BlackVue DR750X-2CH Manuale utente

DR750X-2CH

instagram.com/BlackVueofficial

ABN Tower 4F, 331, Pangyo-ro, Bundang-gu, Seongnam-si,

Gyeonggi-do, Republic of Korea, 13499

Headquarter

FCC ID: YCK-DR750X-2CH / HVIN : DR750X-2CH

ENGLISH/NEDERLANDS

DR590X-1CH

DR590W-2CH

BLACKVUE

DR590X-1CH

For manuals, customer support and FAQs go to www.blackvue.com

Voor handleidingen, Customer Support en Veelgestelde Vragen, ga naar

www.blackvue.com

Important safety information

For user safety and to avoid property damage, read through this manual and follow

these safety instructions to use the product correctly.

yDo not disassemble, repair, or modify the product yourself.

Doing so may cause re, electric shock, or malfunction. For internal inspection and

repair, contact the service center.

yDo not adjust the product while driving.

Doing so may cause an accident. Stop or park your car in a safe place before

installing and setting up the product.

yDo not operate the product with wet hands.

Doing so may cause electric shock.

yIf any foreign matter gets inside the product, detach the power cord immediately.

Contact the service center for repair.

yDo not cover the product with any material.

Doing so may cause external deformation of the product or re. Use the product

and peripherals in a well-ventilated location.

yIf the product is used outside the optimal temperature range (-20°C – 70°C / -40°F – 158°F),

performance can decline or malfunctions may occur.

yWhen entering or exiting a tunnel, when directly facing into bright sunlight, or when

recording at night without lighting the quality of recorded video may deteriorate.

yIf the product is damaged or the power supply is cut due to an accident, video may

not be recorded.

yDo not remove the microSD card while the microSD card is saving or reading data.

yThe data can be damaged or malfunctions may occur.

FCC Compliance Information

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protections against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception

which can be determined by turning the equipment o and on, the user is encouraged

to ty to correct the interference by one or more of the following measures.

yReorient or relocate the receiving antenna.

yIncrease the separation between the equipment and receiver.

yConnect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

yConsult the dealer or an experienced radio, TV technician for help.

yOnly shielded interface cable should be used.

Finally, any changes or modifications to the equipment by the user not expressly

approved by the grantee or manufacture could void the user’s authority to operate

such equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operation of this device.

FCC ID: YCK-DR590X-2CH

CAUTION

Any changed or modications in construction of this device which are not expressly

approved by the party responsible for compliance could void the user’s authority to

operate the equipment.

There is a risk of explosion if the battery is replaced by an incorrect type.

Dispose of used batteries according to the instructions.

CE WARNING

yChanges and modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

yIt is desirable that it be installed and operated with at least 20cm or more between

the radiator and a person’s body (excluding extremities: hand, wrists, feet, and

ankles).

Disposal of your BlackVue dashcam

1. All electrical and electronic products should be disposed of

separately from the municipal waste stream via designated

collection facilities appointed by the government or the local

authorities. Contact local authorities to learn about disposal and

recycling options available in your area.

2. The correct disposal of your BlackVue dashcam will help prevent

potential negative consequences for the environment and human

health.

3. For more detailed information about disposal of your BlackVue

dashcam, please contact your city oce, waste disposal service or

the shop where you purchased the product.

ICC Compliance

This Class [B] digital apparatus complies with Canadian ICES-003.

This radio transmitter has been approved by Industry Canada to operate with the

antenna types listed below with the maximum permissible gain and required antenna

impedance for each antenna type indicated. Antenna types not included in this list,

having a gain greater than the maximum gain indicated for that type, are strictly

prohibited for use with this device.

- IC Warning

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions:

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause

undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicable aux appreils

radio exempts de license.

L’exploitation est autoriséee aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et

(2) l ’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, méme si

le brouillage est susceptible d’encompromettre le fonctionnement.

IC: 23402-DR590X2CH

Declaration of Conformity

Product information

For the following

Product: radio equipment/ dashcam

Type: DR590X-1CH

Declaration and applicable standards

Hereby, TJM Supplies B.V. declares that the type of radio equipment DR590X-1CH

conforms to:

Directive EMC 2014/53/EU and the RoHS directive (2011/65/EU) on the restriction of

the use of certain hazardous substances in electronic equipment by applying EN 50581:

2012 and IEC 62321-3-1: 2013.

The full text of the EU declaration of conformity can be found at the following internet

address:

https://blackvue-nederland.nl/declaration-of-conformity/

Importer

Company: TJM Supplies B.V.

Address: Zompstraat 8

8102 HX Raalte

The Netherlands

Email: [email protected]

Phone number: +31 85-0402973

Business license number: 72016981

VAT number: NL858946439B01

Verklaring van overeenstemming

Productgegevens

Voor het volgende

Product: radioapparatuur/ dashcam

Model(len): DR590X-1CH

Verklaring en toepasselijke normen

Hierbij verklaart TJM Supplies B.V., dat het type radioapparatuur DR590X-1CH conform is

met:

Richtlijn EMC 2014/53/EU en de RoHS richtlijn (2011/65/EU) betreffende beperking

van het gebruik van bepaalde gevaarlijke stoffen in elektronische apparatuur door

toepassing van EN 50581:2012 en IEC 62321-3-1:2013.

De volledige tekst van de EU-conformiteitsverklaring kan worden geraadpleegd op het

volgende internetadres:

https://blackvue-nederland.nl/declaration-of-conformity/

Importeur

Bedrijfsnaam: TJM Supplies B.V.

Adres: Zompstraat 8

8102 HX Raalte

Nederland

Email: [email protected]

Telefoon: +31 85-0402973

KVK nummer: 72016981

BTW nummer: NL858946439B01

In the box

Check the box for each of the following items before installing the BlackVue dashcam.

Front camera Cigarette lighter

power cable

Quick start guide Cable clips (3 EA)

microSD Card microSD card adapter

Double-sided tape

for the Mounting

Brackets

Hardwiring

power cable

(Optional)

External GPS - USB

Type

(Optional)

Need help?

Download the manual (including FAQs) and the latest rmware from

www.blackvue.com

Or contact a Customer Support expert at cs@pittasoft.com

ENGLISH

At a glance

The following diagrams explain each part of the BlackVue dashcam.

Front camera

34 mm

Camera lens

Mounting bracket Front security LED

: Lights on during (i) normal mode, (ii) an event is

being recorded (impact detected), (iii) manual

recording has started, or (iv) motion is detected

in parking mode.

: Blinks slowly during parking mode motion

detection standby.

Lock button

42.6 mm

111.8 mm

GPS LED

GPS is on.

Recording LED

: Lights orange in normal mode.

: Lights red when (i) an event is being recorded (impact detected),

or (ii) manual recording has started.

: Lights green in parking mode when motion is detected.

Speaker

LTE/Wi-Fi LED

Lights yellow when Cloud is connected

Lights white when Wi-Fi is connected

Blinks quickly when LTE/Wi-Fi is turning o.
