Billion Modem/Router ADSL BIPAC-7100S Manuale utente
BIPAC-7100S
Powerline WLAN
ADSL Router and Adapter
VoIP ADSL Modem/Router
Broadband Router
SHDSL Bridge / Router Wireless ADSL Router
Wireless Client
High-speed Internet Access with ADSL
The BIPAC-7100S complies with ADSL standards for worldwide deployment and supports downstream rates of up
to 8Mbps and upstream rates of up to 1 Mbps. It is designed for small office, home office and residential users,
enabling high-speed Internet connections. User can enjoy ADSL services and broadband multimedia applications
such as interactive gaming, video streaming and real-time audio much easier and faster than ever before.
Ease of Use with Quick Start Setup
The Quick Start setup allows easy installation of the BIPAC-7100S. With this simple Quick Start setup, end users
can enter the necessary ISP information and start surfing the Internet immediately.
SOHO Firewall Security and Parental Control
Along with the built-in NAT natural firewall feature, the BIPAC-7100S also provide advanced hacker pattern-
filtering protection. It can automatically detect and block Denial of Service (DoS) attacks, such as IP Spoofing, Ping
of Death, Land Attack, etc. Powered by URL blocking and packet filtering, the BIPAC-7100S supports parental
control to Internet access according to web addresses, web address keywords or the time of a day. It ensures your
family or company a safe surfing environment.
Easy Network Management
The Web-based User Interface makes the BIPAC-7100S extremely easy to install and manage your network. With
built-in DHCP server, system administrators can easily attach this security router into existing network and manage
the IP assignment without re-configuring the other stations. The built-in diagnostic test tool is extremely useful to
troubleshoot the problem if necessary.
Virtual Private Network (VPN)
The BIPAC-7100S supports embedded IPSec VPN protocol (IKE, 3DES and DES), for establishing a private
encrypted tunnel over the public Internet to ensure transmission security between two or more sites.
•High-speed Internet Access with ADSL
•Ease of Use with Quick Start Setup
•IPSec/IKE Virtual Private Network
•Universal Plug and Play (UPnP) Compliant
•SOHO Firewall Security with DoS Prevention
•Parental Control with URL Blocking and Packet Filtering
•Dynamic Domain Name System (DDNS)
•Web-based Configuration, Management and Firmware
Upgrade
•Ideal for residential users
ADSL Modem / Router
ADSL VPN Firewall Router
with Single Ethernet port
Securely share your high speed ADSL connection
Feature & Specification
ADSL Compliance
•Compliant with ADSL Standards
- Full-rate ANSI T1.413 Issue 2
- G.dmt (ITU G.992.1)
- G.hs (ITU G.994.1)
- ADSL over ISDN/U-R2
•Sync. Rate: up to 8Mbps for download rate and
1Mbps for upload rate
Network Protocols and Features
•NAT, static routing and RIP-1/2
•Universal Plug and Play (UPnP) Compliant
•Dynamic Domain Name System (DDNS)
•Virtual Server and DMZ
•SNTP, DNS relay and IGMP proxy
•POP3 (email account checking)
Hardware Specification
Physical Interface
•WAN: ADSL port
•Factory default reset button
•LAN: 10/100M auto-crossover (MDI/MDI-X)
•Power jack
• Power switch
Physical Specification
•Dimensions: 7.28" x 5.0" x 1.85"
(185mm x 127mm x 47mm)
Power Requirement
•Input: 12V DC, 1A
Specifications are subject to change without notice.
ATM and PPP Protocols
• ATM Adaptation Layer Type 5 (AAL5)
•Multiple Protocol over AAL5 (RFC 2684,
formerly RFC 1483)
•Bridged or routed Ethernet encapsulation
•VC and LLC based multiplexing
•PPP over Ethernet (PPPoE)
•PPP over ATM (RFC 2364)
•Classical IP over ATM (RFC 1577)
•OAM F4/F5
Firewall
•Built-in NAT firewall
•Prevent DoS attacks including IP Spoofing,
Land Attack, Ping of Death, TCP SYN
Flooding, etc.
•E-mail alert whenever detect attacks
•Packet filtering based-on MAC address, IP
address & port number
•URL blocking – string or domain name
detection in URL string
Virtual Private Network (VPN)
•Embedded IPSec/IKE
•DES and 3DES encryption for IPSec
•L2TP/PPTP/IPSec pass-through
Management
•Ease of use with Quick Start setup
•Web-based GUI for remote and local
management
•Firmware upgraded via Web-based GUI and
FTP/TFTP
•System & intrusion detection log
•SNMP MIB support
•Support DHCP server/client/relay
•Diagnostic test utility
Operating Environment
•Operating temperature: 0 ~ 45
ºC
•Storage temperature: -20 ~ 70 ºC
•Humidity: 20 ~ 95% non-condensing
Billion Electric Co., Ltd.
8F, No.192, Sec.2, Chung Hsing Road,
Hsin Tien City, Taipei Hsien, Taiwan
TEL : +886-2-2914-5665
FAX : +866-2-2918-6731,+886-2-2918-2895
www.billion.com
