Beta Three CPM110P Manuale utente

CPM110P

UM-CPM110P-20130408 ver A

User Manual

10"Two-way Full Range

Active Coaxial Speaker

CPM SERIES COAXIAL SPEAKERS

文件（图）名版本第㌯댠㌯눱ヒ³

英文说明书

产品名称

客户⿆럅옯型号

文件（图）号

专业音箱

䴱䴱刯β㌯䴱䴱䴱P

10.

Read the instruction first before using this product.

Pay attention to all warnings.

Obey all operating instructions.

Do not expose this product to rain or moisture.

Do not block any ventilation openings. Install according to instructions .

Do not install this product near any heat source, such as , heater, burner, or any other equipment with heat radiation .

Only use spare parts by manufacturer.

Pay attention to the safety symbol on the of the cover.

manual

Please keep this manual for future reference

Clean this equipment with a dry cloth.

manufacturer's

supplied the

outside

SAFETY INSTRUCTIONS

PLEASE READTHIS MANUAL FIRST

Thank you for a buyin product. Read this manual first as it will help you operate the system properly. Please keep this manual

for future reference. g

WARNING:

Thisproduct mustbeinstalledbyprofessionals.Whenusing hangingbracketsorrigging other than those supplied with

theproduct,pleaseensuretheycomplywiththelocalsafetycodes.

Theexclamationpoint withinan equilateral triangleis intendedtoalertyou tothe presenceofimportant

operatingand servicinginstructions.

ATTENTION:Don'trefitthesystemorsparepartswithoutbeingauthorizedasthiswill .voidthewarranty

WARNING: Don't (suchas candles) theequipment.placenakedflames closeto

文件（图）名版本第㏒댠䴱눱ヒ³

英文说明书

产品名称

客户⿆럅옯型号

文件（图）号

专业音箱

䴱䴱刯β㌯䴱䴱䴱P

CPM110P

CONTENT

Features

Description

Applications

AMPLIFIER MODULE

INSTALLATION

Mounting Accessories

Installation Reference

INTRODUCTION

Technical Sheet

2D Dimension

TECHNICAL SPECIFICATION

Amplifier Module

CONTENT

CPM Series Coaxial Speakers

Product information is subject to change without

prior notification. Please visit www.elderaudio.com

for latest updates.

Frequency Response Curve & Distortion Curve

β3 CPM108p is a 10"Two-way Full Range Coaxial Speaker.

Strict quality control during the R&D, manufacturing,

materials inspection, procedure inspection and shipment

inspection make sure every unit meets the high standard

demand.

The cabinet is made of high intensity PLY board. Special

multilayer black painting with scratch-resistand and erode-

resistand feature protect the cabinet surface perfect.

Selected POLYESTER damping materials absorb cabinet

stand wave effectively. Built-in crossover circuit and

different voltage output give the user more options.

Aiming at this special cabinet, the transducers used are

optimized by our experienced engineers who focus on the

magnetic system and vibration system.To get the excellent

performance, the engineers take a lot of advanced

technology to decrease the magnetic impendence and

lower the magnetic leakage, and not increase the

transducer weight.

Description

CPM110P

CPM Series Coaxial Speakers

10"Two-way Full Range Active Coaxial Speaker

INTRODUCTION

Two transducers two way full range speaker with coaxial

horn, computerized stimulation design.

Features

Applications

Multifunctional hall

Small Auditorium

Church

Conference room

Small performance

HF horn is mounted on the LF axis.

Used for full range sound reinforcement and can be used

as ground monitor speaker.

Apply to monitor, conference system and small scale

performance.

Flexible installation according to actual application.

Performance enhanced with built-in DSP.

New generation Class D amplifier, durable and reliable.

LINE OUT A

MIC/LINE IN A

LINE OUT B

PWR SIG CLIP

MUSIC FLAT

LOWCUT

LINE MIC

MODE SYSTEM

MIX OUT

LINE IN B

VOLUME

0 dB

OFF

POWER

AC INPUT

AC220-240V,100W,50Hz ,T2.5AL

CPM110P

1 2 3 4 5 6 7 8 9

11 1310 12 14 17

CPM110P

1、Line input signal indicator

2、Microphone input signal indicator

3、Music mode

4、Flat mode

5、Low cut mode

6、Power indicator

7、Signal indicator

8、Clip indicator

9、Power ON/OFF switch

10、Line input B

11、Line/microphone input A

12、Line output B

13、Line/microphone output A

14、MIX output

15、Volume control

16、Protection fuse. Use only fuse of the

correct amp rating.

17、Power supply input. Make sure that

the voltage is set for your country's

correct voltage.

AMPLIFIER MODULE

Rear Panel Amplifier Module

CPM Series Coaxial Speakers

CPM110P

CPM Series Coaxial Speakers

Warning:Make sure the mounting accessories

safety factor not less than 5:1 or meet the local

standard during installation .

INSTALLATION

Mounting Accessories(Optional)

M10 mounting points are very convenient and efficient for

the different application with special brackets.

Installation Reference

1.Reference A

2.Reference B

1. U-Bracket

200001000010001005020

180

108

100

110

120

130

Sensitivity (dB)

Frequency (Hz)

-36

-108

-180

CPM110P TECHNICAL SPECIFICATION

Specification

Frequency response(-3dB):

Max.SPL:

Transducer:

Input:

Connector:

Input impedance(line):

Input level:

Input overloading level:

Wire connection:

Heat radiation:

Power cable:

80Hz-20kHz

123dB/129dB(PEAK)

1 10"Woofer×

Channel one (Mic/Line) balanced input

XLR for input, XLR for output

20Kohm balanced input, 10Kohm unbalanced input

0 dBV (0.775V rms, 1.0V peak)Line-100Hz

Maximum input level 8V peak

pin 1: ground; pin2: signal +; pin3: signal -

Forced air-cooled drives

IEC 3 pin power connector

1 44mm×Compression Driver

Safety voltage range:

Cabinet:

Handle:

Painting:

Cabinet dimension(W x D x H):

Packing dimension(W x D x H)::

Net weight:

Gross weight:

AC 220V-240V~50/60Hz

Mounting accessories：

Rated impedance: 8 Ohms

CPM Series Coaxial Speakers

Frequency Response

2nd Distortion

3rd Distortion

Frequency response curve & Distortion curve

Power supply consumption power(static) :

Amplifier power output: 20W

100W

2 x M10 Mounting points

Plywood,wedge shaped

1 x Wooden handles

Cabinet coated by Polyurethane paint; grille is powder coated

13.5kg (29.7 lb)

15.5kg (34.1 lb)

385 x 406 x 317mm(15.2 x 16.0 x 12.5in)

495 x 395 x 485mm(19.5 x 15.6 x 19.1in)

385mm

[15.2in]

317mm

[12.5in]

406mm

[16.0in]

CPM110P

CPM Series Coaxial Speakers

TECHNICAL SPECIFICATION

2D Dimension

Side viewFront view

Back view

Bottom view

Notes:

www.beta3pro.com
