The SPO-2000 is a microprocessor based pulse generator capable of calibrating any
phantom finger based heart rate monitor.
The unit has six available pulse rates ranging from 30 to 180 BPM. Each pulse rate has a
unique LED indicator.
The SPO-2000 is designed to work in conjunction with the FingerSimmanufactured by
BC Biomedical and available from BC Group International. The FingerSimis used to
verify the operation of pulse oximeters. The SPO-2000 adds calibrated pulse rates to the
functionality of the FingerSims.
BC GROUP
SPO-2000
PULSE OXIMETER SIMULATOR
4
This section looks at the layout of the SPO-2000 and gives descriptions of the elements
that are present.
OVERVIEW
2 Light Touch Keys
ACTIVE/STANDBY for
Controlling the Power
Generator.
SCROLL for selecting
the Pulse Rate.
FingerSimHolder
Connector for Power
Transformer
ON/OFF Switch
6 LEDs for Indicating
Pulse Rate (BPM)
2 LEDs for Indicating Status
ACTIVE for showing when the
Power Generator is active.
POWER for showing when the
Unit is On.
5
2 soft touch keys are provided for unit operation:
–This key is used to turn the pulse generator output ON and OFF.
–This key is used to select the desired pulse rate.
KEYS
6
There are eight LEDs to indicate the status of the system. They are marked POWER,
ACTIVE, 30, 60, 90, 120, 150, AND 180.
POWER –This LED indicates that the power switch is turned ON and the on board power
supply is functioning properly.
ACTIVE–This LED indicates that the system is in the ACTIVE mode and the solenoid is
being pulsed at the currently selected heart rate.
30 –This LED indicates that the currently selected heart rate is 30 BPM. This is the heart
rate that is selected when the system is first turned ON.
60 –This LED indicates that the currently selected heart rate is 60 BPM.
90 –This LED indicates that the currently selected heart rate is 90 BPM.
120 –This LED indicates that the currently selected heart rate is 120 BPM.
150 –This LED indicates that the currently selected heart rate is 150 BPM.
180 –This LED indicates that the currently selected heart rate is 180 BPM.
LED INDICATORS
7
When the system is first turned on the SPO-2000 will start in the standby mode with a
heart rate of 30 BPM.
Insert the desired FingerSiminto the rectangular opening on the SPO-2000.
NOTE: It is recommended that the FingerSimbe inserted with the printed side down to
minimize wear on the printing by the mechanism inside the SPO-2000.
Use the key to select the desired pulse rate. Then the output is enabled by
depressing the key. The ACTIVE LED will turn on and the FingerSimwill pulse
at the desired rate.
The pulse rate can be changed by depressing the key, in either the ACTIVE or
STANDBY mode.
Connect the finger probe of the pulse oximeter being tested to the FingerSim. Run the
probe’s cable underneath the SPO-2000.
The output is disabled by depressing the key. The ACTIVE LED will turn off and
the Phantom Finger will stop pulsing.
OPERATIONS
8
NOTE: The accuracy of the saturation percentage on the pulse oximeter being tested is a
function of the FingerSim-not the SPO-2000. The SPO-2000 only controls the pulse
rate. See the user information included with the FingerSimfor accuracy and related
data.
