Bosch GPL100-30G Istruzioni per il montaggio

Operating / Safety Instructions

Consignes d’utilisation / de sécurité

Instrucciones de funcionamiento y seguridad

GPL100-30G

GPL100-50G

IMPORTANT:

Read Before Using

IMPORTANT :

Lire avant usage

IMPORTANTE:

Leer antes de usar

English Version

See page 6

Version française

Voir page 29

Versión en español

Ver la página 55

1-877-BOSCH99 (1-877-267-2499) www.boschtools.com

GPL100-50G

GPL 100-30G

GPL100-30G 50G 11-20.indd 1 4/23/21 5:27 PM

-2-

GPL100-50G

GPL100-30G

(1)

(2)

(3)

GPL100-30G 50G 11-20.indd 2 4/23/21 5:27 PM

-3-

(1) (4)

(5)

(6)

(7)

(8)(9)(1)

GPL100-50G

GPL100-30G 50G 11-20.indd 3 4/23/21 5:27 PM

-4-

GPL 100-50G

click!

GPL100-30G 50G 11-20.indd 4 4/23/21 5:27 PM

-5-

(10)

1 608 M00 05J

(11)

BT 150

0 601 096 B00

(12)

6 082 762 2ZX

GPL100-30G 50G 11-20.indd 5 4/23/21 5:27 PM

-6-

Safety Symbols

The definitions below describe the level of severity for each signal

word. Please read the manual and pay attention to these symbols.

This is the safety alert symbol. It is

used to alert you to potential personal

injury hazards. Obey all safety

messages that follow this symbol to

avoid possible injury or death.

Read manual symbol - Alerts user to

read manual.

DANGER indicates a hazardous

situation which, if not avoided, will

result in death or serious injury.

WARNING indicates a hazardous

situation which, if not avoided, could

result in death or serious injury.

CAUTION indicates a hazardous

situation which, if not avoided, could

result in minor or moderate injury.

GPL100-30G 50G 11-20.indd 6 4/23/21 5:27 PM

-7-

Read all instructions. Failure to follow all

instructions listed below may result in

hazardous radiation exposure, electric shock, fire and/or serious

injury. The term “tool” in all of the warnings listed below refers to your

mains-operated (corded) tool or battery-operated (cordless) tool.

The following

labels are on

your laser tool for your

convenience and safety. They

indicate where the laser light is

emitted by the tool. ALWAYS BE

AWARE of their location when

using the tool.

Do not direct the laser beam at persons or

animals and do not stare into the laser beam

yourself. This tool produces laser class 2 laser

radiation and complies with 21 CFR 1040.10 and

1040.11 except for conformance with IEC 60825-1

Ed. 3., as described in Laser Notice No. 56, dated

May 8, 2019. This can lead to persons being blinded.

DO NOT remove or deface any warning or caution labels.

Removing labels increases the risk of exposure to laser radiation.

Use of controls or adjustments or performance of procedures

other than those specified in this manual, may result in hazardous

radiation exposure.

ALWAYS make sure that any bystanders in the vicinity of use

are made aware of the dangers of looking directly into the laser

tool.

DO NOT place the laser tool in a position that may cause

General Safety Rules

GPL100-30G 50G 11-20.indd 7 4/23/21 5:27 PM

-8-

anyone to stare into the

laser beam intentionally or

unintentionally. Serious eye

injury could result.

ALWAYS position the laser

tool securely. Damage to the

laser tool and/or serious injury to

the user could result if the laser

tool fails.

ALWAYS use only the

accessories that are

recommended by the

manufacturer of your laser

tool. Use of accessories that

have been designed for use with

other laser tools could result in

serious injury.

DO NOT use this laser tool for

any purpose other than those

outlined in this manual. This

could result in serious injury.

DO NOT leave the laser tool

“ON” unattended in any

operating mode.

DO NOT disassemble the

laser tool. There are no user

serviceable parts inside. Do

not modify the product in any

way. Modifying the laser tool

may result in hazardous laser

radiation exposure.

DO NOT use the laser viewing

glasses as safety goggles.

The laser viewing glasses are

used for improved visualization

of the laser beam, but they

do not protect against laser

radiation.

DO NOT use the laser viewing

glasses as sun glasses or

in traffic. The laser viewing

glasses do not afford complete

UV protection and reduce color

perception.

DO NOT use any optical tools

such as, but not limited to,

telescopes or transits to view

the laser beam. Serious eye

injury could result.

DO NOT stare directly at the

laser beam or project the

laser beam directly into the

eyes of others. Serious eye

injury could result.

Work area safety

Keep work area clean and well

lit. Cluttered or dark areas invite

accidents.

DO NOT operate the laser

tool around children or

allow children to operate

the laser tool. Serious

eye injury could result.

GPL100-30G 50G 11-20.indd 8 4/23/21 5:27 PM

-9-

DO NOT use laser tools,

attachments and accessories

outdoors when lightning

conditions are present.

Do not operate the measur-

ing tool in explosive environ-

ments, such as in the presence

of ﬂammable liquids, gases or

dusts. Sparks can be created in

the measuring tool which may ig-

nite the dust or fumes.

Electrical safety

Batteries

can

explode or leak, cause injury

or fire. To reduce this risk,

always follow all instructions and

warnings on the battery label and

package.

DO NOT short any battery

terminals.

DO NOT charge alkaline

batteries.

DO NOT mix old and new

batteries. Replace all of them at

the same time with new batteries

of the same brand and type.

DO NOT mix battery chemistries.

Dispose of or recycle batteries

per local code.

DO NOT dispose of batteries

in fire.

Keep batteries out of reach of

children.

Remove batteries if the device

will not be used for several

months.

Personal safety

If laser radiation strikes your

eye, you must deliberately

close your eyes and imme-

diately turn your head away

from the beam.

Do not make any modiﬁca-

tions to the laser equipment.

Stay alert, watch what you

are doing and use common

sense when operating a tool.

Do not use a tool while you are

tired or under the influence of

drugs, alcohol or medication.

A moment of inattention while

operating a tool may result

in serious personal injury or

incorrect measurement results.

Use safety equipment.

Always wear eye protection.

Safety equipment such as dust

mask, non-skid safety shoes,

hard hat, or hearing protection

used for appropriate conditions

GPL100-30G 50G 11-20.indd 9 4/23/21 5:27 PM

-10-

will reduce personal injuries.

Use caution when using laser

tools in the vicinity of electrical

hazards.

Magnets

Keep the tool and

mounting bracket

away from

implants or other

medical devices such as

pacemaker or insulin pumps.

The magnets generate a field

that can impair the function of

implants or medical devices,

which may lead to serious

personal injury.

Keep the tool and mounting

bracket away from magnetic

data storage medium and

magnetically sensitive

equipment. The effect of

the magnets can lead to

irreversible data loss.

Use and care

Use the correct tool for

your application. The correct

tool will do the job better

and safer.

Do not use the tool if the

switch does not turn it on

and off. Any tool that cannot

be controlled with the switch

is dangerous and must be

repaired.

Store idle tool out of the

reach of children and do

not allow persons unfamiliar

with the tool or these

instructions to operate the

tool. Tools are dangerous in

the hands of untrained users.

Maintain tools. Check for

misalignment or binding

of moving parts, breakage

of parts and any other

condition that may affect the

operation. If damaged, tool

repaired before use. Many

accidents are caused by poorly

maintained tools.

Use the tool, accessories,

etc., in accordance with

these instructions and in

the manner intended for the

particular type of tool, taking

into account the working

GPL100-30G 50G 11-20.indd 10 4/23/21 5:27 PM
