B&C Speakers Hf Compression drivers DE 75 P Manuale utente

2" high frequency compression driver. The particular mylar/titanium

diaphragm using a 3" edgewound flat aluminium wire voice coil and

a optimized high energy ceramic magnet assembly produces smooth

response and excellent sonic properties .

Specification 1

Throat Diameter 50 mm (2 in)

Nominal Impedance 8 Ω

Minimum Impedance 7.8 Ω

Power Handling

(800 –20000 Hz)

Nominal280 W

Continuous Program3160 W

Sensitivity (1W/1m) 108 dB

Frequency Range 0.5 – 18 kHz

Recommended Crossover5800 Hz

Voice Coil Diameter 75 mm (3 in)

Winding Material Aluminium

Inductance 0.1 mH

Diaphragm Material Titanium

Flux Density 1.85 T

Also available in 16 Ω, data upon request

Mounting and Shipping Information

Four M6 holes 90° on 102 mm ( in) diameter

Overall Diameter 170 mm (6.7 in)

Depth 67 mm (2.6 in)

Net Weight (1 unit) .5 kg (9.9 lb)

Shipping Weight (2 units) 9.6 kg (21.2 lb)

Shipping Box (2 units) 210x210x190 mm

(8.3x8.3x7.5 in)

1 Driver mounted on B&C ME 75 horn.

2 2 hours test made with continuous pink noise signal (6 dB crest factor) within

the specified range. Power calculated on rated minimum impedance.

3 Power on Continuous Program is defined as 3 dB greater than the Nominal rating.

Applied RMS Voltage is set to 2.83V for 8 ohms and V for 16 ohms Nominal

Impedance. Average SPL from 500 to 18000 Hz.

5 12 dB/oct. or higher slope high-pass filter.
