Belkin F5D6001 Manuale utente

User Manual

F5D6001

802.11b Wireless

Desktop Network Card

Connect your desktop to a wireless network

P743056-D_F5D6001v3kMan8_03.qxd 9/5/03 4:58 PM Page 2

TABLE OF CONTENTS

Introduction

Features...............................................................................................1

Product Specifications............................................................................2

System Requirements.............................................................................2

Package Contents ..................................................................................2

Knowing your Desktop Network Card...............................................................3

Installing the Card.......................................................................................4

The Belkin Wireless Network Monitor Utility...................................................10

Troubleshooting.........................................................................................18

Information...............................................................................................19

P743056-D_F5D6001v3kMan8_03.qxd 9/5/03 4:58 PM Page 3

INTRODUCTION

Thank you for purchasing the Belkin Wireless Desktop Network Card (the Card).

This high-speed Card provides you with an innovative wireless networking

solution that is easy to set up and use. The Card transmits at a rate of 11, 5.5, 2,

or 1Mbps to let you share files and printers on the network—without the hassle

and inconvenience of connecting wires! Operating in the ISM band using Direct

Sequence Spread Spectrum (DSSS) transmission, the Card implements the IEEE

802.11b standard and supports Windows 98SE, 2000, Me, or XP operating

systems.

Features

The Card complies with the IEEE 802.11b standard in order to communicate with

other 802.11b-compliant wireless devices.

•2.4GHz ISM (Industrial, Science, and Medical) band operation

•Includes an easy-to-use profile manager for storing multiple wireless network

settings for work, school, home, etc.

•Wireless interface compliance with the IEEE 802.11b standard

•PCI interface, complies with PCI specification 2.1

•64- or 128-bit wireless (WEP) encryption

•Wireless access to networked resources

•Support for both Infrastructure and Ad-Hoc (peer-to-peer) networking modes

•Data rate of up to 11Mbps

o Supports 11, 5.5, 2, or 1Mbps rates (Auto-Rollback)

•Easy to install and use

•External detachable antenna

•LED link indicator

P743056-D_F5D6001v3kMan8_03.qxd 9/5/03 4:58 PM Page 1

Product Specifications

Host Interface: 32-bit, PCI 2.2-compliant

Power Consumption: 300mA (max.)

OS Support: Windows© 98SE, 2000, Me, or XP operating systems

Certification: FCC Class B, CE Mark, C-Tick

Operating Temperature: 0° C to 55° C

Storage Temperature: –25° C to 70° C

Typical Operating Range: Indoors: 160 ft. (50m) @ 11Mbps, 260 ft. (80m)

@ 5.5Mbps or lower

Outdoors: 490 ft. (150m) @ 11Mbps, 980 ft. (300m)

@ 5.5Mbps or lower

Humidity 10% to 90% non-condensing

System Requirements

•PC with available PCI expansion slot

•PC running Windows 98SE, 2000, Me, or XP

•CD-ROM drive (for loading software)

Package Contents

•Belkin Wireless Desktop Network Card

•External Antenna

•Software CD

•Quick Installation Guide

•User Manual

•Product Registration Card

INTRODUCTION

P743056-D_F5D6001v3kMan8_03.qxd 9/5/03 4:58 PM Page 2

Activity LED

Off No activity

Blinking Activity

Link LED

Solid Connected to a wireless network

Off Not connected

Antenna

Antenna Cable

Link LED

Activity LED

Threaded Connector

PCI Edge Connector

Warning! Your Card is sensitive to static electricity. Handle the Card

by the edges and avoid touching the PCI edge connector or any of

the components on the green printed circuit board.

KNOWING YOUR DESKTOP NETWORK CARD

P743056-D_F5D6001v3kMan8_03.qxd 9/5/03 4:58 PM Page 3

INSTALLING THE CARD

Installing your Card is done in three easy steps.

1. Install the software FIRST. If you install your Card into your computer before

you install the software, it will not work until you install the software.

2. Install the Card inside of your computer.

3. Let Windows finish installing the Card.

Step 1: Software and Driver Installation

1. Insert the CD into your CD-ROM drive.

2. The Belkin Wireless Desktop Network Card Setup Utility screen will

automatically appear. If it does not appear within 15-20 seconds, then

select your CD-ROM drive and double-click on the folder named “Files”.

Next double-click on the icon named “start.exe”.

3. In the menu window, drag your mouse over the “Install” button then select

“Click here” to start the software installation program.

NOTE: INSTALL THE SOFTWARE FIRST BEFORE YOU INSTALL THE CARD

INTO YOUR COMPUTER.

P743056-D_F5D6001v3kMan8_03.qxd 9/5/03 4:58 PM Page 4

INSTALLING THE CARD

4. The installer will start. You will see a progress screen. Go to the next step.

5. Next, you will see an introduction screen. Click “Next” to continue with the

installation of the Card.

6. If you are using Windows 2000 or Windows XP, you may see a screen similar

to the one below. This does not mean there is a problem. Select

“Continue Anyway”.

P743056-D_F5D6001v3kMan8_03.qxd 9/5/03 4:58 PM Page 5

7. When the software installation is complete, you will see a screen prompting

you to finish. Click “Finish”.

8. A message will appear telling you that you need to shut down your computer

to install the Card. Choose “Yes, I want to shut down my computer now” to

shut down your computer. Follow the directions in the next section to install

your Card inside of your computer.

INSTALLING THE CARD

P743056-D_F5D6001v3kMan8_03.qxd 9/5/03 4:58 PM Page 6

INSTALLING THE CARD

Step 2: Installing the Card into your PC

1. POWER OFF THE COMPUTER AND DISCONNECT THE POWER CORD.

2. Remove the screws that secure the computer cover and remove the cover.

3. Touch any metal part of the case to ground yourself. This will discharge any

static electricity that could damage your product or your computer.

4. Locate an empty PCI expansion slot. Confirm that the Card will fit into the

slot you have chosen.

5. Remove the port cover from the back of the PC that corresponds to the PCI

slot you selected. If there is a screw, place it in a safe place as you will be

using it to attach the Card to the computer chassis later.

6. Push the Card firmly into the PCI slot that you have chosen. Apply pressure

as needed until the connector is fully seated.

7. Now secure the Card with the screw that you previously placed in a safe place.

8. Carefully screw the antenna’s gold

connector onto the threaded

connector on the Card until it

is finger-tight. Do not use a

wrench to tighten the connector.

Place the antenna on top of the

computer’s case or on top of

your desktop while taking care

to keep it away from any solid

metal objects.

9. Replace the computer’s cover.

10.Now that the Card is installed,

you can reconnect all of the

cables and turn the computer

back on. Proceed to Step 3.

P743056-D_F5D6001v3kMan8_03.qxd 9/5/03 4:58 PM Page 7

INSTALLING THE CARD

Step 3: Finishing the Installation

1. After you have installed your Card and replaced the cover on your computer,

turn your computer back on and let it boot up.

2. Windows will detect that new hardware has been installed. Depending on

which version of Windows you are using, a window similar to the one

pictured below will appear. Select the option that will automatically install

the software.

3. If you are using Windows 2000 or Windows XP, you may see a screen similar

to the one below. This does not mean there is a problem. Select

“Continue Anyway”.

P743056-D_F5D6001v3kMan8_03.qxd 9/5/03 4:58 PM Page 8
