Beta Three QS600T Manuale utente

QS600T

6"TwoWay Full Range

Pro Speaker System

User Manual

UM- QS 6 0 0 T - 2 0 1 5 0 3 2 6 v e r A

10.

Read the instruction first before using this product.

Pay attention to all warnings.

Obey all operating instructions.

Do not expose this product to rain or moisture.

Do not block any ventilation openings. Install according to instructions .

Do not install this product near any heat source, such as , heater, burner, or any other equipment with heat radiation .

Only use spare parts by manufacturer.

Pay attention to the safety symbol on the of the cover.

manual

Please keep this manual for future reference

Clean this equipment with a dry cloth.

manufacturer's

supplied the

outside

SAFETY INSTRUCTIONS

PLEASE READTHIS MANUAL FIRST

Thank you for a buying product. Read this manual first as it will help you operate the system properly. Please keep this manual

for future reference.

WARNING:

Thisproductmustbeinstalledbyprofessionals.When using hangingbracketsorrigging other thanthosesuppliedwith

theproduct,please ensure they complywith thelocalsafetycodes.

Theexclamationpointwithin anequilateraltriangleis intendedto alertyouto thepresenceof important

operatingandservicing instructions.

ATTENTION:Don'trefitthesystem or sparepartswithout being authorizedasthis will .voidthe warranty

WARNING: Don't (suchas candles) theequipment.placenakedflames close to

QS600T

Product information subjects to be updated without

notification, please visit www.elderaudio.com for

latest update.

CONTENT

Features

Description

Applications

CONNECTION

Terminal Plate

INSTALLATION

Installation Accessories

Installation Reference

INTRODUCTION

System Connection Reference

Technical Sheet

Frequency Response And Impedance Curve

2D Dimension

TECHNICAL SPECIFICATION

6"TwoWay Full Range Pro Speaker System

Qs400 adopts multifunctional structure design. it’s

KTV

QS600T

6"TwoWay Full Range Pro Speaker System

Features

Description

Applications

INTRODUCTION

6"TwoWay Full Range Pro Speaker System

Two new 3-inch paper cone mid-high frequency drivers.

6-inch paper cone low frequency driver.

High intensity injection moulding cabinet.

Dispersion 140° x 160°.

Frequency response 80 Hz 16k Hz (-3dB).

Sensitivity 88dB, Max SPL 120 dB.

3 x M8 hang point.

Customizable grill and cabinet color.

QS600T is a 6"2-way full range speaker system with wide

dispersion. Its sound is nature and clear while the cabinet

is handy, compact and the appearance elegant and

fashionable. It's applicable in small and medium performing

stages, KTV, multi-function halls as sound monitoring and

major and fill sound reinforcement.

QS600T adopts two 3-inch new paper cone high frequency

speakers which greatly enhance the performance and power

loading capacity in the mid-high frequencies.The optimized

6-inch low frequency driver can realize highest clearance

and lowest distortion in high sound pressure.The 12 dB

attenuation slope cross frequency circuit enables smooth

frequency response. And the full range circuit protecting

system provides higher security.

The cabinet is injection moulded with high intensity

polypropylene.The delicate designed shape provides best

structure strength and acoustic characteristics.The colors

of grill and cabinet are available for customization.

applicable both in mobile and stage performance. Our

special designed accessories with the 3 x M8 hanging point

can be used in various installation requirements easily and

conveniently.

. Multifunction Rooms

Public Avenue

Monitor

Small Performance

QS600T

CHA

BRIDGE IN

CHB

SIGNAL GND

SIGNAL +

SIGNAL -

BRIDGE

PARALLEL

STEREO ON

OFF

50HZ

25HZ

OFF

CHB OUTPUT

CHA OUTPUT

POWER

CABLE

FUSE

5HZ

CAUTION

BRIDGE

OUTPUT ASSIGNMENT:

BRIDGE MONO OUTPUT:

CHA :

PIN1+ : SIGNAL GND

CHA: PIN 1+ :

PIN 1 - :

PIN 2+ :

PIN 2 - :

CHA SIGNAL

CHA GND

CHB SIGNAL

CHB GND

CHB: PIN 1+ :

PIN 1 - :

PIN 2+ :

PIN 2 - :

CHB SIGNAL

CHB GND

PIN2+ :

Serial no:

Special design for big power！

RISK OF ELECTRIC SHOCK

DO NOT OPEN

MODE LF FILTER GROUND

CLIPLIMITER

INPUT

PIN1:

PIN2:

PIN3:

Red：1+ Black：1-

1- Crossover

LOW

HIGH

QS600T QS600T

6"TwoWay Full Range Pro Speaker System CONNECTION

Terminal Plate

System Connection Reference

Attention: The impedance of connected speaker must match the impedance of amplifier output.

Attention: Make sure the polarity of speaker and amplifier correctly.

QS 600T connects the amplifier with a wire clamp.

QS600T

1. Ceiling

2.Wall

3. Support

For 35 mm diameter tripod

6"TwoWay Full Range Pro Speaker System

INSTALLATION

Installation Accessories Installation Reference

Warning:

safety factor not less than 5:1 or meet the local

standard during installation .

Make sure the mounting accessories

QS600T has 3 hanging points to work together with the

special designed accessories for fast and convenient

hanging, wall-mounting and on standing with adjustable

angles.

1. Hanging Bracket

2.Wall Bracket

3. Standing Bracket

(W x H x H)

SpeakerTesting Method

1. Frequency response

Use Pink noise to test the speaker in the anechoic room,

adjust the level to make the speaker work at its rated

impedance and the power output is 1W, then test the

frequency response 1m away from the speaker.

2. Sensitivity

Use full range Pink noise which was modified by EQ curve

to test the speaker in the anechoic room, enlarge the signal

to make the speaker work at its rated impedance and the

power output is 1W, then test the sensitivity 1m away from

the speaker.

3. MAX.SPL

Use full range Pink noise which was modified by EQ curve

to test the speaker in the anechoic room, enlarge the signal

to make the speaker work at its instant power output level,

then test the SPL 1m away from the speaker.

4. Rated Power

Use the pink noise according to IEC#268-5 to test the speaker,

enlarge the signal for continuous 100hours, the rated Power

is the power when the speaker will not incur hot damage or

mechanics damage.

QS600T

2×3 High frequency drivers"

80Hz-16kHz

1×6 Woofer"

6"TwoWay Full Range Pro Speaker System TECHNICAL SPECIFICATION

Technical Sheet

Frequency Response And Impedance Curve

Frequency response curve

Impedance curve

Two way full range speaker

Tweeter:

System:

Woofer :

Frequency response(-3dB):

88dB

8 Ohms

140° x 160°

114dB/120dB(PEAK)

2.5 kHz

3×M8 Bracket lifting point

Cabinet Exterior with/without

polyurethane spraying treatment

(depends on colors)Grill with cloth

80W (RMS)

160W (MUSIC)

320W (PEAK )

Dispersion(H¡Á V):

Sensitivity(1W@1m):

Max.SPL(1m):

Power:

Rated impedance:

Cabinet:

Mounting accessories:

Painting:

Cabinet dimension:

Package dimension:

N.W.(2pcs):

G.W.(2pcs):

Connector:

Crossover point:

Wire clamp

Polypropylene injection moulding

10kg(22 lb.)

399mm×241mm×229mm

(15.7in×9.5in×9in)

9kg(19.8 lb.)

452mm×310mm×525mm

(17.8in×12.2in×20.1in)

Impedance (Ohms)

5k 10k 20k

Sensitivity (dB)

100

Frequency (Hz)

50 100 200 500 2k1k

399mm

[15.7in]

Toy view

Front view

Side view Back view

QS600T

229mm

[9in]

241mm

[9.5in]

6"TwoWay Full Range Pro Speaker System

TECHNICAL SPECIFICATION

2D Dimension

Bottom view

Notes:
