Avalon A14-S Manuale utente
A few simple steps to ensure
perfect water, every time.
English
English
www.avalonh2o.com
We’re Here to Help
Let’s Connect
Call Us:
1.800.256.0695
Email Us:
support@avalonh2o.com
sales@avalonh2o.com
Live Chat:
Monday-Thursday: 9 a.m.-5:30 p.m.
Friday: 9 a.m.-4:30 p.m.
@avalon_h2o Avalon Water Coolers Avalonh2o
Follow our social media accounts and stay up to
date on the latest Avalon news.
We are also available
for live video chat!
English
Use and Care Guide
MODELS: A14-S A14BLKS
Registration
Please visit the website below to register your new water cooler within the first
30 days of purchase. Registration within the first 30 days will activate your one
year warranty.
www.avalonh2o.com/register-my-avalon-cooler
Please keep your model number, order number and purchase date
for future support. You can reach us at 1-800-256-0695.
Model Number
Order Number
Purchase Date
English
Contents
About Your Water Cooler
Meet Your Avalon Product
Part Names
Indicator Lights
Tech Specs
BioGuard
Getting Started
Unpacking your Avalon Water Cooler
Install Water Bottle
Install/Remove Drip Tray
Powering the Dispenser
Activate Heating and Cooling
User Guide and Maintenance
Dispensing Water
Touchless Dispensing
Changing the Bottle
Cleaning
Self-Cleaning
Rinsing, Cleaning, and Draining
Cleaning
Troubleshooting
Safety
Warranty
1
2-3
4
5
6
8
9-10
11
12
13
15
16
17-18
20
22-23
24-25
27-28
30-31
33
English
1
Piping hot,
cool or crisp
cold water
Self-cleaning ozone
function for longer
lasting water purification
Meet Your Avalon Product
Custom Temperature Empty bottle indicator
Notifies you when your
bottle is empty
Attractive Design
Stainless steel design
with three water spouts
Bottom loading
No more lifting,
flipping or spills
UL Listed
We design
&
manufacture
with your safety in mind
Energy Star Approved
Saves the environment
and your wallet
Built-in Nightlight
Makes late night
water trips a breeze
Child Safety Feature
Ensures safe hot water
flow for the entire family
Worry-Free Cleaning
Touchless
Touchless hands-
free dispensing for
cold water
About Your Water Cooler
English
2
4. Cooling Indicator Light
Part Names
9. Panel
11. Nightlight
10. Spout
12. Drip Tray
2. Heating Indicator Light
3. Self-Cleaning Indicator Light1. Empty Bottle
Indicator Light
5. Child Safety
Lock Push Button
8. Cold Water
Push Button
7. Cool Water
Push Button
6. Hot Water
Push Button
Blinking = Heating Blinking = Cooling
Self Clean
Cold
Hot
Unlock
20. Touchless Sensor
About Your Water Cooler
English
3
Part Names
17. Power Cord
14. Nightlight Switch
15. Cooling Switch
16. Heating Switch
13. Self-Cleaning Switch
18. Drain Outlet
19. Condenser
About Your Water Cooler
English
4
Indicator Lights
Self-Cleaning Indicator Light
When the unit is placed into self-cleaning mode this indicator light will blink until
the cycle is complete. When the cycle is complete the light will turn o.
Heating Indicator Light
This light will indicate when the water is heating. The light will blink while the water
is heating and will turn o when it has reached the correct temperature of 185°F.
Cooling Indicator Light
This light will indicate when the water is cooling. The light will blink while the water
is cooling and will turn o when it has reached the correct temperature of 47°F.
Empty Bottle Indicator Light
This light will indicate that the bottle below is empty and will need to be replaced.
This red light will begin to blink to alert you of the empty bottle.
Self Clean
Cooling
Heating
About Your Water Cooler
English
5
Tech Specs
Avalon Models A14-S A14BLKS
Hot/Cold/Cool Output
Hot Water Capacity
Hot Tank Volume
Cold Water Capacity
Cold Tank Volume
Applicable Environment
Product Size
Packing Size
Net Weight/Gross Weight
Voltage/Frequency
Cooling Method
Heating Method
Heating Watts / Cooling Watts
Power Consumption
1.8L/min / 2.2L/min / 2L/min
4 L/H ( ≥ 185°F)
1.16 Liters
2.5 L/H ( ≤ 47°F)
3.6 Liters
39 ~ 104°F humidity ≤90%
13”(L)x12”(W)x41”(H)
16”(L)x15”(W)x45”(H)
35.5 lb /46.5 lb
115 V 60Hz
Compressor
Internal Element
420W / 100 W
520 W
This product is not recommended to be used at an altitude of above 1500 meters.
