Avalon A13CT-S Manuale utente
A few simple steps to ensure
perfect water, every time.
www.avalonh2o.com
We’re Here to Help
Let’s Connect
Call Us:
1.800.256.0695
Email Us:
support@avalonh2o.com
sales@avalonh2o.com
Live Chat:
Monday-Thursday: 9 a.m.-5:30 p.m.
Friday: 9 a.m.-4:30 p.m.
@avalon_h2o Avalon Water Coolers Avalonh2o
Follow our social media accounts and stay up to
date on the latest Avalon news.
We are also available
for live video chat!
Use and Care Guide
MODEL: A13CT-S
Registration
Please visit the website below to register your new water cooler within the first
30 days of purchase. Registration within the first 30 days will activate your one
year warranty.
www.avalonh2o.com/register-my-avalon-cooler
Please keep your model number, order number and purchase date
for future support. You can reach us at 1-800-256-0695.
Model Number
Order Number
Purchase Date
Contents
About Your Water Cooler
Meet Your Avalon Product
Part Names
Indicator Lights
Tech Specs
BioGuard
Filter Function Introduction
Getting Started
Unpacking
Installation (Under the Sink)
Installation (Refrigerator Water Line)
Flushing Filters
Finishing Water Cooler Installation
Activating Heating and Cooling
Installing and Removing the Drip Tray
User Guide and Maintenance
Dispensing Water
Touchless Dispensing
Replacing the Filters
Leak Detection
Cleaning
Activating Self-Cleaning Function
Rinsing, Cleaning, and Draining
Cleaning
Troubleshooting
Safety
Warranty
1-2
3-4
5
6
7
8
10
11-12
13
14-15
16-19
20
21
23
24
25-27
28
30
31-33
34-35
37-38
40-41
43
1
Metal Adapter with Valve
(3/8” compression)
Meet Your Avalon Product
Inside the box, you’ll find:
2 Small PE Tubing
2 Mounting Brackets
Carbon Block Filter Sediment Filter
2 Filter
Flushing Adapters
Valve and
Tube Assembly
PE Tubing
(20’ length, 1/4” diameter)
Three Way
Plastic Adapter
(1/4”)
About Your Water Cooler
2
Meet Your Avalon Product
Attractive Design
Attractive stainless
steel design with
sleek electronic
illuminated buttons
Custom Temperature
Piping hot,
cool, or crisp
cold water
Dual Stage Filtration
Double the filtration
for twice the peace
of mind
Worry-Free Cleaning
Self-cleaning
ozone function
for longer lasting
water purification
NSF Certified Filters Energy Star ApprovedUL Listed Child Safety Feature Touchless
We meet strict
standards for public
health protection
We design
& manufacture
with your safety
in mind
Saves the
environment
& your wallet
Ensures safe hot
water flow for the
entire family
Touchless hands-
free dispensing for
cold water
Built-in Nightlight
Makes late night
water trips a breeze
About Your Water Cooler
3
9. Panel
11. Nightlight
10. Spout
12. Drip Tray
5. Child Safety
Lock Push Button
Part Names
8. Cold Water
Push Button
7. Cool Water
Push Button
6. Hot Water
Push Button
Replace Filter Self Clean
Blinking = Heating Blinking = Cooling
2. Heating Indicator Light
4. Cooling Indicator Light
3. Self-Cleaning Indicator Light
1. Filter Indicator Light
Cold
Hot
Unlock
About Your Water Cooler
23. Touchless Sensor
4
Part Names
14. Filter Reset Switch
19. Heating Switch
22. Drain Outlet
20. Water Inlet
21. Power Cord
18. Cooling Switch
17. Nightlight Switch
16. Self-Cleaning Switch
15. Condenser
13. Filters
Push Connect Ring
About Your Water Cooler
