Beta Three S215a Manuale utente

Beta Three

S215a

ED-B3-MA-050511-001

User s manual

ACTIVE WOODEN SPEAKER

High intensity configuration

50Hz~18KHz

Treb:100W Bass:300W

120dB(Free Field)

100Hz: 12dB/10Hz: 12dB

Balance:20K Unbalance:10K

80 X50

XLR J3P/XLR K3P

~110V/~220V 50Hz Manual selet

458X542X747mm

37Kg

42Kg

Built-in Crossover two way full ranger active speaker

Features

Specifications

ACTIVE WOODEN SPEAKER

Fequency Response(-3dB):

Dispersion(H V):

Rated Power(RMS):

Input Impedance:

Input Connectors:

Net Weight(1Pcs):

Gross Weight:

Dimensions (W D H):

Packaging Dimensions 1pcs/pack(W D H):

Max SPL(1m):

System:

Frequency adjust:

Power supply:

Cabinet configuration

Two way phase reversed active wooden subwoofer

with two transducer professional efficient transducer,

computer simulating design

2 way active full range speaker

One 15'' woofer

One 3" compression driver with titanium diaphragm

Bi-amplifier design forindependant HF, LF, active

frequency compensation , auto electrical limit

protection adjust for LF/HF

Cabinet built with high intensity materials

Flying point in the cabinet, support hole in the bottom

big dynamics and high sensitivity, MF/HF is very clear and LF

is very powerful

Suited for avenueswhere require highquality reinforcement,

like bar,bands, cimema, multi-functional room,VIP room

meetingroom etc.

Suitable for moving performance, such as commerial promotion,

bands performance, party, can be used as the reinforce speaker

living performance ofelectric guitat ,keyboard

User s manual

652x568x865mm

747

458

542

Cabinet Dimension

Installation drawing

ACTIVE WOODEN SPEAKER User s manual

Stand

Speaker

Ceiling

Steel wire

Flying mounting buckle

Speaker

RRUser sM anual

S215a

ACTIVE WOODEN SPEAKER

Beta Three
