Binatone SYMPHONY 2600 Manuale utente

"Symphony Symphony 2600 System"

User Guide - Front Page

1) Colour : White background black letters.

2) Material : 80lb book paper.

3) Size: 105mm(w) x 145mm(H) or A6

"Symphony 2600 System"

User Guide - Back Page

Ver. 1, Ju 07 Before operating this set,

please read these instructions carefully.

TELEPHONES WITH

USER GUIDE

SMS MESSAGING

THIS EQUIPMENT IS NOT DESIGNED FOR

MAKING EMERGENCY TELEPHONE CALLS

WHEN THE POWER FAILS. ALTERNATIVE

ARRANGEMENTS SHOULD BE MADE FOR

ACCESS TO DIAL EMERGENCY SERVICES.

DIGITAL CORDLESS

Symphony 2600 System

Important note — emergency calls

The Symphony

emergency calls when the mains power fails. So you

should make alternative arrangements for access to

Emergency Services.

(This means that you should also have a basic

phone that does not need mains power, connected

to your line so that you can make calls during a

power failure.)

If you need help …

The Binatone Help Line is available from 9.00 am to

5.00 pm, Monday to Friday, on

Calls are charged at Local Call rate.

Unpacking your Symphony 2600 system

In the box are:

■the cordless handset (up to six, depending on

which Symphony system you’ve bought)

■the base unit

■two rechargeable batteries and a battery

compartment cover for each handset

■atelephone line cable for the base unit

■amains power lead and adapter for the base

unit

■up to five , each with a separate

mains power lead and adapter, for multi-

handset systems

Keep the packaging materials in a safe place in

case you later need to transport the unit.

Keep your sales (till) receipt, which is your

guarantee.

Or visit our website, at:

http://www.binatoneonline.com/

charger pods

0845 345 9677

2600 is not designed for making

2600

INT (Intercom) button

Press and hold for 2 seconds to

make an intercom call (if you

have more than one handset).

Where to find it

CHARGE light

This comes on when the handset'¡¯s

batteries are being charged.

PHONE

Press to begin or answer a phone call.

Press during a call to switch the

speakerphone on and off.

(Note: the speakerphone won’t work

if the batteries are low.)

Left and right Soft buttons

Press to select the functions shown

above them on the display (for

example,

If the display is blank

Press the button to switch the handset on

Display

For details of how to change the

screen background, refer to the

functions in the

section headed ‘Quick reference

guide to the menus’.

Before you can use the handset to make calls you will need to fit

and fully charge the batteries, as described on pages 5to 6.

HANDSET LOCATOR button

Press to make all registered handsets

ring (useful if you've forgotten

where you put a handset).

R (Recall) button#

Press and hold this button for a Recall signal.

IN USE light

Arrow buttons

Press or

Press to navigate through the menu on the

display.

Press in idle mode for short-cut functions

during a call to adjust the

volume in the earpiece.

to go straight to the

menu. SMS text

messages

to go straight to a list of

(CID) records. Caller

Display

HANG UP /C/ button

Press to end a call.

Press while using menus to cancel and

return to idle mode.

Press and hold for 2 seconds to turn

the handset on and off.

Short cuts

To subscribe to network features like Caller Display and Call Waiting,

simply call your network service provider (the company which

supplies your telephone line). You don’t need to do anything special

on your Symphony 2600 phone to set these features up.

to go straight to a list of

records. redial

Menu Back

button

Wallpaper

button

Handfree

CID

connection to the telephone line.

Flashes when you have a

Flashes when you have message(s).

CID

Contents

Read these notes first 3

Choosing a site for the base unit and

charger pod 3

Radio signals between handset and

base unit 3

Mains power connection 3

Installation and set-up 4

Before you start

Electrical safety

Interference

‘Out of range’ warning

Exploring the display

Shortcut buttons 9

To lock the keypad

Switching on and off

Ringer melodies and volumes 11

Your handset’s name 12

Time and date 13

Making and answering calls 14

To make a call 14

To answer a call 14

To end a call 15

The speakerphone 15

Muting the microphone 15

Earpiece volume 15

Last Number Redial 16

… and options in the Redial list 16

The Phone Book

(memory dialling) 18

To open the Phone Book 18

To store a number 18

To make a memory call (short-cut

method) 19

To make a memory call (Phone Book

method) 19

To change a stored number 20

To delete a Phone Book entry 21

To delete all Phone Book entries 21

Caller Display 22

To review Caller Display records

(shortcut) 23

To review all call information 23

Options in the Caller Display lists 24

… to delete a entry from the list 24

… to store a number in the Phone Book

Using a multi-handset system 25

To make an intercom call 25

To end an intercom call 25

To transfer a call 26

To shuttle between two calls 26

To set up a three-way conference

To page all handsets from the

base unit 27

continued overleaf …

Handset registration 28

To re-register or to register a new

handset 28

To register to a different brand of

base unit

Binatone Help Line: 0845 345 9677

(Local Call rate)

889

10 11

… to delete all entries from the list 24

SMS text messaging — read

thisfirst

Caller Display

Registering for the SMS service

The SMS Send and Receive numbers

SMS message boxes

30 30

31 31

Contents

SMS text messaging

To write and send a text message

you hear an error tone

To read your messages

… and to store a caller’s number in the

Phone Book

… or to delete messages from the Inbox

To reply to a message

To delete a message from the Outbox

or Draft Box

To check or change the Send and

Receive numbers

Quick reference guide to the

menus

Troubleshooting

Cleaning and care

Declaration of conformity

Guarantee and service

Technical details

Connection and conditions for use

You can connect your Symphony

a line connected to a local exchange, with its own phone number; to an

extension socket connected to a DEL; or to an extension on an

approved compatible PBX. Do not connect the Symphony

extension to a payphone.

The ringer equivalence numbers (RENs) of all instruments (phones,

fax machines, etc.) connected to an exchange line must not add up to

more than 4 — otherwise, one or more of them may not ring and/or

answer calls correctly. The Symphony

other telephones have a REN of 1 unless marked otherwise.

http://www.binatoneonline.com/

...If

To forward a message to another

receiver

To switch SMS receotion on

To change write format

36 37

To select the send server

2600 to a direct exchange line (DEL) —

2600 as an

2600 has a REN of 1, and most

Read these notes first

Choosing a site

for the base

unit and

charger pod

The base unit and charger pod(s) should be placed on a

level surface, in a position where:

■the mains adapter plug will reach an easily accessible

230-V AC switched mains supply socket — never try

to lengthen the mains power cable

■the base unit’s telephone line cable will reach your

telephone line socket or extension socket (the charger

pod does not have a telephone line connection)

■it is not close to another telephone — this can cause

radio interference

■it is not close to a sink, bath or shower, or anywhere

else where it might get wet

■it is not close to other electrical equipment — fridges,

washing machines, microwave ovens, fluorescent

lights, TVs etc.

!If you’re using the SMS text messaging facility,

please note that only one SMS phone connected to

the line can receive messages. So you shouldn’t

connect another SMS-compatible phone to the same

line as your Symphony

Radio signals

between

handset and

base unit

To use your handset and base unit together, you must

be able to establish a radio link between them. Be

aware that:

■Any large metal object — like a refrigerator, a mirror

or a filing cabinet — between the handset and the

base unit may block the radio signal.

■Other solid structures, like walls, may reduce the

signal strength.

Mains power

connection IMPORTANT — The Symphony

charger pod must be used with the mains adapter

supplied with the unit. Using any other adapter will

result in non-compliance with EN60950, and will

invalidate any approval given to this apparatus.

Binatone Help Line: 0845 345 9677

(Local Call rate)

2600.

2600 base unit and

Installation and set-up

Choose a suitable site for the

base unit See page 3

Plug the mains adapter into a 230 V AC, 50 Hz mains

socket, with the switch on the socket set to OFF

Connect the mains

power lead and the

telephone line cord

into the underside of

the base unit

Use the telephone line

cord supplied with your

Symphony

not use any other

telephone line cord

See the note

on page 3

4Switch on at the mains socket

http://www.binatoneonline.com/

2600 — do

Installation and set-up

Fit the rechargeable batteries in each handset

A+

–

. Fit the two batteries as shown,

making sure you match the and

ends to the markings in the

battery compartment

B. Fit the battery compartment

cover, sliding it into place

and pressing firmly to make

sure it is secure

Battery safety

—batteries in the handset they may

burst, causing damage. Use the

rechargeable batteries supplied.

Plug the mains adapter into a 230 V AC,

50 Hz mains socket, with the switch on

the socket set to OFF

Switch on at the mains socket

If you have one or more charger pods …

See the note

on page 3

Caution : DON’T use non-rechargeable

Binatone Help Line: 0845 345 9677

(Local Call rate)

Installation and set-up

8Charge the batteries for 15 hours

The battery charge level symbol should

increase by one bar every half hour when

you’re charging an empty battery. If you

think that the symbol isn’t showing the

correct battery charge level, remove and

refit the batteries.

Keeping the batteries charged

When you don’t need to use the

handset (for example, overnight or

when you go out), replace it on the

base unit or charger pod, to keep the

batteries charged.

Whenever the battery charge level

symbol shows ‘nearly empty’( ),

place the handset on the base unit or

charger pod to charge the batteries.

Before you use the handset for the first time,

it’s important to charge the batteries fully.

The handset ‘beeps’ when it’s correctly in

position on the charging cradle.

Leave the handset on the charging cradle

for 15 hours.

Make sure mains power is

switched on at the socket if you

want to use the phone — it will

not work without electrical power

Connect the base unit to the telephone line

Switch off power at the mains socket

Insert the telephone line plug into the

socket as shown

Switch mains power back on

Use the plug

to raise the

shutter before

pushing it

into the

socket

NOTE: the charger pod does not have

a connection to the telephone line.

Battery charge

level symbol

The Charge

light comes on.

http://www.binatoneonline.com/

CID

eG :e

ifor

cs tl

etisopmoC

Installation and set-up

Binatone Help Line: 0845 345 9677

(Local Call rate)

If you have a Broadband line

If you connet your telephone to a line with broadband connection,

you will need to insert a microfilter(not included) between the

telephone and telephone line,otherwise you may get interference

between the telephone and the broadband,whichcould cause

problems.

In a home with broadband,every telephone must have a microfilter

connected,not just the one at the telephone point that your modem

is connected to.If you need more broadband microfilters,contact

your broadband supplier.

CID

Indice

Altri manuali Binatone Telefono senza fili

Binatone

Binatone Style 1820 Manuale utente

Binatone

Binatone E3300 Manuale utente

Binatone

Binatone IDECT V2I Manuale utente

Binatone

Binatone iDECT C10i Single Manuale utente

Binatone

Binatone ICARUS 200 SYSTEM Manuale utente

Binatone

Binatone SYMPHONY 3325 Manuale utente

Binatone

Binatone Brick 4home edition Manuale utente

Binatone

Binatone Vesta 1305 Call Blocker Manuale utente

Binatone

Binatone Ultra XD1220 Manuale utente

Binatone

Binatone Concept Combo 3525 Twin Manuale utente

Binatone

Binatone BIG BUTTON 510 SYSTEM Manuale utente

Binatone

Binatone Solas 1520 Triple Manuale utente

Binatone

Binatone Elite 2025 Manuale utente

Binatone

Binatone The brick Manuale utente

Binatone

Binatone SYMPHONY 2610 System Manuale utente

Binatone

Binatone ICARUS 2010 system Manuale utente

Binatone

Binatone DP270 Manuale utente

Binatone

Binatone Eclipse Plus Manuale utente

Binatone

Binatone Activity 2600 Manuale utente

Binatone

Binatone ICARUS 1500 Manuale utente

Binatone

Binatone FUSION 2200 Manuale utente

Binatone

Binatone SYMPHONY 2210 Manuale utente

Binatone

Binatone Lifestyle 1900 Manuale utente

Binatone

Binatone iDECT Eclipse Plus Single Manuale utente

Manuali Telefono senza fili popolari di altre marche

3Com

3Com NBX Manuale utente

Panasonic

Panasonic KX-TGK210HK Manuale utente

Panasonic

Panasonic KX-TCA181EX Manuale utente

BT FREESTYLE 3200 Manuale utente

AT&T

AT&T CL84102 Manuale utente

BREZZICNI

BREZZICNI CL-3622 Manuale utente

Panasonic

Panasonic KX-TG1831NZ Manuale utente

Panasonic

Panasonic KX-TG7301E Manuale utente

Furuno

Furuno FM-4721 Manuale utente

Sanyo

Sanyo CLT-J70 Manuale utente

Amplicomms

Amplicomms BigTel 201 Manuale utente

GE 26992 Manuale utente

AT&T

AT&T E1812B Manuale utente

Sanyo

Sanyo CLT-670 Manuale utente

GE 15432970 Manuale utente

Curtis

Curtis TC595 Manuale utente

Gigaset

Gigaset Gigaset 3000 Micro Manuale utente

Poly

Poly VVX D230 Guida all'installazione
