels from
previous values are still on
the display
For unknow reason it has not cleared the screen completely.
Press the mode button once to go to “CO2 Graph” mode and
once again to go back to the “CO2 Value” view.
Issue Date: 20-10-2019 Version v1.2
