Avalon A1TL Manuale utente
A few simple steps to ensure
perfect water, every time.
English
English
www.avalonh2o.com
We’re Here to Help
Let’s Connect
Call Us:
1.800.256.0695
Email Us:
support@avalonh2o.com
sales@avalonh2o.com
Live Chat:
Monday-Thursday: 9 a.m.-5:30 p.m.
Friday: 9 a.m.-4:30 p.m.
@avalon_h2o Avalon Water Coolers Avalonh2o
Follow our social media accounts and stay up to
date on the latest Avalon news.
We are also available
for live video chat!
English
Use and Care Guide
MODELS: A1TL • A2TL
Registration
Please visit the website below to register your new water cooler within the first
30 days of purchase. Registration within the first 30 days will activate your one
year warranty.
www.avalonh2o.com/register-my-avalon-cooler
Please keep your model number, order number and purchase date
for future support. You can reach us at 1-800-256-0695.
Model Number
Order Number
Purchase Date
English
Contents
About Your Water Cooler
Meet Your Avalon Product
Part Names
Indicator Lights
Tech Specs
Getting Started
Unpacking
Operation instructions
Cleaning
Rinsing, Cleaning and Draining
Cleaning
Troubleshooting
Safety
Warranty
1
2
3
4
6
7-9
16-18
19-21
23
11-13
14-15
English
English
1
Meet Your Avalon Product
About Your Water Cooler
English
Child Safety Feature
Ensures safe hot water
flows for the entire family
UL Listed
We design & manufacture
with your safety in mind
Custom Temperature
Piping hot,
or crisp cold water
Top Loading
Suitable for 3 or
5 gallon bottles
Attractive Design
Attractive design with
press-paddle spouts
2
Part Names
1. Bottle Supporter
2. Heating Indicator Light
3. Cooling Indicator Light
4. Power Indicator Light
5. Cold Water Spout
6. Cold Water Press Paddle
10. Drip Tray
7. Child Safety Lock
8. Hot Water Spout
9. Hot Water Press Paddle
11. Cooling Switch
12. Heating Switch
13. Power Cord
14. Drain Outlet
15. Condenser
About Your Water Cooler
English
3
Indicator Lights
Power Indicator Light
This light will remain on as long as the water cooler is plugged in to indicate that
the cooler is on.
Heating Indicator Light
This light will indicate when the water is heating. The light will remain on while the
water is heating and will turn o when it has reached the correct temperature of
185°F. As the water is dispensed the hot tank will refill and the water will heat. As
the water reheats this indicator light will turn on.
Cooling Indicator Light
This light will indicate when the water is cooling. The light will remain on while the
water is cooling and will turn o when it has reach the correct temperature of 47°F.
As the water is dispensed the cold tank will refill and the water will cool. As the
water cools this indicator light will turn on.
About Your Water Cooler
English
4
Tech Specs
Model A1TL • A2TL
Hot/Cold Temp Output
Hot Water Capacity
Hot Tank Volume
Cold Water Capacity
Cold Tank Volume
Product Size
Packing Size
Net Weight/Gross Weight
Voltage/Frequency
Cooling Method
Heating Method
Heating Watts / Cooling Watts
Power Consumption
2L/min / 2.2L/min
4 L/H ( ≥ 185°F)
1.02 Liters
2 L/H ( ≤ 47°F)
3 Liters
11.25”(L)x10.75”(W)x42”(H)
15.5”(L)x14.3”(W)x46.5”(H)
30.65 lb /34.8 lb
115 V 60Hz
Compressor
Internal Element
420W / 100 W
520 W
About Your Water Cooler
English
